ABS hydraulic unit and ABS control
module (Teves 20 GI), removing and
installing
Carefully read and follow all cautions and
warnings Page 45-7 before beginning work.
Location
The ABS control module is bolted to the ABS
hydraulic unit, located on the left-side of the
engine compartment.

CAUTION!
Do not bend brake lines at or near the ABS
hydraulic unit.
Switch ignition OFF when disconnecting and
reconnecting the ABS control module
connector.
Part numbers are listed here for reference
only. Always check with your Parts
department for the latest information. Sealing plug kit Part No. 1H0 698 311 A:
1 - Valve dome transportation protection (plastic
foam)
2 - Sealing plugs -M10- 3 - Sealing plugs -M12- Page 3 of 9ABS, ABS/EDL hydraulic unit, vacuum brake booster and brake master cylinder (Teves 20 GI), servicing12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.45.3
