VOLKSWAGEN TOUAREG 2017 Owner´s Manual

Folding the backrest of the rear bench forward and back into place

Fig. 99 Lower part of the rear seat bench: Lever to unlock the rear seat backrest by hand.

Fig. 100 Right side wall of the luggage compartment: Switches for power release of the rear seat backrest.

x After putting the seat backrest back up, the seat must be adjusted to the person using it ⇒  Adjust-ing the seating position.
WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal injury.
x Always make sure there are no people or animals in the area around the rear seat backrest when folding it forward.
x Never fold the rear backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get caught or damaged.
x Keep hands, fingers, feet and other body parts out of the way when folding the rear seat backrest up and down.
x Each rear seat backrest must be securely latched in the upright position so that the safety belts on the rear seats can provide protection. This is particularly the case for the middle seat on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together with the rear seat backrest during sudden braking, driving maneuvers or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head restraint or backrest cushion will not butt up against the front seats.
x The weight on the rear seat backrests when folded down must never exceed 110 lbs. (50 kg).
NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is adjusted in the fore and aft direction.
If the vehicle battery charge is weak, power release of the rear seat backrests may not be possi-ble.

Luggage compartment cover

Fig. 101 In the luggage compartment: Closed luggage compartment cover.

Fig. 102 In the luggage compartment: Removing the luggage compartment cover.

Removing the luggage compartment cover
x If there is a gap cover (2), unhook it from the fastening eyes on the rear seat backrests ⇒ fig. 102 (1).
x Push down release button (2) and push in the end parts of the luggage compartment cover (3).
x Lift the luggage compartment cover up and out.
Reinstalling the luggage compartment cover
x First fit the luggage compartment cover ⇒ fig. 101 (1) into the left-hand slot.
x Then fit the other end into the right-hand slot.
x Push down release button ⇒ fig. 102 (2) and push in the end parts of the luggage compartment cover (3).
x Push the luggage compartment cover down into the right-hand slot so that it locks into place.
x Make sure that the luggage compartment cover is properly locked into place.
x If there is a gap cover ⇒ fig. 101 (2), hook it back into the fastening eyes on the rear seat backrests
⇒ fig. 102 (1).
WARNING
In a sudden braking or other maneuver, or in a collision, unsecured or improperly secured objects or animals on the luggage compartment cover could cause serious personal injury.
x Never leave hard, heavy or sharp objects in bags or loose on the luggage compartment cover.
x Never let animals ride on the luggage compartment cover.
WARNING
The view towards the rear is greatly limited when the luggage compartment cover is in the convenience position.
x Before driving, ensure that the luggage compartment cover is not in the convenience position.
NOTICE
To help prevent damage to the luggage compartment cover, the luggage compartment may only be loaded to a height at which the luggage compartment cover will not press on the cargo when the rear hatch is closed.
x The defroster heating wires or antenna in the rear window can be damaged by objects that rub against them.
Do not cover the ventilation slots in the side consoles. Otherwise, stale air cannot escape from the vehicle.

Luggage compartment pass-through

Fig. 103 In the rear backrest: Luggage compartment pass-through opening.

Tie-downs

Fig. 104 In the luggage compartment: Tie-downs.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage compartment Hooks on elastic straps can cause serious personal injury if not handled properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the vehi-cle and do not let them snap back and hit you.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the lug-gage compartment and then to the tie-downs near the loading edge of the luggage compart-ment. This way, if one of the hooks on the elastic straps snaps back, it will move away from you, decreasing the risk of personal injury.
The maximum weight force for the tie-downs is about 785 lbs (356 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Shopping bag hook

Fig. 105 In the luggage compartment: Shopping bag hook.

Luggage compartment floor

Fig. 106 In the luggage compartment: Lifting luggage compartment floor panel and securing it with retaining strap.

Roof rack

Attaching the roof rack base carrier and roof rack

Fig. 107 Attachment points for the base carrier and roof rack.
