Contents of the vehicle tool kit ⇒ fig. 181
(1) Screwdriver with a hexagonal socket in the handle for removing or inserting previously
loosened wheel bolts. The screwdriver blade is reversible. The screwdriver may be stored
under the lug wrench.
(2) Adapter for anti-theft wheel bolts. Volkswagen recommends that you always carry the adapter
for the wheel bolts in the vehicle along with the vehicle tool kit. The code number of the wheel
bolt lock is imprinted on the front of the adapter. If lost, a replacement adapter can be ordered
using this number. Record the code number of the wheel bolt lock and store it separately from
the vehicle.
(3) Screw-in towing eye.
(4) Hubcap puller clips for removing hubcaps, wheel covers, or wheel bolt caps.
(5) Jack. Before putting the jack back in the foam insert, make sure to completely crank the jack
down to its original position. The crank must then be locked against the side of the jack;
otherwise, the jack will not fit and cannot be securely stowed.
(6) Lug wrench.
x Take the wire clip out of the vehicle tool kit .
x Insert the wire clip through the opening of the cover cap ⇒ fig. 185 and pull off in the direction of
the arrow.
The caps are designed to protect the wheel bolts and should be installed again after the wheel
change.
The anti-theft wheel bolt has a separate cap. This only fits the anti-theft wheel bolt, but not the
standard wheel bolts.
WARNING
Changing a wheel, especially on the side of the road, can be dangerous. To help reduce the
risk of serious personal injury:
x Always stop the vehicle as soon as it is safe to do so. Move the vehicle a safe distance off
the road where it is safe to change the wheel.
x Always make sure that all passengers, especially children, are in a safe place outside the
vehicle and away from the vehicle and traffic (such as behind a guard rail).
x Turn on the emergency flashers and set up another warning device about 25 yards
(25 meters) behind the vehicle to warn approaching traffic.
x Change a wheel by yourself only if you are familiar with the necessary steps. Otherwise,
get expert assistance.
x Always switch the engine off, firmly apply the parking brake, and shift the transmission
into Park (P) (automatic transmission) or any gear (manual only) to help prevent the vehicle
from moving suddenly and slipping off the jack.
x Always make sure that the ground is level and firm. If necessary, place the jack on a large
and sturdy board or on a similar ground support.
x Always block the wheel diagonally opposite the wheel being changed with chocks or other
similar things.
x If you are towing a trailer, always unhitch it from your vehicle before starting to change
the wheel. Always apply the trailer brakes firmly and make sure the trailer cannot move
unintentionally.
x Always use proper and undamaged tools when changing a wheel.
x Once a wheel is lifted off the ground, having the transmission in Park (P) or in gear will not
prevent sudden vehicle movement.
x Always use a jack that has been approved by the manufacturer for your vehicle. Never use
other jacks, even if they have been approved for use on other Volkswagen models.
x To reduce the risk of losing control, crashes, and serious personal injuries, never loosen
the screws on rims with threaded rim rings.
x After changing a wheel, have the wheel bolt tightening torque checked with an accurate
torque wrench.
x After changing a wheel or tire, reset the Tire Pressure Monitoring System .
Color Current strength in amps
Green 30
Orange 40
Opening the fuse box in the instrument panel
x Insert a flat object, such as a screwdriver from the vehicle tool kit, into the opening ⇒ fig. 191
(magnified view) and carefully lift off the cover.
x On the inside of the cover there are plastic tweezers (1) for removing and inserting fuses.
x To install, guide the cover from the bottom into the instrument panel and push until you can hear it
latch into place.
Opening the fuse box in the engine compartment
x Open the engine hood
