VOLKSWAGEN TOUAREG 2014 2.G Owners Manual

Function key: Effect
Inbox : Displays received SMS.
Templates : Selection of available templates for sending SMS.
Extras : Opens a pop-up window with the following options:
Display off : Switches off the display. Press one of the Infotainment buttons or the screen to switch on again.
Conference details29: Opens a list of the parties in a current conference call
Mute : Switches the microphone off during a telephone call, so that the person on the line cannot hear what is being said in the vehicle.
]: Opens the telephone directory of the paired mobile phone to select a telephone number
Entering a telephone number and taking a call

Fig. 234 Entering a telephone number.

Answering a call
An incoming telephone call is indicated in the top line of the screen by “Incoming call” and the caller's telephone number.
If the caller's telephone number is stored in the telephone directory, the caller's name is displayed
x Press the  function key to answer the call.
x Press the ^ function key to reject the call.

Stored telephone numbers

Fig. 236 Displaying a telephone directory entry.

The entries in the telephone directory of the mobile phone cannot be changed permanently via the telephone control. A telephone number stored in the telephone directory on the mobile phone can only be modified for calls from the vehicle. You can add a country code, for example
The telephone directory entries can be called up in the Navigation system via the Directory menu
Searching for an entry in the telephone directory

Fig. 237 Telephone directory.

Fig. 238 Search window for selecting a telephone directory entry.

If no name is suggested as you enter text, there is no telephone directory entry matching the sequence of characters you have entered. Using the  function key, delete characters in the input line until a name is suggested again. Please take the sorting order into consideration
Selecting displayed entry
Press the # function key to open the menu showing the search results that are still available .
Using voice operation, you can also record the name stored in the telephone directory after the corresponding voice command
Displaying and editing telephone number

Fig. 239 Editing a telephone number.

You can save telephone numbers in the telephone control from calls that have been missed, dialed or received in the vehicle. Depending on the mobile phone model, call lists stored on the mobile phone could also be displayed.
x In the PHONE main menu, press the Call lists function key.
x Open a call list by pressing it in the pop-up window.

Function key: Effect
Missed calls : Missed calls.
Dialed Numbers : Dialed telephone numbers.
Received calls : Received calls.

Incoming calls rejected with the ^ function key are stored in the call list of received calls.33
If a telephone number is stored in the telephone directory, the stored name is displayed instead of the telephone number.
x Press a telephone number or a name on the screen to dial it.
x Press the H function key to edit the telephone number or use it further.
Call lists are always specific to a user profile
Storing telephone numbers to speed dial buttons

Fig. 240 Speed dial settings menu: Assignment of speed dial buttons.
33 Depending on the mobile phone.

Fig. 241 Telephone control main menu: Newly assigned speed dial button.

Functions during a telephone call

When a connection is made to a dialed telephone number, the PHONE main menu changes to the
telephone call view ⇒ fig. 242.
Holding a call34
x Press the 5 function key to “mute” the current telephone call (display: Call being held).
x Press the  function key to resume the call.
While a call is being held, no sound is transmitted. Conversations in the vehicle cannot be heard by the other party.
Ending a telephone call
x Press the ^ function key to end the current call.
The PHONE main menu is displayed again ⇒ fig. 241.
DTMF tones
Every telephone button has a specific DTMF tone assigned to it. DTMF tones are used, for example, to send a password or to select an employee in a call center or to access the voice mail.
x If you are asked to enter a sequence of characters during a telephone call, open the keypad by
pressing the o function key and enter the characters ⇒ fig. 243.
Making an additional call, “toggling calls” and “call waiting”

Fig. 244 Telephone call with call on hold.
