Sun protection

as a communications window for transmitting signals to and from
electronic components and accessories.
The uncoated area must not be blocked on the inside or outside or
covered with stickers because this can cause the electronic compo-
nents to malfunction.
Rear window sunshade

Fig. 91 In the center console: Button for the electrical sunshade on
the rear window.

NOTICE
To help prevent damage to the sunshade or the interior rim, do
not let the manual sunshade “snap” back down as it retracts.

Windshield wipers and washer

NOTICE
To help prevent damage to the wiper blades and the wiper motor
when it is cold outside, always make sure that blades are not
frozen to the windshield before operating the wipers. Using the
windshield wiper service position can be helpful in cold weather
so the wipers do not freeze to the windshield ⇒  Windshield wip-
er service position.
Indicator light

Windshield wiper lever

Fig. 92 Operating the front windshield wiper.

frozen to the windshield before operating the wipers. Using the
service position can be helpful in cold weather so the wipers do
not freeze to the windshield ⇒  Windshield wiper service posi-
tion.
If the ignition is switched off while the wipers are running, the
wipers will continue at the same wiping speed when the ignition
is switched on again. Frost, ice, snow, leaves, and other objects
on the windshield can damage the wipers and the wiper motor.
Remove snow and ice from the wipers before you begin driv-
ing.
If the wiper blades freeze to the windshield, loosen them care-
fully. Volkswagen recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is
dry because the windshield can be scratched.
The windshield wipers work only if the ignition is switched on and
the engine hood is closed. The windshield wipers turn off automatical-
ly when the engine hood is opened.
The intermittent wiping for the front windshield depends on the
driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them careful-
ly. Volkswagen recommends using a deicing spray.
Windshield wiper functions

Wiper performance in different situations:
During automatic
wipe/wash:
While the washer system is working, the
Climatronic switches to recirculation for
about 30 seconds to help prevent the
washer fluid odor from entering the vehi-
cle interior.
During intermittent
wiping:
Speed-dependent interval control: The
higher the vehicle speed, the faster the
wipers move.

Heated washer nozzles
The heating thaws frozen washer nozzles, but not the fluid supply
hoses. When the ignition is switched on, the heat applied to the
washer nozzles is automatically regulated depending on the outside
air temperature.
Headlight washer system
The headlight washer system cleans the headlight glass.
If the ignition and the headlights (high or low beams) are switched on,
the headlights are cleaned the first time and every fifth time the front
windshield washers are activated. This happens only when the low or
high beams are on when the windshield wiper lever is pulled towards
the steering wheel. However, the headlights must still be washed by
hand periodically (for instance, during refueling) in order to get rid of
hard-to-remove dirt (like insect splatter).
To help make sure that the headlight cleaning system works during
winter weather, always keep the headlight washer nozzles free of
snow and remove any ice with a deicer spray before driving. Use a
deicer spray to remove any ice.
If there is something on the windshield, the wiper will try to wipe it
away. If it continues to block the wiper, the wiper will stop moving.
Remove the obstacle and switch the wiper on again.

Windshield wiper service position

Fig. 93 Windshield wiper in service position.
