Fig. 205 Bulb holder with backup light bulb 2.

Replacing light bulbs in the vehicle body

Fig. 206 In the side of the luggage compartment: Releasing the tail light, removing the trim panel and removing the screws.

Fig. 207 Removed tail light: Removing the bulb holder and replacing the tail light and brake light bulb 3 or turn signal bulb 4.

6. Remove the screws (3) C.
7. Pull the tail light out of the body carefully until the electrical connector is visible.
8. Remove the red locking mechanism ⇒ fig. 207 (1) D as illustrated and disconnect the electrical connector with the lever (2) D pressed down.
9. Lay the tail light on a clean and level surface.

Replacing light bulbs

10. Remove the screws (4) E.
11. Remove the bulb holder (3) E from the tail light.
12. Replace burned out tail light, brake light (5) F or turn signal bulbs (6) F with bulbs that are identical to the ones being replaced.
13. Insert the bulb holder in the tail light and screw it in E.

Installing the tail lights

14. Turn the locking mechanism ⇒ fig. 206 (1) A 90 ° clockwise until it stops.
15. Insert the electrical connector into the bulb holder until it clicks into place. Press the red
locking mechanism ⇒ fig. 207 (1) D back in.
16. Insert the tail light into the opening on the body carefully.
17. Hold the tail light in the correct position with one hand and tighten the screws with the other hand (3) C.
18. Insert the trim panel ⇒ fig. 206 (2) B into its original position, first at the bottom and then at the top.
19. Close the side storage compartment in the luggage compartment.
20. Close the rear hatch

LEDs in the rear taillights
Changing LEDs is not possible without dismantling vehicle components. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Taillights with LEDs may also have some “standard” light bulbs. These bulbs can be replaced.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.

Replacing license plate light bulbs

Fig. 208 In the rear hatch: Clamped license plate lamp.

Fig. 209 In the rear hatch: Screwed license plate lamp.

Please carry out each step only in the order specified:
Clamped license plate lamp Screwed license plate lamp
5. Carefully insert the license plate lamp into the opening in the bumper. Ensure that the license plate lamp is installed in the correct direction.
Carefully insert the license plate lamp into the opening in the bumper. Make sure that the adhesive anti-glare strip faces forward.
6. Press the license plate lamp into the bumper until it audibly latches. Tighten the securing screws of the license plate lamp with the screwdriver.

Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Replacing the light bulb in the backup lamp

Jump-starting

WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety
precautions before working on the batteries or the electrical system ⇒ 12 Volt vehicle battery.
x Always make sure that the battery providing starting assistance (the booster battery) has the same voltage as the dead battery (12 V) and about the same amperage capacity (see battery label).
x Never jump-start a vehicle with a thawed or frozen vehicle battery. The battery can explode. A dead battery can freeze at temperatures around +32 °F (0 °C).
x A battery that is frozen or was frozen, but has since thawed, must be replaced.
x When the vehicle battery is jump started, it gives off hydrogen gas, which is highly explosive! Always keep fire, sparks, open flame, and smoking materials far away from vehicle batteries. Never use a mobile telephone while connecting or disconnecting jumper cables.
x Jump-start batteries only in well-ventilated areas. Batteries give off highly explosive hydrogen gas during jump-starting.
x Always route the jumper cables so that they cannot get caught in any moving parts in the engine compartment.
x Never short out the battery terminals by connecting the positive terminal (+) and negative (-) terminals with each other.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery, as this may cause the hydrogen gas given off by the dead battery to explode.
x Never attach the negative cable from the vehicle providing starting assistance to any part of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Always follow the instructions of the jumper cable manufacturer.
NOTICE
To help prevent extensive damage to the vehicle electrical system, read and heed the following:
x Connecting jumper cables improperly can cause a short circuit and do expensive damage to the vehicle's electrical system.
x Do not let the vehicles touch each other while the jumper cables are connected. If they do, electrical current may flow between the vehicles when the positive (+) terminals are connected, causing electrical system damage.

Using jumper cables

Fig. 210 Diagram for attaching the jumper cables: Dead battery 1 and booster battery 2.

x Turn the ignition of the vehicle with the dead battery. If the engine starts, wait 2 to 3 minutes until it
“runs smoothly” before removing the jumper cables as described below ⇒ . If the engine does not start within about 10 seconds, turn off the ignition and wait at least one minute; then try again.

Before removing the jumper cables
1. Switch off the headlights (if they are on).
2. In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected.
Removing jumper cables
With the engine running, remove the jumper cables in reverse order to the way they were connected.
1. Disconnect the black (-) cable from the vehicle with the dead battery.
2. Disconnect the black (–) cable from the other vehicle (vehicle with the good battery).
3. Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
4. Disconnect the red (+) cable from the vehicle with the dead battery.
5. Close the battery cover as the case may be.

WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety
precautions before working on the batteries or the electrical system ⇒ 12 Volt vehicle battery.
x Always wear proper eye protection. Never lean over the vehicle batteries.
x Attach the jumper cables in the correct order: first the positive cable, then the negative cable.
x Never connect the negative cable from the vehicle providing starting assistance to parts of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Check the battery acid level indicator window on the vehicle battery. Use a flashlight, never a match, cigarette lighter, or other open flame. If you cannot see the color of the window clearly, or if it is light yellow or colorless, do not jump-start the vehicle. Get expert assistance.
x Avoid electrostatic discharge in the vicinity of the vehicle battery. Sparks may cause the hydrogen gas escaping from the vehicle battery to ignite.
x Never jump-start a vehicle with a battery that is damaged or frozen or that was frozen and has thawed. The battery can explode. Replace the battery instead.
x Always follow the instructions of the jumper cable manufacturer.
x Always make sure that the battery providing starting assistance has the same voltage as the dead battery (12 V) and about the same capacity (see battery label).
x Batteries give off explosive hydrogen gas. Always keep fire, sparks, open flame and smoking materials away from batteries.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery. The hydrogen gas from the battery is explosive.
x Never short out the battery terminals by connecting the positive (+) and negative (–) terminals with each other.
