VOLKSWAGEN PASSAT 2007 Owners Manual

WARNING
Improperly positioned safety belts can cause serious personal injury in an accident or a sudden braking maneuver.
x Always make sure that all vehicle occupants are correctly restrained and stay in a correct seating position whenever the vehicle is being used.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are correctly positioned on the body.
x A loose-fitting safety belt can cause serious injuries by shifting its position on your body from the strong bones to more vulnerable soft tissue and cause serious injury.
x The shoulder belt portion of the safety belt must be positioned over the middle of the occupant's shoulder and never across the neck or throat.
x The safety belt must lie flat and snug on the occupant's upper body.
x Never wear the shoulder part of the safety belt under your arm or otherwise out of position.
x The lap portion of the safety belt must be positioned as low as possible across the pelvis and never over the abdomen. Make sure the belt lies flat and snug against the pelvis. Pull on the safety belt to tighten if necessary.
x Expectant mothers must always wear the lap portion of the safety belt as low as possible across the pelvis and below the rounding of the abdomen.
x Do not twist the belt when attaching it. If you cannot untwist a twisted safety belt, wear it anyway, but make sure the twisted part is not in contact with your body. Have the problem corrected right away by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Never hold the safety belt away from your body with your hand.
x Never wear belts over rigid or breakable objects, such as eyeglasses, pens or keys.
x Never modify the position of the belt using comfort clips, loops or similar devices.

x If you have a physical impairment or condition that prevents you from sitting properly on the seat with the safety belt properly fastened, special modifications to your vehicle may be necessary.
x Contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility or call the Volkswagen Customer CARE Center at 1-800-822-8987 for information about possible modifications to your vehicle.
Safety belt height adjusters

Fig. 81 Next to the front seats: Safety belt height adjuster.

If a safety belt is too short to correctly fit you or one of your passengers, even when the safety belt is pulled out all the way, you can use a safety belt extender.
Never use the safety belt extender for any other purpose – including the attachment of a child restraint.
The extender adds about 8 inches (20 cm) to the safety belt. Always remove the safety belt extender when it is not needed and stow it safely. Contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility if you believe you may need an extender.
Key to fig. 82:
(1) Vehicle safety belt buckle.
(2) Buckle tongue on the safety belt extender.
(3) Safety belt buckle on the safety belt extender.
(4) Safety belt buckle tongue on the factory-installed safety belt.
Key to fig. 83:
(A) Safety belt buckle on the safety belt extender.
(B) Distance between the safety belt buckle on the safety belt extender and the centerline of the person using the safety belt extender. The distance must be more than 6 inches (15 cm)!
(C) Centerline of the person using the safety belt extender.
Using a safety belt extender
x Adjust both the seat and the head restraint properly, Adjusting the seating position.
x Insert the buckle tongue on the safety belt extender ⇒ fig. 82 (2) into the vehicle belt buckle for the seat where the safety belt extender is being used (1).
x Fastening or unfastening the vehicle safety belt ⇒ page 101, Fastening and unfastening safety belts.
x Pull the belt to make sure that the tongues are securely locked in the buckles.
x Make sure that the safety belt is positioned properly, Safety belt position, Safety belt position.
Properly using safety belt extenders:
x Use a safety belt extender only when the factory installed safety belt is too short when worn properly by a person in proper seating position.
x Only use 1 safety belt extender per seat and vehicle safety belt.
x Always remove the safety belt extender when it is not needed.
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is not needed and being used with the safety belt. Otherwise, the airbag control module will receive an incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a person who is not using the safety belt. Leaving the extender attached to the safety belt buckle when the front seat is occupied and the safety belt is not being used will signal the airbag control unit during a collision that the front passenger seat is occupied and that the safety belt is being used. The electronic control unit for the airbag system will then receive incorrect information that will cause the safety belt pretensioner to deploy unnecessarily and the front passenger airbag to deploy later in collisions that would normally trigger the front airbag earlier in the collision to help protect an unrestrained front seat occupant. The airbag will not be able to provide enough protection for an occupant not wearing a safety belt.
x Only use the safety belt extender approved by Volkswagen for your vehicle.

WARNING
Improper use or positioning of a safety belt extender increases the risk of serious personal injury and death.
x A driver or passenger who is not properly restrained can be seriously injured by striking the interior of the passenger compartment or by the safety belt itself, which can be displaced from stronger parts of the body into sensitive areas like the abdomen.
x Safety belt extenders offer optimum protection only when they are properly used.
x Only use the extender when the belt is not long enough to be worn low and snug and the person is in the correct seating position. Remove and stow extender safely when not needed.
x Always make sure the safety belt tongue of the safety belt extender is securely inserted into the buckle for the seating position that belongs to the seat where the safety belt extender is being used. Attaching the safety belt to the wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never use the safety belt extender if you can properly attach the safety belt without it. Using a safety belt extender when not needed can increase the risk of injury, especially in a collision.
x Never use a safety belt extender if the distance (B) between the front edge of the safety belt extender buckle (A) and the centerline of the person using the safety belt extender
⇒ fig. 83 (C) is less than 6 inches (15 cm).
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is not needed and being used with the safety belt. Otherwise, the airbag control module will receive an incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a person who is not using the safety belt.
x Never use more than 1 extender with a safety belt. Using more than 1 extender can change the way the safety belt passes over the body and can cause serious injury.
x Never use the safety belt extender to secure a child restraint.
x Never use a safety belt extender on your Volkswagen that you got from another automobile manufacturer or from an automotive parts store.
x Never use the safety belt extender you got for your vehicle for any other vehicle, regardless of make, model, or model year.
NOTICE
x Leaving the extender attached to the safety belt buckle when the front seat is occupied and the safety belt is not being used will signal to the airbag control unit that the front passenger seat is occupied and that the safety belt is being used. The electronic control unit for the airbag system will then receive incorrect information that will
– cause the safety belt pretensioner to deploy unnecessarily in collisions
– cause the front passenger airbag to deploy later in collisions in which the front airbag would otherwise be triggered earlier to help protect an unrestrained front seat passenger.
x A pretensioner that has deployed cannot be repaired. The entire safety belt must be replaced.
NOTICE
If the safety belt extender is left attached to the safety belt buckle, the safety belt warning system will sense that the safety belt for that seat is being used. The warning light will not come on and the warning chime will not sound even though the seat is occupied and the safety belt is not being used.

Safety belt retractor, pretensioner, load limiter

WARNING
Improper handling, care, servicing, and repair procedures can increase the risk of personal injury and death by preventing a belt pretensioner from activating when needed or by causing it to activate unexpectedly.
x The pretensioner can be activated only once. If a pretensioner has been activated, the safety belt must be replaced.
x Safety belt systems including the pretensioners cannot be repaired. Special procedures are required to remove, install, and dispose of this system.
x Never repair, adjust, or change pretensioners or any other part of the safety belt system yourself. We strongly recommend that you have any work on the safety belt system performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. They have the necessary technical information, training, and special equipment, Parts, accessories, repairs and modifications.
WARNING
Undeployed safety belt pretensioners and airbag modules contain explosive materials that can cause serious personal injuries if they are not properly handled when they or the vehicles they are installed in are scrapped.
x Never abandon vehicles or vehicle parts.
x Always scrap vehicles and vehicle parts, especially those containing undeployed airbag modules and undeployed safety belt pretensioners, at a licensed facility that has the knowledge and experience to properly dispose of the vehicle and its safety belt and airbag systems.
Undeployed airbag modules and safety belt pretensioners are classified as Perchlorate Material. Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all applicable legal requirements regarding handling and disposal of the vehicle or parts of its restraint system, including airbag modules and safety belts with pretensioners. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.

Lights

Lights up Possible cause Proper response
 One or more driving lights not working or cornering light malfunction.
Replace burned out bulb or if all light bulbs are OK, see an authorized Volkswagen dealer or authorized Volkswagen Service facility.
Fog lights switched on (indicator light on the headlight switch).
Z

Turn signal lever and high beam switch

Fig. 97 Turn signal lever and high beam switch.

High beams can only be switched on when low beams are on.
Switching lights on and off

Fig. 98 Headlight switch next to the steering wheel: A vehicles with front fog lights. B vehicles without front fog lights.
