VOLKSWAGEN TIGUAN 2010 Owners Manual

window is dry. By switching rear window intermittent wiping off and then back on, you can override this feature and activate the rear window wiper immediately.
The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
Windshield wiper functions

Windshield wiper service position

Fig. 92 Windshield wiper in service position.

Rain sensor

Fig. 93 Windshield wiper lever: Adjusting rain sensor 1.

Fig. 94 Sensitive rain sensor surface.

x Salt streaks: Salt streaks on the windshield from winter driving can cause wiping more often or continuously on glass that is almost dry.
x Dirt: Caked-on dust, wax, any other buildup on the windshield (lotus effect), or car-wash detergent residue can lower the rain sensor's sensitivity and cause it to react too slowly or not at all.
x Crack or chip in the windshield: If a stone hits and chips the windshield while the rain sensor is on, this will trigger a wiper cycle. After that, the rain sensor will recognize the change and recalibrate itself to respond to the smaller detection zone. Depending on the size of the chip, the sensor's reaction pattern may or may not change.
WARNING
The rain sensor cannot always recognize rain and activate the wipers.
x Switch the wipers on manually when water on the windshield reduces visibility.
Clean the rain sensor's sensitive surface ⇒ fig. 94 regularly and check the wiper blades for wear or damage.
To remove wax and coats of polish safely, we recommend using an alcohol-based windshield cleaner.
Checking and refilling windshield washer fluid

Fig. 95 In the engine compartment: Cap of the windshield washer fluid reservoir.

x Refill with clear water (not distilled water) and an appropriate windshield washer fluid that is
recommended by Volkswagen ⇒ . Follow the directions on the container.
x In cold weather, always use a special windshield washer antifreeze solution that will help keep the
water from freezing ⇒ .
Recommended cleaners

x For the warmer months, Windscreen Clear SummerG 052 184 A1 or equivalent. Mixing ratio 1:100 (1 part concentrate to 100 parts water) in the windshield washer reservoir.
x All-season Windscreen ClearG 052 164 A2 or equivalent. the mixing ratio in winter to 0 °F (-18 °C) about 1:2 (1 part concentrate to 2 parts water), otherwise, mixing ratio 1:4 in the windshield washer reservoir.
Filling capacity
The windshield washer fluid reservoir holds about 3.2 qts. (3.0 liters).
WARNING
Never mix antifreeze or similar additives into the windshield washer reservoir. This could produce an oily film on the windshield, which would considerably reduce visibility.
x Use clear water (not distilled water) with a cleaning solution recommended by Volkswagen.
x If necessary, blend with a suitable windshield washer fluid antifreeze agent.
NOTICE
x Never mix cleaning solutions recommended by Volkswagen with other cleaning agents. If you do, this could cause sediments or other by-products that can clog the windshield wiper nozzles.
x When refilling, do not confuse one type of operating liquid with another! Otherwise serious malfunctions and engine damage can occur!

Mirrors

NOTICE
Broken glass in the self-dimming mirrors can cause electrolyte fluid leakage. Liquid electrolyte leaked from a broken mirror glass will damage any plastic surfaces it comes in contact with. Clean up spilled electrolyte fluid immediately with clear water and a sponge.
Inside mirror

Fig. 96 Manually adjustable inside mirror.

Fig. 97 Self-dimming inside mirror.

The self-dimming feature can be switched on and off with the switch on the inside mirror (2). When self-dimming is activated, the indicator light (1) is on.
If the ignition is switched on, the sensor (3) automatically darkens the inside mirror depending on the amount of light shining into the vehicle from the rear.
The self-dimming feature is deactivated when you shift the transmission into Reverse (R) or switch on the interior lights or the reading light.
Do not attach external navigation devices to the windshield or in the vicinity of the self-dimming inside
mirror ⇒ .
WARNING
The illuminated display on an external navigation device can cause the self-dimming inside mirror to malfunction, which can result in crashes and serious injuries.
x Malfunctions in the self-dimming function can result in the rearview mirror being unable to evaluate the exact distance of vehicles in the rear or other objects.
If the light striking the sensor is filtered or blocked (such as by a sunshade), the self-dimming inside mirror will not work properly or may not work at all.
Outside mirrors

Fig. 98 In the driver door: Adjusting knob for outside mirrors.

Turn the rotary knob to the desired position:
2 Adjust the right outside mirror by pressing the knob to left/right and up/down.
 Neutral position. Outside mirror folded out, no heating or adjustment possible.

Synchronous mirror adjustment
x In the Settings - Convenience menu select “Mirror adjust: Both mirrors” for synchronous outside mirror adjustment
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Self-dimming outside mirror on the driver side
The self-dimming outside mirror is controlled together with the self-dimming inside mirror ⇒  Inside mirror.
Memory for front passenger side mirror (when backing up)
x Choose the remote control vehicle key that will be used with the settings about to be made.
x Unlock the vehicle with that remote control vehicle key.
x Set the parking brake.
x Shift the transmission into Neutral (N).
x Switch on the ignition.
x Activate the function Mirror down in the Settings - Convenience menu.
x Shift the transmission into Reverse (R).
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment position is used again.
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into Reverse (R) gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about 10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base when moving the mirrors.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision. But vehicles or other objects seen in a convex mirror will look smaller and farther away than they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
x Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
x Never fold power mirrors in manually because doing so could damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by pressing on the edges of the mirror surface.
