VOLKSWAGEN TOUAREG 2010 Owners Manual

Data media Conditions for playback
Audio files Video files
I Audio CDs (up to
80 min).
I Standard video DVD
and DVD-compatible DVD
audio.
I CD-ROM-, CD-R-, CD-
RW audio data CD up to
max. 700 MB (Megabyte)
in the data system ISO
9660 Level 1 and 2, Joliet
or UDF 1.02, 1.5, 2.01,
2.5.
I DVD+/-R/RW up to 4.7
GB and dual layer DVDs
up to 8.5 GB in the Joliet
file system (single-session
only); UDF.

The data medium configuration or the devices or programs used for recording can cause individual tracks or data medium to be unreadable. Information can be found on the Internet on the best ways to create audio files, video files and data media (compression rate, ID3 tag etc.).
Due to the larger quantity of data, it takes longer to read a data medium containing compressed audio files (such as MP3, WMA) than a “normal” audio CD. Complex directory structures can also the delay the reading process. If possible, only use data media with readable audio and video files.
Play lists only define a certain playback sequence. Play lists do not save any files. Play lists cannot be played if the files on the data medium are not saved in the location to which the play list is referring (relative data path). Play lists cannot be copied to the media center (HDD).
NOTICE
Do not use memory card adapters.
No liability can be accepted for damaged or lost files on the data media.
Inserting or removing data media

Fig. 150 Data media slots in glove compartment.

Inserting or removing memory cards
If a memory card cannot be inserted, check the insert position and memory card.
x Insert a compatible memory card into one of the memory card slots (2) with the cutoff corner first and facing right until the card clicks into place.
x To remove, briefly press the inserted memory card. The memory card “pops” into the eject position and can be removed.
No files can be copied onto the memory card in the unit.
Data media or files cannot be read
A message will be shown if a data medium cannot be read. The data medium needs to be removed manually.
Only supported files can be displayed and played via the Audio menu. Other files are ignored.
When you browse a media source, folders containing non-supported files are also displayed, but they appear empty once opened.
Navigation data (VCards etc.) can only be read via the Directory menu
WARNING
Inserting data media when the vehicle is moving can distract you from the road and lead to accidents. Always keep the storage compartment closed when the vehicle is moving.
NOTICE
The memory card slot's locking mechanism and the memory card can be damaged by incorrect insertion of a memory card or by inserting a incompatible memory card!
x When inserting a card, make sure it is correctly positioned.
x Excessive pressure can destroy the locking mechanism in the memory card slot.
x Only use suitable memory cards
If you insert a number of different CDs and DVDs and receive the message Drive error every time, contact a qualified workshop.
Open MEDIA main menu

Fig. 151 MEDIA main menu: Audio menu.

Fig. 152 MEDIA main menu: Video DVD menu.

Response Effect
Briefly press the button M
once.
Switch tracks or chapters at the start of
the current track or chapter.
Briefly press the button M
twice.
Switch tracks or chapters at the start of
the previous track or chapter.
Briefly press the button L
once.
Switch to next track or chapter.
Press M and hold. Fast search backward.
Press L and hold. Fast search forward.
Briefly press the button N once. Playback stops. The button N changes
to b.
OR: Briefly press the button b
once.
Playback is resumed. The button b
changes to N.

Media mode (audio):

Files B on data media are often organized by means of folders  and play lists t to determine a certain playing order.
Files, folders and playlists on a data medium are sorted by name in alphanumerical order.
The illustration shows a typical audio data CD that contains tracks B, folders A and sub folders
⇒ fig. 154.
The tracks are played back as follows:
1. Tracks (1) and (2) in the CD's root directory
2. Track (3) and (4) in the first directory F1 in the root directory of the CD
3. Track (5) in the first subdirectory F1.1 of the directory F1
4. Track (6) in the first subdirectory F1.1.1 of the subdirectory F1.1
5. Track (7) in the second subdirectory F1.2 of the directory F1
6. Track (8) and (9) in the second directory F2
Play lists t are treated like directories in the playback sequence.
WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System, when using your mobile phone, or when operating the mobile phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your mobile phone, and the mobile phone controls only if road, traffic, and weather conditions permit and you will not be distracted from your driving.
x If you cannot use the Infotainment System, your mobile phone, or the mobile phone con-trols safely while driving, wait until later or find a safe spot where you can pull off the road and park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other warning sounds outside the vehicle.
Compressed video files (Podcasts, AVI) on a data medium are treated like audio files when played back.
Play lists are not automatically played, they must be specifically selected via the menu for track selection.
Playback of video files in the Audio menu

Track display in Audio menu

Fig. 155 MEDIA main menu: Audio menu.

Browsing audio and media sources

Fig. 156 Track list of a playing audio CD.

Fig. 157 Track list of a playing audio data CD.
