VOLKSWAGEN JETTA SPORTWAGEN 2013 1B / 6.G Owner's Guide

d Are special or heavy-duty tires necessary for the kind of driving expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may result from substandard fuel
or service or the unavailability of Genuine Volkswagen parts.
Driving through water on roads

Technical data

Fig. 18 Vehicle identification number (VIN).

Maximum power
output (SAE net)
Injection
technology
Engine
ID
code
Maximum torque No. of cylinders
Displacement
170 hp at 5700 rpm
(125 kW at 5700 rpm) SRE
CBTA,
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinders
151 CID
2480 ccm

Diesel engines

Maximum power
output (SAE net)
Injection
technology
Engine
ID
code
Maximum torque No. of cylinders
Displacement
140 hp at 4000 rpm
(103 kW at 4000 rpm)
TDI® with
DPF
CJAA
2.0L
236 lb-ft at 1750 rpm
(320 Nm at 1750 rpm)
4 cylinders
120 CID
1968 ccm

Dimensions

Vehicle key set

Remote control vehicle keys

Fig. 19 Remote control vehicle key with panic button.

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons or the power locking buttons are pushed repeatedly in
quick succession, the power locking system is switched off for a brief period to help keep it from being
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is
opened in this span of time, the vehicle is automatically locked afterwards.
Mechanical key

Fig. 20 Mechanical key.

Indicator light in the remote control vehicle key

Fig. 21 Indicator light in the remote control vehicle key.

Power locking and closing system
