VOLKSWAGEN PASSAT 2008 Owners Manual

Driving with an open luggage compartment lid

Driving a loaded vehicle

x Factory-installed or retrofitted accessories.
x Hitch weight and tongue weight for trailer towing.
Please refer to the Gross Vehicle Weight Rating (GVWR) and the Gross front and rear Axle Weight Ratings (GAWR) for your vehicle, which are printed on the vehicle's Safety Compliance Certification Label on the driver door jamb.
WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as little as possible.
Gasoline engines

Maximum power output (SAE net) Engine ID code Transmission Curb weight4 Gross vehicle weight rating
Gross front axle weight rating
Gross rear axle weight rating
170 hp (125 kW) CBTA
5S manual
3272 – 3300 lbs(1484 – 1497 kg)
4431 lbs (2010 kg) 2271 lbs(1030 kg) 2271 lbs (1030 kg)
6S automatic
3325 – 3360 lbs(1508 – 1524 kg)
4475 lbs (2030 kg) 2315 lbs(1050 kg) 2271 lbs (1030 kg)
280 hp (206 kW) CDVB DSG® 6S automatic
3448 – 3481 lbs(1564 – 1579 kg)
4630 lbs (2100 kg) 2381 lbs(1080 kg) 2359 lbs (1070 kg)

Diesel engines

4 Depending on equipment version.

Maximum power output (SAE net) Engine ID codeTransmission Curb weight4 Gross vehicle weight rating
Gross front axle weight rating
Gross rear axle weight rating
140 hp (103 kW) with DPF CKRA 6S manual 3441 – 3468 lbs(1561 – 1573 kg)
4586 lbs (2080 kg) 2359 lbs (1070 kg) 2337 lbs (1060 kg)
DSG® 6S automatic 3497 – 3519 lbs(1586 – 1596 kg)
4652 lbs (2110 kg) 2425 lbs (1100 kg) 2337 lbs (1060 kg)

WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as little as possible.

Luggage compartment

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal injury during hard braking or sharp steering or in an accident. Loose items can also be struck and thrown through the passenger compartment by the front airbags if they inflate. To help reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that they cannot move into the deployment zone of a side or front airbag during sudden braking, in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle interior and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and increases braking distances. Heavy loads which are not properly stowed or secured in the vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings, which are printed on the Safety Compliance Certification Label located on the door jamb of the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave differently.
x Always adapt your speed and driving style to accommodate your payload and its weight distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid sudden braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can be damaged by objects that rub against them.
The ventilation slots between the rear window and the luggage compartment cover must not be blocked so that stale air can escape from the vehicle.

Folding the rear seat backrest forward and back into place

Fig. 112 On the left side of the luggage compartment: Release lever for the left-side rear seat backrest. The release lever for the right-side rear seat backrest is on the right side of the luggage compartment.

Fig. 113 Rear seat bench: Seat backrest folded down.

WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal injury.
x Always make sure there are no people or animals in the area around the rear seat backrest when folding it forward.
x Never fold the rear seat backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get caught or damaged.
x Keep hands, fingers, feet and other body parts out of the way when folding the rear seat backrest up and down.
x Each rear seat backrest must be securely latched in the upright position so that the safety belts on the rear seats can provide protection. This is particularly the case for the middle seat on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together with the rear seat backrest during sudden braking, driving maneuvers, or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head restraint or backrest cushion will not touch the front seats.
There is a separate release lever in the luggage compartment for each rear seat backrest section.
Luggage compartment pass-through

Fig. 114 In the rear seat backrest: Opening luggage compartment pass-through without lock.

Fig. 115 In the rear seat backrest: Opening luggage compartment pass-through with lock.

Tie-downs

Fig. 116 In the luggage compartment: Tie-downs.
