Recommended cleaners
x For the warmer months, Windscreen Clear Summer G 052 184 A1 or equivalent. Mixing ratio 1:100 (1 part concentrate to 100 parts water) in the windshield washer reservoir.
x All-season Windscreen Clear G 052 164 A2 or equivalent. Mixing ratio in winter to 0 °F (-18 °C) about 1:2 (1 part concentrate to 2 parts water), otherwise mixing ratio 1:4 in windshield washer reser-voir.
Filling capacity
The windshield washer fluid reservoir holds about 1.2 gallons (4.5 liters).
WARNING
Never mix antifreeze or similar additives into the windshield washer reservoir. This could produce an oily film on the windshield, which would considerably reduce visibility.
x Use clear water (not distilled water) with a cleaning solution recommended by Volkswagen.
x If necessary, blend with a suitable windshield washer fluid antifreeze agent.
NOTICE
x Never mix cleaning solutions recommended by Volkswagen with other cleaning agents. If you do, this could cause sediments or other by-products that can clog the windshield wiper nozzles.
x When refilling, do not confuse one type of operating liquid with another! Otherwise serious malfunctions and engine damage can occur!

Air conditioner does not work
The air conditioner may not switch on for one of the following reasons:
x The engine is not running.
x The fan is switched off.
x The air conditioner fuse has blown.
x The outside air temperature is colder than about +38 °F (+3 °C).
x The air conditioner compressor has been temporarily switched off due to excessive engine coolant temperature.
x There is another malfunction in the vehicle. Have the air conditioner checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Special considerations
When it is very hot and humid outside, water condensation can drip from the air conditioner evapora-tor and form a puddle under the vehicle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment temperature as fast as possible considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield may fog up after the engine is started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.
The air coming out of the vents flows through the passenger compartment and through the vents under the rear window. Do not cover these slots with clothing or other things.
Air vents

Fig. 174 In the instrument panel: Air vents.

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find helpful information under “Characteristics” and “Checklist” in the index.

Description Possible causes, among others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump-start – Charge vehicle battery
The wrong vehicle key is used. Use a valid vehicle key
Fuel level too low. Refuel
AdBlue fill level too low. Refill AdBlue
Vehicle cannot be locked or unlocked using vehicle key.
– Battery in the remote control vehicle key dead. – Too far away from vehicle (out of range). – Buttons have been pressed too many times.
– Replace the battery in the remote control vehicle key – Move closer to vehicle. – Synchronize vehicle key – Lock or unlock vehicle manually
Unusual noises. Cold engine, braking assist systems, electronic steering column lock. Check the “Noises” entry in the index.
Odd driving behavior.
Assistance systems activated. Check the “Assistance systems” entry in the index.
DSG® Direct Shift Gearbox too hot. Stop vehicle as soon as you can do so safely
Outside mirrors move when vehicle is unlocked. Convenience settings are stored. Correct convenience settings
Front seats cannot be adjusted with power controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
Features do not work as described in this manual.
Settings were adjusted in the Volkswagen Information Sys-tem.
Check and reset to factory settings if necessary
Headlights do not light up the road as they should.
– Headlights adjusted too high.– Light bulbs burned out. – Low beams not switched on.
– Have the headlight range adjusted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facili-ty. – Change light bulbs – Switch on low beams

Description Possible causes, among others Possible remedy
Electrical consumers do not work.
Vehicle battery charge too low. Charge vehicle battery
Remaining fuel level too low. Refuel
Fuse blown. Check fuse and replace if necessary
Fuel consumption higher than indicated.
– Short hauls. – “Jumpy” accelerator pedal.
– Avoid short distance driving. – Drive defensively. – Accelerate smoothly.
Electrical loads switched on. Switch off unnecessary loads.
Engine control malfunctioning. Have the malfunction corrected
Tire pressure too low. Adjust tire pressure
Driving in the mountains. No direct corrective action possible.
Towing a trailer. – Check use. – Remove if not in use.
Driving with heavy payload. No direct corrective action possible.
Driving at high engine speed. Select a higher gear.

Fuses

A single load (a single electrical component) may be protected by several fuses.
One fuse may protect several loads (several electrical components).
Fuses in the vehicle

Fig. 214 On the driver side in the instrument panel: Fuse box cover.

Fig. 215 In the engine compartment: Fuse box cover.

Color Current strength in amps
Brown 7,5
Red 10
Blue 15
Yellow 20
White or clear 25
Green 30
Orange 40

Opening the fuse box in the instrument panel
x Pull the lower part of the cover in the direction of the arrow ⇒ fig. 214 and remove the cover from the bottom.
x On the inside of the cover there are plastic tweezers for removing and inserting fuses.
x To install, guide the cover from the bottom into the instrument panel and push in the direction
opposite to the arrow ⇒ fig. 214 until you can hear it latch into place.
Opening the fuse box in the engine compartment
x Open the engine hood ⇒ 
x Move the release tabs in the direction of the arrows ⇒ fig. 215 to unlock the fuse box cover.
x Remove the cover upward.
x To install push the cover onto the fuse box. The locking tabs must latch with an audible “click”.
Vehicles with battery located in the luggage compartment
There are additional fuses above the vehicle battery behind the panel on the left side of the luggage compartment. Have these fuses replaced by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
NOTICE
x To help prevent vehicle damage, be careful when removing fuse box covers and be sure to reinstall them properly.
x Open fuse boxes must be protected from dirt and moisture. Dirt and moisture in fuse boxes can cause damage to the electrical system.
The vehicle contains other fuses in addition to those mentioned in this section. Have these fuses replaced by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Replacing blown fuses

Fig. 216 Illustration of a blown fuse.

Fig. 217 Removing or inserting a fuse using the plastic tweezers.

x If necessary, replace the plastic tweezers in the fuse box cover.
x Replace the cover.
NOTICE
If a fuse is replaced with a fuse with higher amperage, then damage can occur at various plac-es in the electrical system.
