VOLKSWAGEN TOUAREG 2014 2.G Owners Manual

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Climatronic controls

Fig. 283 In the front center console: Climatronic controls.

Button/Knob More information. Front Climatronic controls .
) Air distribution to the windshield, the upper body, and the footwells. Push the button repeatedly until you get the setting you want; the selected setting is shown in the front Climatronic display.
2%34 Residual heat mode
!54/ Automatic temperature, fan, and air distribution control.
/&& Switch off: Press OFF button or adjust manually to 0. This switches Climatronic off entirely. /&& lights up in the front Climatronic display.
WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions and serious personal injury.
x Never switch off the fan for a long time and never use air recirculation a long period of time because no fresh air will enter the passenger compartment.
Operation via the Infotainment System

Fig. 284 Infotainment System: Front climate control settings.

Function key More information. Front Climatronic controls ⇒ fig. 284.
u Air distribution to the windshield and footwells.
 Heated steering wheel: The steering wheel is heated to about +77 °F (+25 °C) and held constant at about this temperature.
AUTO Automatic temperature, fan, and air distribution control. By tapping the function key repeatedly, you can select from the air conditioning profiles Low, Medium, and High in AUTO mode.
Fan switch Manual fan speed adjustment. Setting 0: fan and Climatronic switched off.

x Press the SETUP Infotainment button.
x Press the System feature key.
x Press the Units feature key.
x Select the desired unit.
Automatic window fog detection
Automatic window fog detection checks whether the windows are fogged up and if necessary automatically adjusts the air flow to the windshield and side windows or switches on the windshield heating. If the fan or the air conditioner !

The air coming out the vents and flow through the passenger compartment and out through the vents below the rear window. Do not cover these slots with clothing or other objects.
Air vents

Fig. 285 Air vents in the instrument panel.

Automatic air recirculation.
The air recirculation mode helps prevent outside air from entering the vehicle interior.
In very hot or cold outside temperatures, temporarily switch to manual air recirculation in order to cool or heat the vehicle interior faster.
For safety reasons, air recirculation is switched off if you push the  button ⇒ .
Switching air recirculation on and off manually
Switching on: Press the 3 button repeatedly until the indicator light in the button comes on.
Switching off: Press the 3 button repeatedly until the indicator light in the button goes out.
Switching air recirculation on and off automatically
x Press the CLIMATE Infotainment button.
x Tap the Extras function key.
x Switch automatic air recirculation on or off by tapping the Automatic air recirculation function key.
If the check box in the function key is checked =, automatic air recirculation is switched on.
What automatic air recirculation does
In automatic air recirculation mode, fresh air will enter the passenger compartment. If the system detects an increased concentration of pollutants in the outside air, it automatically switches to air recirculation. As soon as the pollutant level is back in the normal range, air recirculation is switched off.
Unpleasant odors cannot be detected by the system.
To keep the windows from fogging up, automatic air recirculation is not switched on automatically in certain circumstances.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, collisions and serious personal injury.
x Never use air recirculation mode over an extended period of time, since no fresh air will enter the passenger compartment.
x When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
When backing up and while the automatic wiper/washer is operating, air recirculation is briefly activated to avoid unpleasant odors in the passenger compartment. This feature only works if
automatic air recirculation is enabled ⇒ Switching air recirculation on and off automatically.

Refueling

WARNING
x Even if empty, portable fuel containers can leak and cause a fire and serious personal injuries, especially in a crash.
x If, under exceptional circumstances, you must transport a portable fuel container, please observe the following:
For your safety, we strongly recommend that you do not travel with a portable fuel container in your vehicle.
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for example, in the luggage compartment or on the rear hatch). Static electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact with the container. This will help prevent static electricity from discharging and causing a fire.
– Always observe local and state or provincial laws about the use, storage, and transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI/ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires, and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel when your vehicle has a gasoline engine can cause very serious and expensive engine and fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance. These fuels contain substances that can severely damage the fuel system and the engine if the engine is started.
x Vehicles with diesel engines must never be refueled or driven with gasoline, kerosene, heating oil, or other non-specified fuels that have not been expressly approved for use with the diesel engine. Other kinds of fuel will cause serious damage to the fuel system and the engine that is not covered by any Volkswagen Limited Warranty.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly, following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance if necessary.

Indicator lights and fuel gauge

Fig. 286 In the instrument cluster: Fuel gauge for gasoline and diesel fuel.

WARNING
Driving with a fuel tank that is almost empty can lead to stalling in traffic, a collision, and serious personal injuries.
x When the fuel tank is almost empty, fuel supply to the engine can be interrupted, especially when driving up an down hills. The interruption in fuel flow could stall the engine during a maneuver in difficult terrain and make you lose control of the vehicle.
x Steering and braking assistance as well as ESC and related systems will not work if the engine “sputters” or stalls due to lack of fuel.
x Always refuel when the tank is 1/4 full to reduce the risk of running out of fuel and stalling in traffic.
NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x Never drive until the fuel tank is completely empty. The irregular fuel supply can cause the engine to misfire. This allows unburned fuel to get into the exhaust system and damage the catalytic converter or the diesel particulate filter.
The small arrow next to the gas pump symbol in the fuel gauge shows the side of the vehicle with the fuel filler flap.
Refueling

Fig. 287 In the right rear fender: Opening fuel filler flap.

Fig. 288 Fuel cap placed on the open fuel filler flap.
