Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Side window with window diversity antenna for:
– Radio
– Central locking
(3) Roof rack
(4) Outside door handles
(5) Outside mirror:
– Additional turn signal light
– Area view
(6) Lift points for the jack
(7) Trailer hitch/ball mount receiver

– Mute switching for radio or activation of voice control (if applicable) \f
– Display Phone main menu or accept telephone calls -
– Audio, Navigation

Upper center console

Fig. 7 Overview of upper center console.
Key to fig. 7:
(1) Air vent for indirect ventilation
(3) Air vents z
(2) Storage compartment
(4) Radio or Radio & Navigation system (factory installed)
(5) Controls for:
– Climatronic
– Seat heating switch button A
(6) Located here:
– Switch for emergency flashers
– PASSENGER AIR BAG /&&  light (front airbag for front seat passenger)
– Park Distance Control system button  or ∗
– Rear View camera ∗
– Heated steering wheel \b

â–ª Hybrid
â–ª Tire pressure
â–ª Display since start
â–ª Display since refuel
â–ª Display long-term
â–ª Digital speed (digital speed display).
Navigation
Audio
â–ª Source list
– DAB
– FM
– AM
– Radio memory
– HDD
– SD
– DVD
– USB
– Bluetooth
– TV tuner
– TV station memory
– External AV source
Telephone
â–ª Directory
â–ª Dialed numbers
â–ª Missed calls
â–ª Received calls
Using the instrument cluster menus

Fig. 17 Right side of the multi-function steering wheel: Controls for the menus in the instrument cluster.

NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage, moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-ters near the vehicle that use the same frequency range (such as radio equipment or mobile phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak battery can reduce the operating range.
If the remote control vehicle key buttons ⇒ fig. 20 or the power locking buttons ⇒ fig. 27 are pushed repeatedly in quick succession, the power locking system is switched off for a brief period to help keep it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 21 Releasing the emergency key and removing it from the remote control vehicle key.

Fig. 22 Releasing the emergency key and removing it from a remote control vehicle key with a panic button.

Accessory weight
The combined weight (in excess of those standard items which may be replaced) of automatic trans-mission, electro-mechanical power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment (whether installed or not).
Aspect ratio
The ratio of sidewall height to tire width, expressed as a percentage. A number of 70 (0.7:1 or 70%) or lower indicates a low-profile tire with a shorter sidewall for improved steering response and better overall handling on dry pavement.
Bead
The part of a tire made of steel wires, wrapped or reinforced by ply cords, with the shape and structure to ensure proper fit to the wheel rim.
Bead separation
A breakdown of the bond between components in the bead.
Carcass
The tire structure, except tread and sidewall rubber which, when inflated, bears the load.
Chunking
The breaking away of pieces of the tread or sidewall.
Cord
The strands of material forming the plies in the tire.
Cord separation
The parting of cords from adjacent rubber compounds.
Cracking
Any parting within the tread, sidewall, or inner liner of the tire extending to cord material.
Cold tire inflation pressure
The tire pressure recommended by the vehicle manufacturer for a tire of a specified size that has not been driven for more than a couple of miles (kilometers) at low speeds in the 3 hour period before the tire pressure is measured or adjusted.
Curb weight
The weight of a motor vehicle with standard equipment including the maximum capacity of fuel, oil, and coolant, air conditioner, and additional weight of optional equipment.
Extra load tire
A tire designed to operate at higher loads and at higher inflation pressures than the corresponding standard tire.
Gross Axle Weight Rating (GAWR)
The load-carrying capacity of a single axle system, measured where the tire contacts the ground.
Gross Vehicle Weight Rating (GVWR)
The maximum loaded weight of the vehicle.
Groove
The space between 2 adjacent tread ribs.

Flashes Display
text
Possible cause or
meaning ⇒ 
Proper response
(Intermittently
while driv-
ing.)
cation problem be-
tween a sensor and
the system. This
may be caused by
interference from a
nearby radio trans-
mitter (such as a
mobile phone or
other broadcast de-
vice) that uses the
same frequency
range. The indicator
light should stop
flashing as soon as
you are far enough
away from the de-
vice causing the
interference.
terference off.

x In the storage compartment in the lower front center console.
Opening and closing the cover in the rear center console
x Reach into the recess from below ⇒ fig. 128; fold the cover up in the direction of the arrow and hold it open.
x The cover is spring-loaded and closes when you let it go.
Opening and closing the 12 Volt socket covers in the front center armrest storage compartment, luggage compartment, lower front center console
x Grasp the cover on the side ⇒ fig. 129 and open it in the direction of the arrow; hold it open.
x The cover is spring-loaded and closes when you let it go.
NOTICE
x Follow the manufacturer's instructions for connected devices!
x Never exceed the maximum power consumption, or the entire vehicle electrical system may become damaged.
x 12 Volt socket:
– Only use equipment that has been tested for electromagnetic compatibility and complies with applicable guidelines.
– Never feed current into the socket with a solar panel, for example.
Unshielded devices may interfere with radio reception or the vehicle's electrical system.
115 Volt outlet in the vehicle

Fig. 130 Rear center console: Open cover for access to the 115 Volt outlet (if equipped).

NOTICE
x Follow the manufacturer's instructions for connected devices!
x Never exceed the maximum power consumption, or the entire vehicle electrical system may become damaged.
x 115 Volt outlet:
– Do not connect devices or plugs which are too heavy, such as a grid power supply adapter or cord, directly onto the outlet.
– Do not connect lamps containing fluorescent tubes.
– Only connect devices to the outlet with voltage consistent with the voltage of the outlet.
– For devices with a high starting current, the integrated over-current shutoff will prevent them from being switched on. In this case, disconnect the power supply from the device and reconnect after about 10 seconds.
Some devices may not work very well when connected to the 115 Volt outlet due to low wattage.
Unshielded devices may interfere with radio reception or the vehicle's electrical system.

Browsing lists

Fig. 134 List for selecting audio files for import.

Fig. 135 Station list in radio mode.
