Fig. 61 Adjusting the rear head restraints.

Removing and reinstalling head restraints

Fig. 62 Removing the front head restraints.

Fig. 63 Removing the rear head restraints.

Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Adjust the head restraint according to the occupant's size, Adjusting front and rear head restraints.
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward, Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 63 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward, Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size, Adjusting front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged.

Adjusting the steering wheel position

Fig. 64 Manual adjustment for the steering wheel position.

Center armrest

Fig. 65 Front center armrest.

Fig. 66 Folded down rear center armrest with storage compartment (arrow).

WARNING
The center armrest can restrict the driver's arm movement and cause crashes and serious personal injury.
x Always keep storage compartments in the center armrest closed while driving.
x Never let a passenger, especially a child, ride on the center armrest. Improper seating position can increase the risk of serious personal injury in a crash.
x Never put hot drinks or other liquids in the cup holder. Hot liquids can spill when the vehicle is moving as well as during braking or other sudden maneuvers.

Seat functions

x If the outside temperature or the temperature inside the passenger compartment is 77 °F (25 °C) or more.

Function Action for seat heating ⇒ fig. 67
Switch on: Press the A button. Seat heating is switched on to maximum.
Adjust the heating level: Press the button Arepeatedly until the desired heating level is set.
Switch off: Press the buttonArepeatedly until all indicator lights in the button are off.
Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the ignition was switched off. However, this feature only works if the key is not taken out of the ignition switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature
⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks, and legs that may take a long time to heal and may never heal completely. If you have any of these conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain can receive serious burns to the back, buttocks, and legs that take a long time to heal or may never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned because of a medical condition. Take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.

x Liquids, sharp objects and things that do not let the heat in the seat escape into the air, including, for example, a child restraint, a blanket, or seat covers on the seat can damage seat heating.
x If you smell an odor, immediately shut off seat heating and have it checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Never install leather upholstery on a vehicle with seat heating that originally had cloth upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth upholstery is replaced with leather upholstery.
Switch off seat heating when it is not needed to help reduce unnecessary fuel consumption.
Memory seats

Fig. 68 Memory buttons on the outer side of the driver seat.

Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position stored for backing up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is rotated from R into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory function:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock button 0 on the vehicle key and then press the desired memory button at the same time within about 3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
x Press and hold the SET button.
x Press and hold the unlock button 0 on the vehicle key and the desired memory button at the same time within about 10 seconds. A chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instructions, Assigning driver seat and outside mirror settings to a vehicle key to assign the driver seat and outside mirror settings to the vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button 1 in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions whenever the vehicle is unlocked with the vehicle key open button 0 and the driver door is opened. If two people use the vehicle, each of them should always use the key in which his or her personal settings have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can be reprogrammed and assigned to a vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x The vehicle battery is weak or dead.
x The SET button is pressed again within about 10 seconds.
x The seat position is readjusted within about 10 seconds after pressing the SET button.
