VOLKSWAGEN PASSAT 2013 B8 / 6.G Manual PDF

Luggage compartment lid

Warning light

Fig. 41 Opening luggage compartment lid from the outside.

Applicable only in Mexico, the AGCC, and South Korea
Opening the luggage compartment lid

Fig. 42 In the remote control vehicle key: Button to unlock and open the luggage compartment lid.

Fig. 43 Opening luggage compartment lid from the outside.

WARNING
Improper or unsupervised unlocking or opening of the luggage compartment lid can cause
severe injuries. Never open the lid when someone is in the way.
x If a bicycle or luggage rack is installed on the luggage compartment lid, it may be hard to
see that the luggage compartment lid is unlatched. An unlatched luggage compartment lid
may open suddenly when the vehicle is moving.
At temperatures below +32 °F (0 °C), the luggage compartment lid may not open automatically
after you unlock it. It will be necessary to lift it by hand.
Closing the luggage compartment lid

Fig. 44 Opened luggage compartment lid: Recessed grips for closing.

WARNING
Improper or unsupervised closing of the luggage compartment lid can cause severe injuries.
Never close the lid when someone is in the way.
x Never leave your vehicle unattended or let children play around your vehicle, especially
with the luggage compartment lid left open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to get out. A closed vehicle can
become very hot or very cold depending on the season. Temperatures can quickly reach
levels that can cause unconsciousness or death, particularly to small children.
Make sure that the remote control vehicle key is not in the luggage compartment before closing
the luggage compartment lid.

Power windows

Switches in the driver door
Key to fig. 45:
(1) For the windows in the front doors.
(2) For the windows in the rear doors.
(3) Safety switch.
Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch.
Stopping automatic
movement:
Press/pull the switch again.
_
The safety switch (3) deactivates the power windows
in the rear doors. The yellow indicator light in the
switch comes on.

You can still use the power windows for several minutes after the ignition is switched off as long as the
driver or front passenger door has not been opened. When the vehicle key has been removed from
the ignition and the driver door has been opened, the power windows cannot be opened or closed.
Power windows – features

WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-
dows for several minutes after the ignition is switched off as long as the driver or front pas-
senger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
If the power windows malfunction, the one-touch feature, as well as pinch protection will not work
properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.

Power sunroof
