VOLKSWAGEN TOUAREG 2014 2.G Repair Manual

The sunshade opens automatically when the power sunroof opens if the shade was previously completely closed or in front of the glass roof. The sunshade remains in the previous position and does not close automatically with the sunroof. The sunshade cannot be closed completely until the power sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special knowledge and tools are required to close the power sunroof if it will not close on its own. To help prevent damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility help you close and repair the power sunroof.
The comfort position provides sufficient ventilation without loud wind noise.
Applicable only in Canada
Opening or closing the power sunroof

Fig. 35 In the headliner: Rotary switch for the power sunroof. A: Turn the rotary switch to slide the sunroof open or closed. B: Press or pull the switch to tilt open or to close.

Function Switch positionAction
To tilt open the tilting roof fully: (4) Push the rear part of the switch briefly.
To stop the one-touch feature: (4) or (5) Push or pull switch again briefly.
To set an intermediate position: (4) to (5) Pull or push the rear part of the switch briefly until the desired position is reached.
To close fully: (5) Pull the rear part of the switch briefly.
You must switch on the ignition to operate the power sunroof. After switching off the ignition, you can still open or close the power sunroof for several minutes as long as the driver or front passenger door has not been opened.
All procedures are interrupted as soon as the rotary switch is operated.
The sunshade opens automatically when the power sunroof opens if the shade was previously completely closed or in front of the glass roof. The sunshade remains in the previous position and does not close automatically with the sunroof. The sunshade cannot be closed completely until the power sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special knowledge and tools are required to close the power sunroof if it will not close on its own. To help prevent damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility help you close and repair the power sunroof.
The comfort position (2) provides sufficient ventilation without loud wind noise.
Applicable only in the United States
Opening or closing the sunshade

Fig. 36 In the headliner: Buttons for sunshade.

Function Response
To open fully (one-touch feature): Briefly press the ⇒ fig. 36 (1) button.
To stop the one-touch feature: Briefly press the (1) button or the (2) button.
To set an intermediate position: Keep the (1) button or (2) button pressed until the position has been reached.
To close fully (one-touch feature): Briefly press the (2) button.
You can still use the sunshade for several minutes after the ignition is switched off as long as the driver or passenger door has not been opened.
When the power sunroof is completely open the sunshade is automatically moved to a ventilation position.
When the power sunroof is in the tilt position the sunshade will also open a small gap.
When the power sunroof is open, the electrical sunshade can only be closed up to the front edge of the glass roof.
Power sunroof – convenience closing feature

x Try to close the power sunroof or the sunshade again.
x If the power sunroof or the sunshade still cannot close, the sunroof or sunshade will stop where the resistance is located. The power sunroof or the sunshade will close the next time without pinch protection.
Opening and closing the power sunroof without pinch protection
x The switch ⇒ fig. 34, ⇒ fig. 35 must be rotated to the “Closed” position (1) A.
x Power sunroof: Within 5 seconds after the pinch protection was triggered, pull the rear part of the
switch ⇒ fig. 34 (5), ⇒ fig. 35 (5) B until the sunroof is fully closed.
x Sunshade: Within 5 seconds after the pinch protection was triggered, press the ⇒ fig. 36 (2),
⇒ fig. 37 (2) switch until the sunshade is fully closed.
x The power sunroof or sunshade will now close without pinch protection!
x If the power sunroof still will not close, please see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
If you let go of the switch while the roof is closing, the power sunroof opens automatically.
WARNING
Without pinch protection, the power sunroof and sunshade will close with enough force to cause serious personal injury.
x Always be careful when closing the power sunroof.
x Always make sure that no one is in the way when overriding the pinch protection to close the power sunroof or the sunshade!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the edge of the roof; injuries may result.
Pinch protection is also active during convenience closing of the windows and the power sunroof
⇒ Convenience closing.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Applicable only in the United States
Initializing the power sunroof

Fig. 38 In the headliner: Sunroof rotary switch.

WARNING
Closing the sunroof without pinch protection can cause severe injuries.
x Always be careful when closing the sunroof.
x Always make sure that no one is in the way when overriding pinch protection to close the sunroof.
x Pinch protection does not prevent fingers or other body parts from being pressed against the roof frame, thereby causing injury.
If the sunroof malfunctions or pinch protection does not operate properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

HomeLink® Universal Transmitter

WARNING
Improper use of the HomeLink Universal Transmitter can cause serious or even fatal personal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink Universal Transmitter, you may be operating a garage door or estate gate. Always make sure that people and objects are out of the way to help prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will need to stand on a ladder or step stool. Always take extra precautions to prevent falls and serious injury.
x Never use the HomeLink Universal Transmitter with any garage door opener that does not have the safety stop-and-reverse feature, as required by federal safety standards. This includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer when using the remote controlled garage door opener or electrical drive.
Programming the HomeLink® Universal Transmitter

Fig. 40 Roof keypad: Buttons for the HomeLink Universal Transmitter.

Fig. 41 Infotainment System: HomeLink Universal Transmitter menu.

The buttons 1 , 2 , and 3 on the roof keypad ⇒ fig. 40 between the sun visors can operate up to 3 separate remote control devices (for example, a gate and garage door, a house alarm, or a lighting system).
Getting ready to program
x Please read the product manufacturer's instructions before programming the garage door opener or other device.
x Safely park the vehicle within range of the device to be programmed.
x Switch the ignition on, but do not start the engine.
Menu Garage door opener in the Infotainment System
Call up the Garage door opener menu in the Infotainment System ⇒ fig. 41.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.

Function key: Effect
Program buttons : Buttons 1 , 2 or 3 can be programmed after you tap the function key. Follow the instructions on the Infotainment System screen.
Delete button assignment : Deletes the programming of buttons 1 , 2 , and 3 ⇒ fig. 40.
Version information : Most recent programming information for your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Programming information
You must complete the programming process within 5 minutes. If you exceed this time limit, the programming is cancelled.
If programming is cancelled, a red LED lights up in the keypad and the turn signals flash once.
Programming unassigned buttons
x Complete the programming preparation steps described above
x Press unassigned button in the roof keypad .
x Follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3 times.
Repeat these steps with another unassigned garage door opener button to use that button to control another device.
Programming previously assigned buttons
x Complete the programming preparation steps described above ⇒ Getting ready to program.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the Program button function key and follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.

If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3 times.
Repeat these steps with another previously assigned garage door opener button to use that button to control another device.
Deleting programming for all buttons
Be sure to delete the programming on all buttons on the sun visor keypad before selling the vehicle or turning it over to people you do not know.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the delete button assignment function key and confirm.
The green LED in the keypad will light up to confirm that the programming has been successfully deleted.
After programming
Test the garage door opener ⇒ Operating the HomeLink® Universal Transmitter.
Operating the HomeLink® Universal Transmitter
