WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when an airbag deploys and strikes a passenger in an improper seating position.
Proper seating position

Fig. 39 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 40 Proper safety belt positioning and head restraint adjustment.

For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions:
Applies to all vehicle occupants:
x Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of your head as close as possible to the head restraint ⇒ fig. 39 and ⇒ fig. 40.
x Push the head restraint completely down for short people, even if the top of the head is then below the upper edge of the head restraint.
x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly ⇒  Safety belts.
Driver - seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 39. When adjusting the proper distance to the steering wheel, grasp the top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the airbag is deployed.

Manual controls on the driver and front passenger seats

Fig. 41 Controls on the driver seat.

Fig. 42 Controls on the front passenger seat.

Driver seat:
⇒ fig. 41 Front passenger
seat:⇒ fig. 42
Function Action
(3) Adjust backrest angle. Driver seat: Lean forward and turn the adjuster wheel forward or backward. Front passenger seat: Move the lever in the direction of the arrow and adjust the backrest in the desired angle. The backrest must be securely latched in that position!
(4) Adjust seat height. Move the lever several times up or down.

Electrical controls on the driver and front passenger seats

Fig. 43 Driver seat controls to adjust the seat backward and forward, change seat cushion height and angle, and adjust backrest angle.

Fig. 44 Lumbar support control.

fig. 43 Press the switch in the direction of the arrow:
(A) (1) Slide the seat backward or forward.
(2) and (3) Raise or lower the seat cushion.
(2) or (3) Adjust seat cushion angle.
(B) Forward or backward. Adjust backrest angle.


Press fig. 44 switch for each area:
(1) or (2) Adjust lumbar support. (1) inflates, (2) deflates.
(3) or (4) Adjust lumbar support height. (3) moves the lumbar support up, (4) moves the lumbar support down.

WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsupervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or while calling up the stored memory settings for the front seats. In an emergency, stop automatic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.

Adjusting the rear seat

Fig. 45 Adjusting the rear seat.

Fig. 46 Adjusting the rear backrest.

NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is adjusted in the fore and aft direction.
x If the rear seat is in a forward position, items can get into the area between the seat and the luggage compartment floor. When you slide the rear seat back again, make sure that the area behind the seat is clear of objects.
Adjusting front and rear head restraints

Fig. 47 Adjusting the front head restraints.

Fig. 48 Adjusting or folding the rear head restraints.

Adjusting the height
x Push the head restraint up in the direction of the arrow or down when the button ⇒ fig. 47 (1) or
⇒ fig. 48 (1) is pressed ⇒ .
x The head restraint must lock securely in the position selected.
Folding the outer rear head restraints down
x With the button (2) pressed, fold the head restraint forward and down ⇒ .
x To use the seating area, fold the head restraint back up until it locks in place.
Proper head restraint adjustment
Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher. Position the back of the head as close as possible to the head restraint.
Adjusting the head restraint for short people
Push the head restraint down as far as it will go, even if this means the person's head is still below the top edge of the head restraint. A small gap may remain between the head restraint and the backrest when the head restraint is all the way down.
Adjusting the head restraint for tall people
Pull the head restraint up as far as it will go.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the risk of neck injury in a crash. Each head restraint must be adjusted according to the occupants' size so that the upper edge is even with the top of the person's head, but no lower than eye level. Always sit so that the back of your head is as close as possible to the head restraint.
x Never adjust head restraint while driving.

Removing and reinstalling head restraints

Fig. 49 Removing the front head restraints.

Fig. 50 Removing the rear head restraints.

Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides until it clicks.
x Push the head restraint down while pressing button (1).
x Adjust the head restraint according to the occupant's size ⇒  Adjusting front and rear head restraints.
Removing the rear head restraints
x Unlock the rear bench and fold it forward ⇒ page 145, Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 50 (2) to unlock the head restraint.
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (1) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (1).
x Fold the backrest of the rear bench back so that it locks securely.
Installing the rear head restraints
x Unlock the rear bench and fold it forward ⇒  Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (1).
x Fold the backrest of the rear bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒  Adjusting front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or the back of the front seat. The headliner or other parts of the vehicle could otherwise be damaged.
