System settings (CAR)

Settings main menu (CAR)

Fig. 140 Infotainment system with navigation: Settings main menu (CAR).

Fig. 141 Infotainment system without navigation: Settings main menu (CAR).

Function key: Effect
Hybrid : Hybrid menu
Offroad : Shows the steering angle ⇒ fig. 140 (A), the compass view with
the current direction of travel (B) and the current altitude (C).

You can always go back to the previously active menu from the main menu by pressing the

The feature is enabled when the function key check box = is checked.

Function key: Effect
= Rain sensor : Activate or deactivate rain sensor
Parking distance warning system : Settings for parking distance warning
system

Changes made in settings menus are automatically applied once the menu is closed.
Settings menu

Function key: Effect
OR: Set the date
Units : Set units for displays in the vehicle.
OR: Set units for displays in the vehicle
Service/inspection : Settings for the Service reminder display and the ser-
vice position of the windshield wipers. Display of current oil level
⇒ page 587 and service messages.
OR: Service menu.
Lights and vision : Settings for lighting outside the vehicle and inside the
passenger compartment
Instrument cluster : Settings for the instrument cluster
Seat settings : Settings for the front seats
Vehicle key : Settings for convenience closing
Central locking : Settings for the central locking system
Garage door opener : Settings for the garage door opener
Vehicle ID/Number of keys : Display of vehicle chassis number and num-
ber of authorized remote control vehicle keys
Tire pressure monitoring : Settings for the Tire Pressure Monitoring Sys-
tem (TPMS)

Changes made in settings menus are automatically applied once the menu is closed.
Service menu

x Press the CAR Infotainment button.
x Tap the Service function key on the screen.
x OR: Tap the Settings and then tap the Service/inspection function key on the screen.
Display of current oil level and service messages
Pressing the

Radio mode

Opening the RADIO main menu and changing frequency band

Fig. 142 RADIO main menu in FM mode.

Function key: Effect
Scan : Starts and stops the scan feature
Screen off : Switching off the display. To switch on again, press any
Infotainment button or touch screen.
Tune : Opens the frequency dial for the selected frequency band
1... to 36... : Station buttons for storing radio stations

Changing radio station or selecting a station from the station list

Fig. 143 FM-station list: Station 2 is playing.

Scan feature (Scan)
