VOLKSWAGEN TIGUAN 2014 1.G Owner's Manual

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal con-venience settings and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Menu structure – overview: Basic version

– Route
– Av. speed
– Digit. speed (digital speed display)
– Speed warn. (speed warning)
▪ Compass (vehicles without navigation system)
▪ Convenience ⇒ Convenience sub-menu
– ATA confirm
– Central locking
Auto unlock
Unlock doors
– Window op. (Window operation)
Off
All
Driver
– Mirror Adj.. (Mirror adjust)
Individually
Both mirrors
Mirror down (vehicles with memory seats)
Back
– Factory Set. (Factory setting).
▪ Lights / Vision
– Coming home
– Leaving home
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
▪ Snow tires (winter tires)
– On
– + 5 mph
– - 5 mph
▪ Units
– Temperature
– Consump./ dist.
▪ Service
– Info
– Back
▪ Tire Monitor⇒ Tire Pressure Monitoring System (TPMS)
▪ Factory setting

Using the instrument cluster menus: Basic version

Fig. 16 Basic version (vehicles without menu control multi-function steering wheel): Control buttons 1 and 2 on the windshield wiper lever.

▪ Push the OK/RESET button to toggle between the 2 figures.
Using the instrument cluster menus: Premium version

Fig. 17 Premium version (vehicles with menu control multi-function steering wheel): Buttons on the right side of the steering wheel.

There are 6 main menus:

Main menus Function See
MFI Multi-Function Indicator (MFI) information.
Audio Station indicator in radio mode. Track display in CD mode. Track display in media mode.
⇒ booklet Radio or
⇒ booklet Navigation
system
Navigation
Information displays on the navigation system: When destination guidance is active, turn arrows and proximity bars are shown. The illustration is similar to the symbol display in the navigation system. If destination guidance is inactive, driving direction (com-pass function) and the current street name are displayed.
⇒ booklet Navigation
system
Phone Information and settings of the mobile phone package. ⇒ booklet Mobile
Phone Package
Vehicle status
Current warning and information messages. This menu item is only displayed when warning or infor-mation messages are available. The number of available messages is shown in the display. Example: 1/1 or 2/2.
Settings Includes the Convenience and Lights & Vision sub-menus, as well as many settings such as time, speed warning for winter tires, language, units and “Display OFF”.

MFI menu (Multi-Function Indicator): Premium version

2 Total trip memory
The memory displays and stores the accumulated driving and fuel consump-tion data of any number of single trips up to a total driving time of 99 hours and 59 minutes, and up to a total distance of 9999 miles (9999 km), depend-ing on the instrument cluster version. If one of the maximum values is ex-ceeded, then the memory is automatically cleared and starts again from 0.

Possible MFI menu displays
The following displays can be accessed in the MFI menu if enabled under Settings > MFI data. Displays that are not enabled will not appear.

Display Function
Travel time Driving time in hours (h) and minutes (min) corresponding to trip mem-ories 1 and 2 (toggle).
Curr. consumption --- mpg
Current fuel consumption in miles per gallon (l/100 km) while driving. When units are set to miles, dashes appear instead of a number when the engine is running and the vehicle is standing still. When units are set to kilometers, the display shows liters consumed per hour when the engine is running and the vehicle is standing still.
Av. consumption ø --- mpg
Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1 and 2 (toggle) is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds.
Range Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the current fuel consumption, among other things.
Route Distance driven in miles (km) per trip memories 1 and 2 (toggle).
Av. speed ø
Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been once the vehicle has been driven about 300 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds.
Digit. speed Digital display of current vehicle speed.
Speed warn. --- mph (km/h)
When the set speed (from 20 to 155 mph - 30 to 250 km/h) is exceed-ed, an acoustic warning sounds, and a visual message may also ap-pear in the instrument cluster display.

Switching between the displays
x Use the arrow up and down buttons (* and +) on the multi-function steering wheel.
Storing speed for the speed warning
x Navigate to MFI > Speed warning (Speed warning at --- mph).
x Press the OK button to save the current speed and to activate the warning.

x If the speed is not right, press buttons * or + on the multi-function steering wheel to set a differ-ent speed within about 5 seconds. Then press the OK button a second time or just wait a few se-conds. The speed is saved and the warning is activated.
x To deactivate, toggle to --- mph and press the OK button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Navigate to MFI > Route.
x Select the memory to be erased.
x Press the OK button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data (Settings > MFI data) to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed
can also be changed ⇒ Settings menu.
Settings menu

Settings menu Function
Factory settings Resets the functions in the Settings menu to the default factory settings.
Back The display returns to the main menu.

Convenience sub-menu

Convenience menu Function
Mirror adjust The setting Both mirrors adjusts the passenger-side outside mirror as well when the driver-side outside mirror is repositioned. This feature is not factory enabled and must be activated in the Convenience sub-menu.
Factory setting Resets certain features in the Convenience sub-menu to the factory settings.
Back The display switches back to the Settings menu.

Lights and Vision sub-menu

Driving checklists and warnings
