4. Install the cover again.
5. Have the power sunroof checked by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility. Emergency closing may cause the power sunroof and its pinch
protection to malfunction.
Emergency release for the selector lever

Fig. 155 Removing the selector gate cover.

Fig. 156 Releasing the selector lever lock.

Removing the selector gate cover
x Pull upward on the cover around the selector lever sleeve ⇒ fig. 155.
x Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever
x Push the release lever ⇒ fig. 156 in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
WARNING
Never shift the transmission out of Park (P) without first firmly applying the parking brake.
Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause
an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the
vehicle is towed (or you let it coast) for an extended period or at high speed with the engine
shut off.

Vehicle tool kit

The vehicle tool kit is in the luggage compartment in one of several places, such as under the luggage
compartment floor panel ⇒ fig. 157.
x Open the luggage compartment lid .
x Grasp the floor panel by the handle and lift it up in the direction of the arrow ; remove it if
necessary.
Completely retract the jack after use. Otherwise it will not fit in its compartment and cannot be
stowed safely.
Contents

Fig. 158 Contents of the vehicle tool kit.

Wheel covers

Hubcaps

Fig. 159 Pulling the hubcap off.

Fig. 160 Twisting the hubcap off.

Wheel covers

Fig. 161 Pulling the wheel cover off.

x Take the wire clip out of the vehicle tool kit .
x Insert the wire clip through the opening of the cover cap ⇒ fig. 162 and pull off in the direction of
the arrow.
The caps are designed to protect the wheel bolts and should be installed again after the wheel
change.
The anti-theft wheel bolt has a separate cap. This only fits the anti-theft wheel bolt, but not the
standard wheel bolts.

Changing a wheel

Fuses
