Function Action
Switching the DRL back on: – Release the parking brake.
– OR: Turn the light switch to the
position.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static cor-nering lights. On some models the static cornering lights may be integrated in the headlights. At speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the !54/ position) ⇒ fig. 85, they work only when the headlights have been automatically switched on. The static cornering lights do not come on when the headlight switch is in
the / position or when the fog lights themselves have been switched on ⇒  Switching lights on and off.
Automatic headlight control !54/
Automatic headlight control is a convenience feature only and cannot always recognize all driving situations.
If the light switch is in the !54/ position, the outside vehicle lighting and the instrument lighting are
automatically switched on at dusk/nightfall and off in normal daylight in the following situations ⇒ :

Automatic activation: Automatic deactivation/change to
daytime running lights:
If the low-light sensor registers
darkness, for example when driving
through a tunnel.
If sufficient brightness is registered.
If you drive faster than about
87 mph (140 km/h) for several se-
conds.
If you drive slower than about
40 mph (65 km/h) for several se-
conds.
If the rain sensor recognizes heavy
rain and switches the windshield
wipers on.
If the windshield wipers have not
moved for several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination during cornering.
The Adaptive Front Lighting System can be switched on and off in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select the menu item Lights and vision from the list.
x Tap Adaptive front lighting system (AFS) to enable or disable this feature.
The feature is enabled when the check box in the Adaptive front lighting system (AFS) function key is checked =.
Lights with LED-technology
You cannot replace the LEDs. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. (DRL) are not bright enough to light up the roadway and be seen by other motorists. You will not be able to see far enough ahead for safety, especially at dusk or when it is dark. Always switch on the low beam headlights at dusk or when it is dark.
x If automatic headlight control (!54/) is switched on, the low beam headlights still may not be switched on in fog or heavy rain. You have to switch on the low beam headlights yourself.
x The taillights do not come on when the daytime running lights are switched on. A vehicle without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can tempo-rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

x Check the check box in the Coming home or Leaving home to select the = feature key.
“Coming home” features
The lighting delay period can be adjusted in the Infotainment System.

Function key: More information
10 Sec. : The lighting delay period is about 10 seconds. Tap the function to
select the setting and close the window.
20 Sec. : The lighting delay period is about 20 seconds. Tap the function to
select the setting and close the window.
30 Sec. : The lighting delay period is about 30 seconds. Tap the function to
select the setting and close the window.

To close the window without changing the setting, tap X .
“Leaving home” feature
The “Leaving home” feature can be enabled or disabled in the Infotainment System. The lighting delay period can also be adjusted in the Infotainment System.

Function key: More information
Off : Feature is switched off. Tap the function to select the setting and
close the window.
10 Sec. : The lighting delay period is about 10 seconds. Tap the function to
select the setting and close the window.
20 Sec. : The lighting delay period is about 20 seconds. Tap the function to
select the setting and close the window.
30 Sec. : The lighting delay period is about 30 seconds. Tap the function to
select the setting and close the window.

To close the window without changing the setting, tap X .
Switching the “Coming home” and “Leaving home” features on and off
The “Coming home” feature must be switched on manually. The “Leaving home” feature is automati-cally controlled by a low-light sensor.

“Coming home” Action
Switch on: – Switch off the ignition.
– Operate the headlight flasher for about 1 second
⇒ page 117.
Opening the driver door switches on the “Com-
ing home” feature. The delay period starts when the
last vehicle door or the rear hatch is closed. The “Com-
ing home” lighting is switched on when the driver door
is open, the headlight switch is set to AUTO, and the
low light sensor detects darkness. The delay period
starts once the last vehicle door or the rear hatch is
closed.
Switch off: – Automatically after the preset delay period is over.
– Automatically if any door or the rear hatch is still open
about 60 seconds after activation.
– Turn the light switch to the / position.
– Switch on the ignition.


“Leaving
home” Action
Switch on: – Unlock the vehicle when the light switch is not in the /
position and the low-light sensor registers darkness. Un-
lock the vehicle if the light switch is in the AUTO position
and the low-light sensor registers darkness.
Switch off: – Automatically after the preset delay period is over.
– Lock the vehicle.
– Turn the light switch to the / position.

“Leaving
home” Action
– Switch on the ignition.

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a light sensor, the background lighting in the outside mirrors is only switched on in darkness.
The lights stay on for about 10 seconds (lighting delay period). The “Coming home” and “Leav-ing home” features can be enabled and disabled in the Infotainment System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic warning will sound to alert that the light is still on.
Instrument panel lighting and headlight range adjustment

Fig. 86 Next to the steering wheel: Control for instrument cluster lighting.

WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Always adjust headlights to loading conditions so that the light cone do not blind others.
WARNING
If dynamic headlight range adjustment does not work properly or at all, the headlights could blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Have headlight range adjustment checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Interior and reading lights

The brightness can be adjusted in the Infotainment System.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select the menu item Lights and vision in the list.
x Select the menu item Footwell light or Ambient lighting from the sub-menu.
x Place your finger on the touchscreen slider ? and, keeping your finger on the screen, move your finger to drag the slider to the desired brightness.
x OR: Tap the - or + function key on the screen to move the slider in steps.
Background lighting
When the ignition and headlights are switched on, the roof console control buttons light up.
There may also be footwell lighting.
The brightness is set using the instrument lighting control
The interior and reading lights go out when you lock the vehicle or a few minutes after you re-move the vehicle key from the ignition. This helps to prevent unnecessary drain on the vehicle battery.
You have to push the  button twice to switch on a reading light that has been automatically switched off.

Sun protection

Sun visor adjustment:
x Flip the sun visor down toward the windshield.
x Lift out of mounting and move toward the doors ⇒ fig. 87 (1).
x Rotate the sun visor toward the door.
Vanity mirror and lighting
A vanity mirror is behind a cover in the sun visor. When the cover is slid open (2), the light comes on.
The light goes out when you shut the cover or if you flip the sun visor up again.
The vanity mirror light goes out after several minutes. This helps to prevent unnecessary drain on the vehicle battery.
Windshield made of heat-insulating glass

Fig. 89 Heat-reflective windshield with communications window (blue shaded area).

Rear side window sunshade

Fig. 90 Sunshade in the rear right window.
