VOLKSWAGEN JETTA HYBRID 2013 1B / 6.G Repair Manual

injuries. Improper seating positions also increase the risk of serious injury or death when an airbag
deploys and strikes an occupant who is not in the proper seating position. The driver is responsible for
all passengers and especially children riding in the vehicle.
The following are only some examples of seating positions that will increase the risk of serious injury
or death.
Therefore, whenever the vehicle is moving:
x Never stand up in the vehicle.
x Never stand on the seats.
x Never kneel on the seats.
x Never ride with the seat backrest reclined.
x Never lean up against the instrument panel.
x Never lie down on the rear seat.
x Never sit on the edge of the seat.
x Never sit sideways.
x Never lean out the window.
x Never put your feet out the window.
x Never put feet on the instrument panel.
x Never rest your feet on the seat cushion or back of the seat.
x Never ride in the footwell.
x Never sit on the front or rear center armrest.
x Never ride without your safety belt properly fastened.
x Never ride in the luggage compartment.
WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are
properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when
an airbag deploys and strikes a passenger in an improper seating position.
Proper seating position

Fig. 35 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 36 Proper safety belt positioning and head restraint adjustment.

x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger–front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the
airbag is deployed.
Manual controls on the driver and passenger seat

Fig. 37 Controls on the left front seat.

Electrical controls on the driver and front passenger seats

Fig. 38 Driver seat: Controls to adjust the seat backward and forward, adjust seat cushion height, and
backrest angle (if applicable).

When entering and exiting the vehicle, be careful not to come into contact with any switches that
could change the seat adjustment.
Adjusting the front and rear head restraints

Fig. 39 Adjusting the head restraints.

WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the
risk of neck injury in a crash. Each head restraint must be adjusted according to the
occupants' size so that the upper edge is even with the top of the person's head, but no
lower than eye level. Always sit so that the back of your head is as close as possible to the
head restraint.
x Never adjust head restraint while driving.
Removing and reinstalling the head restraints

Fig. 40 Removing the front head restraints.

Fig. 41 Removing the rear head restraints.

Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒  in Adjusting the front and rear head restraints Recline the backrest with the head
restraint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 40 (1) to unlock the head restraint.
x Push the flat object (plastic card) in against the guide rod to depress a release button located
under the cap (not visible).
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same
guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The
right-hand guide rod is now released.
x To release the left-hand guide rod, press button (2) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (2).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Adjust the head restraint according to the occupant's size
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward .
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 41 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward .
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are
properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not
strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle
could otherwise be damaged.

Adjusting the steering wheel position

Fig. 42 Manual adjustment for the steering wheel position.

Center armrest

Fig. 43 Front center armrest.

Fig. 44 Folding down the rear center armrest.

WARNING
The center armrest can restrict the driver's arm movement and cause crashes and serious
personal injury.
x Always keep storage compartments in the center armrest closed while driving.
x Never let a passenger, especially a child, ride on the center armrest. Improper seating
position can increase the risk of serious personal injury in a crash.
x Never put hot drinks or other liquids in the cup holder. Hot liquids can spill when the
vehicle is moving as well as during braking or other sudden maneuvers.
