VOLKSWAGEN TOUAREG 2017 Owner´s Manual

Cruise Control System (CCS)

Warning and indicator lights

Fig. 266 In the instrument cluster display: Cruise control status indications.

Adaptive Cruise Control (ACC) with Front Assist

WARNING
Always remember that the Adaptive Cruise Control has limits – Using Adaptive Cruise Con-trol when it is not possible to drive safely at a constant speed can be dangerous and can lead to an accident and serious personal injury.
x Adaptive Cruise Control will not slow the vehicle down or maintain the set distance when you drive towards an obstacle or something on or near the road that is not moving, such as vehicles stopped in a traffic jam, a stalled or disabled vehicle.
x Always adjust your speed and the distance you keep between you and the vehicles ahead of you to the road, traffic, weather, and visibility conditions.
x Never use Adaptive Cruise Control on steep, winding, or slippery roads (such gravel roads, wet roads, or snowy or icy roads) or on roads with standing water.
x Never use Adaptive Cruise Control when driving in heavy or varying stop-and-go traffic.
x Never use Adaptive Cruise Control when driving off-road or on unpaved roads.
x Always remember that the Adaptive Cruise Control cannot detect a vehicle that is driving towards you in your traffic lane and that it cannot detect narrow vehicles such as motorcy-cles and bicycles.
x Never follow a vehicle so closely that you cannot stop your vehicle safely. The Adaptive Cruise Control cannot slow or brake the vehicle safely when you follow another vehicle too closely. Always remember that the Adaptive Cruise Control has a braking power that is only about 30% of the vehicle's maximum braking ability, under certain circumstances the auto-matic braking function cannot bring the vehicle to a stop in time.
x Always turn off Adaptive Cruise Control when entering turn lanes, exit lanes and construc-tion zones or in similar situations because the vehicle will automatically accelerate to the stored speed when the road ahead is clear.
x To help prevent unintended operation of Adaptive Cruise Control, switch the system off when it is not being used.
x It is dangerous to use the Resume feature when the previously set speed is too high for the existing road, traffic, or weather conditions.
x When traveling downhill, the Adaptive Cruise Control may not be able to maintain a con-stant speed. The vehicle will speed up because of its own weight. Downshift and/or use the foot brake to slow the vehicle.
x Never allow the closing speed between you and other vehicles to be so high that the Adaptive Cruise Control may not be able to slow your vehicle safely. If closing speed is too high, you must apply the brakes yourself to reduce the risk of a rear-end crash.
x If a driver intervention warning appears in the instrument cluster display, immediately takeover the control of the brake and gas pedals and low down the vehicle or bring it to stop when necessary and according to the traffic situation.
x If a Forward Collision Warning system (Front Assist) collision warning appears in the instrument cluster display, immediately takeover the control of the brake and gas pedals and low down the vehicle or bring it to stop when necessary and according to the traffic situation.
x Always be prepared to takeover the control of the brake and the gas pedal in every situa-tion.
NOTICE
If you suspect that ACC and the Forward Collision Warning system (Front Assist) don't work properly or the sensors are damaged, switch off ACC immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the ACC system checked.

Display, warning and indicator lights

Fig. 269 In the instrument cluster display: ACC is active and the maximum distance is set to the detected vehicle in front.

Fig. 270 In the instrument cluster display: ACC is not active but a vehicle was detected in front.

Lights
up Possible cause ⇒  Proper response

Lights
up Possible cause ⇒  Proper response
E
Adaptive Cruise Control
(ACC) is not active, the sys-
tem is on but not regulating
or holding speed.
-

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Radar sensors, ultrasonic sensors and Front Assist camera

Fig. 271 Vehicle front view: Sensors and camera

There are 2 radar sensors next to the fog lights on the vehicle front (3). These can detect moving vehicles up to 590 ft (180 m) in front of your vehicle.
The areas of the sensors (2) and (3) and the camera (1) must not be spray painted on or covered by stickers or other objects, since this can lead to a malfunction of the Adaptive Cruise Control (ACC) and the Front Assist system.
NOTICE
If you notice that Adaptive Cruise Control (ACC) or Front Assist doesn't work properly or the sensors are damaged, switch off ACC immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the ACC system checked.
x The sensors can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors can cause ACC or Front Assist to malfunction.
x To help make sure that the system works properly, always keep the sensors clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x For Declaration of Compliance to United States FCC and Industry Canada regulations
Always keep the area of the Front Assist camera clear of ice and snow.
Switching ACC on and off

Fig. 272 On the steering wheel column: Lever for Adaptive Cruise Control.

Fig. 273 Lever for Adaptive Cruise Control: Setting the distance (time intervals)

In order to: You must ⇒ fig. 272: Result:
Push and hold the lever in the
