VOLKSWAGEN TOUAREG 2012 Owners Manual

Function key: Effect
= Voice guidance during phone call : Spoken navigation recommendations
are also given during a telephone call.

Advanced navigation settings: Demo mode and manual location
x In the Advanced navigation settings menu, check the check box in the Demo mode function key by pressing it = to start virtual route guidance to the entered destination.
x Press the Enter current position manually function key to select a manual location in the same way you entered a destination
If demo mode is enabled an additional pop-up window opens when you start route guidance.
x Pressing the Demo mode function key starts a “virtual route guidance” to the destination you have entered.
x If you press the Normal mode function key, a “real route guidance” starts.
The sequence of events and the operations in virtual route guidance are similar to those in real route guidance. Once a manual location has been entered, the virtual route guidance starts from that position.
Virtual route guidance is repeated when you reach the fictitious destination and always starts again from the starting point if it is interrupted.
When real route guidance is started following route guidance in demo mode, the unit first has to reori-ent itself. Depending on the number of currently received satellites, this orientation may take some time. Vehicle movement can reduce the re-orientation time.
If the vehicle is moved and the unit can determine its current location by GPS, any manually entered location will be overwritten with the current vehicle location.
Disable demo mode after use, otherwise you will be prompted to choose between virtual and normal route guidance each time you start route guidance.

MAP (map display)

Fig. 224 3D map display moved with vehicle position.

Browsing and centering map

Fig. 225 3D map view (map section moved).

Autozoom
If Autozoom is active, the map scale is adjusted automatically, depending on the route (small scale for driving on the highway and a large scale for driving in town).
x Press the

2D: Setting orientation of map
x Press the

Favorite destinations on the map
A favorite category can be specified for stored destinations. Favorite destinations can be displayed on the map with the orange favorite icon assigned to them (private T or business P).
The list of favorite destinations is called up from the Destination entry menu.
Points of interest on the map
Points of interest can be selected as a navigation destination.
Points of interest are divided into point of interest categories. These point of interest categories are assigned to blue point of interest icons (such as * hotel and , petrol station). A list of available point of interest categories can be called up from the Map settings menu. Map icons can be selected there for display.
Display detailed information on points of interest
x Press the symbol on the map briefly to display a window with further information.
Due to the map scale, there may be several entries behind one symbol on the map, in which case a list appears for selecting an entry.
x Select the required entry by pressing.
Function keys for further operation are displayed in the information window that appears.
x Selecting points of interest and favorite destinations from the map
x TMC traffic reports on the map
3D models on the map
An abstract 3D city model can be displayed in the 6 3D display type for some cities (such as Berlin).
In addition, special historical buildings and sights of interest are displayed as photo-realistic 3D mod-els.
To display these, autozoom needs to be switched off in some cases and you have to zoom further into the map
The display of 3D city models and 3D sights of interest is enabled and disabled in the map settings
If no symbols or 3D models can be displayed due to the scale, turn the setting knob clockwise
⇒ fig. 131 (3) in order to zoom in on the map.
Map settings: selecting map symbols

Function key: effect on map
= Traffic information : TMC traffic reports are displayed as icons
= 3D landmarks : Photo-realistic 3D models of special historical buildings
and landmarks are displayed17.
= 3D city model : Buildings in cities are displayed as abstract 3D models17.
= P Important destinations (business) : Shows favorite destinations from
the “business” category that were selected upon saving with P
= T Important destinations (private) : Shows favorite destinations from the
“private” category that were selected upon saving with T
= > ... : Activated point of interest categories are displayed.

17 Only available for some cities.

Introduction
Before using

Before using the cellular telephone (mobile phone) control for the
first time, carry out the following steps. This will enable you to use
the mobile phone control safely and make full use of the functions it
provides:
d Follow the basic safety instructions

WARNING
The volume may suddenly get louder change when you switch media source or connect a new audio source.
x Always lower the volume before switching media source or connecting a new audio source.
WARNING
A mobile phone on the seat, instrument panel or in other places can be thrown around the inside of the vehicle during a sudden braking maneuver, a crash or other accident and injure vehicle occupants.
x Never attach a mobile phone to, or place it on, a door, the windshield, or above or near the areas marked “AIRBAG” on the steering wheel, the instrument panel, and the seat backrests, or between these areas and the vehicle occupants. The mobile phone could cause serious injury in an accident, especially when the airbags inflate.
WARNING
Always switch off the mobile phone when refueling and in areas with a risk of explosion. The electromagnetic radiation can cause sparks that can ignite fuel vapors and cause a fire.
x The mobile phone can automatically log itself into the mobile phone network again when the Bluetooth® connection to the telephone control is interrupted.
WARNING
If a mobile phone not connected to an external aerial is used in the vehicle, electromagnetic radiation in the interior could exceed limit values. This also applies if the outside antenna is not installed properly.
x Heart specialists advise that mobile phones can adversely affect the way pacemakers work. Always keep the mobile phone and its integrated antenna at least 8 inches (20 cm) away from a pacemaker.
x Never carry a mobile phone that is switched on in the breast pocket directly over a pace-maker.
x If you suspect there may be interference with a pacemaker or other medical device, switch the mobile phone off immediately.
NOTICE
x Your mobile phone and the telephone control must always be switched off in areas where special regulations apply and when the use of mobile phones is forbidden. Radiation from a switched-on mobile phone can interfere with sensitive technical and medical devices, poten-tially causing malfunctions or damage to the devices.
x High speeds, poor weather and road conditions as well as the network quality may impair telephone calls in the vehicle and lead to loss of connection.
