x Crack or chip in the windshield: If a stone hits and chips the windshield while the rain sensor is on, this will trigger a wiper cycle. After that, the rain sensor will recognize the change and re-calibrate itself to respond to the sensitive surface's reduced detection zone. Depending on the size of the chip, the sensor's reaction pattern may or may not change.
WARNING
The rain sensor cannot always recognize rain and activate the wipers.
x Switch the wipers on manually when water on the windshield reduces visibility.
Clean the rain sensor's sensitive surface ⇒ fig. 109 (arrow) regularly and check the wiper blades for wear or damage.
To remove wax and coats of polish safely, we recommend using an alcohol-based windshield cleaner.
Checking and refilling windshield washer fluid

Fig. 110 In the engine compartment: Cap of the windshield washer fluid reservoir.

Recommended cleaners
x For the warmer months, Windscreen Clear Summer G 052 184 A1 or equivalent. Mixing ratio 1:100 (1 part concentrate to 100 parts water) in the windshield washer reservoir.
x All-season Windscreen Clear G 052 164 A2 or equivalent. Mixing ratio in winter to 0 °F (-18 °C) about 1:2 (1 part concentrate to 2 parts water), otherwise mixing ratio 1:4 in windshield washer reser-voir.
Filling capacity
The windshield washer fluid reservoir holds about 1.2 gallons (4.5 liters).
WARNING
Never mix antifreeze or similar additives into the windshield washer reservoir. This could produce an oily film on the windshield, which would considerably reduce visibility.
x Use clear water (not distilled water) with a cleaning solution recommended by Volkswagen.
x If necessary, blend with a suitable windshield washer fluid antifreeze agent.
NOTICE
x Never mix cleaning solutions recommended by Volkswagen with other cleaning agents. If you do, this could cause sediments or other by-products that can clog the windshield wiper nozzles.
x When refilling, do not confuse one type of operating liquid with another! Otherwise serious malfunctions and engine damage can occur!

Mirrors

NOTICE
Broken glass in the auto-dimming mirrors can cause electrolyte fluid leakage. Liquid electro-lyte leaked from a broken mirror glass will damage any plastic surfaces it comes in contact with. Clean up spilled electrolyte fluid immediately with clear water and a sponge.
Inside mirror

Fig. 111 Manually adjustable inside mirror.

Fig. 112 Auto-dimming inside mirror.

The auto-dimming feature can be switched on and off with the switch on the inside mirror (2). When auto-dimming is activated, the indicator light (1) is on.
If the ignition is switched on, the sensor (3) automatically darkens the inside mirror depending on the amount of light shining into the vehicle from the rear.
The auto-dimming feature is deactivated when you shift the transmission into reverse or switch on the interior lights or the reading light.
Do not attach external navigation devices to the windshield or in the vicinity of the auto-dimming inside
mirror ⇒ .
WARNING
The illuminated display on an external navigation device can cause the auto-dimming inside mirror to malfunction, which can result in crashes and serious injuries.
x Malfunctions in the auto-dimming function can result in the inside mirror being unable to evaluate the exact distance of vehicles in the rear or other objects.
If the light striking the sensor is filtered or blocked (such as by a sunshade), the auto-dimming inside mirror will not work properly or may not work at all.
Outside mirrors

Fig. 113 In the driver door: Adjusting knob for outside mirrors.

Turn the rotary knob to the desired position:
2 Adjust the right outside mirror by pressing the knob to left/right and up/down.
 Neutral position. Outside mirror folded out, no heating or adjustment possible.

Synchronous mirror adjustment
x In the Settings - Convenience menu, select Mirror adjust - Both mirrors for syn-chronous outside mirror adjustment
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Auto-dimming outside mirror on the driver side
The auto-dimming outside mirror is controlled together with the auto-dimming inside mirror ⇒  Inside mirror.
Memory for front passenger side mirror (when backing up)
x Choose the remote control vehicle key that will be used with the settings about to be made.
x Unlock the vehicle with that remote control vehicle key.
x Set the parking brake.
x Switch on the ignition.
x Activate the function Mirror down in the Settings - Convenience menu.
x Shift the transmission into reverse.
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment position is used again.
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about 10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base when moving the mirrors.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and seri-ous injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision. But vehicles or other objects seen in a convex mirror will look smaller and farther away than they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by press-ing on the edges of the mirror surface.

Driving tips

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can cause loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps using the tie-downs in the luggage compartment.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Stowing luggage

Driving with an open luggage compartment lid
