Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Roof antenna
(2) High-mounted brake light
(3) Rear window
– Rear window defroster
(4) Luggage compartment release
(5) Taillights
(6) Rear license plate bracket
(7) Luggage compartment lid
(8) License plate lights

Lower center console

Fig. 7 Overview of the lower center console.
Key to fig. 7:
(1) Levers for:
– Manual transmission
– Automatic transmission
(2) Storage compartment:
– with 12 Volt socket
– or with cigarette lighter
(3) Cup holder in the center console
(4) Storage compartment in the center armrest
– Multimedia jack (MEDIA-IN) ⇒ Booklet Radio or ⇒ Booklet Navigation system
– with AUX-IN jack ⇒ Booklet Radio or ⇒ Booklet Navigation system
– with 12 Volt socket
– There may be a small removable tray at the back of the storage compartment.
(5) Parking brake lever
(6) Starter button for Keyless Access locking and starting system

d Only transport as many passengers as there are seats and safety belts available.
d Never drive if your driving ability has been impaired, for example by medication, alcohol or illegal
drugs.
d Never let passengers or phone calls distract you while driving, and never take your attention off the
road while using vehicle software or adjusting vehicle equipment or accessories.
d Always adapt your speed and driving style to visibility, weather, road, and traffic conditions.
d Always obey traffic laws and speed limits.
d On long trips make frequent rest stops – at least once every 2 hours.
d Secure animals in the vehicle with a system that corresponds to weight and size.
WARNING
Always observe traffic rules and posted speed limits and use common sense. Your good
judgment can mean the difference between arriving safely at your destination and being seri-
ously injured in a crash or other kind of accident.
Regular service and maintenance of your vehicle is important both for operational and driving
safety and to help prolong your vehicle's service life. Always follow the scheduled maintenance inter-
vals in the ⇒ Booklet Warranty and Maintenance, especially for changing the brake fluid. Hard use,
frequent stop-and-go driving, driving in very dusty areas, trailer towing, and other factors may make it
necessary to have the vehicle serviced more frequently. Ask an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility for more information.
Driving in other countries

The daytime running lights are switched on whenever the ignition is switched on and the light switch is
in position / or !54/. The indicator light  or $2, in the instrument cluster indicates that the feature is
active.
If the light switch is in position !54/, a low-light sensor switches the instrument and switch lighting on
and off automatically.
Daytime running lights (DRL) parking feature
Some models are equipped with a daytime running lights (DRL) parking feature that switches the
daytime running lights off when the vehicle is parked and the ignition is switched on.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the O position.
– Set the parking brake.
Switching the DRL on: – Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper that are also static cornering lights. On some
models the static cornering lights may also be integrated in the headlights. At speeds below about
25 mph (40 km/h), the light on one side of the vehicle will come on automatically when you turn a
corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on. The
light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the !54/ position ⇒ fig. 96), they work only when the headlights have been
automatically switched on. The static cornering lights do not come on when the headlight switch is in
the O position or when the fog lights themselves have been switched on.
Automatic headlight control (!54/)
Automatic headlight control is a convenience feature only and cannot always recognize all lighting and
driving situations.
If the light switch is in the !54/ position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.

Turn the rotary knob to the desired position:
2 Adjust the right outside mirror by pressing the knob to left/right
and up/down.
 Neutral position. Outside mirror folded out, no heating or
adjustment possible.

Synchronous mirror adjustment
x In the Settings - Convenience menu, select Mirror adjust - Both mirrors for syn-
chronous outside mirror adjustment.
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the
same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Auto-dimming outside mirror on the driver side
The auto-dimming outside mirror is controlled together with the auto-dimming inside mirror.
Memory for front passenger side mirror (when backing up)
x Choose the remote control vehicle key that will be used with the settings about to be made.
x Unlock the vehicle with that remote control vehicle key.
x Set the parking brake.
x Switch on the ignition.
x Activate the function Mirror down in the Settings - Convenience menu.
x Shift the transmission into reverse.
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about
10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base
when moving the mirrors.

Turn the rotary knob to the desired position:
# Fold the outside mirror in toward the vehicle body ⇒ .
?_ Switch on outside mirror heating. Heats only at outside air
temperatures below +68 °F (+20 °C).
, Adjust the left outside mirror by pressing the knob to left/right
and up/down.
2 Adjust the right outside mirror by pressing the knob to left/right
and up/down.
 Neutral position. Outside mirror folded out, no heating or
adjustment possible.

Synchronous mirror adjustment
x In the Settings - Convenience menu, select Mirror adjust - Both mirrors for syn-
chronous outside mirror adjustment.
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the
same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Auto-dimming outside mirror on the driver side
The auto-dimming outside mirror is controlled together with the auto-dimming inside mirror.
Memory for front passenger side mirror (when backing up)
x Choose the remote control vehicle key that will be used with the settings about to be made.
x Unlock the vehicle with that remote control vehicle key.
x Set the parking brake.
x Switch on the ignition.
x Activate the function Mirror down in the Settings - Convenience menu.
x Shift the transmission into reverse.
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about
10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base
when moving the mirrors.

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances.
Heavy loads that are not properly stowed or secured can cause loss of control and serious
injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity
also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps using the tie-downs in the
luggage compartment.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the
safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the
vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Stowing luggage

For good handling when driving a loaded vehicle, please observe the following:
x Securely stow all luggage.
x Drive especially carefully and accelerate gently.
x Avoid sudden braking and driving maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
x If applicable, observe information about driving with a trailer.
WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances.
Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of con-
trol and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center
of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
– Use your vehicle's luggage compartment tie-downs with suitable straps.
x Always tie down heavy items securely with suitable straps.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the
safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the
vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the ve-
hicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Applicable only in the United States and Canada
Weights and axle weights

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal
injury during hard braking or sharp steering or in an accident. Loose items can also be struck
and thrown through the passenger compartment by the front airbags if they inflate. To help
reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the
luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that
they cannot move into the deployment zone of a side or front airbag during sudden braking,
in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on
the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle interi-
or and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and
increases braking distances. Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by
shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle
capacity weight figures apply when the load is distributed evenly in the vehicle (passengers
and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the
rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings,
which are printed on the Safety Compliance Certification Label located on the door jamb of
the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave
differently.
x Always adapt your speed and driving style to accommodate your payload and its weight
distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid sud-
den braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can be damaged by objects that rub
against them.
The ventilation slots between the rear window and the luggage compartment cover must not be
blocked so that stale air can escape from the vehicle.

WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and carrying heavy or bulky items changes the way the vehicle han-
dles and increases the distance it needs to stop safely.
x Always watch what is happening up ahead and around you. Brake earlier than you would
if you were not towing a trailer.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under
unfavorable load, weather, or wind conditions.
x Drive especially carefully and accelerate gently. Always avoid sudden maneuvers and
hard braking.
x Be especially careful when passing other vehicles.
x Reduce speed immediately if the trailer shows even the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas speed limits for vehicles towing trailers are lower
than for vehicles without trailers.
Ball mount

Fig. 115 Dimensions of the ball mount support.
