VOLKSWAGEN TOUAREG 2017 Owner´s Manual

Distance between vehicle
and obstacle
Audible sig-
nal
Screen: Segment color
if obstacle detected
Front: about 12 – 48 inches
(31 – 120 cm) Beep tone if
manually
activated.
Yellow
Rear: about 12 – 64 inches
(31 – 160 cm)
Front: about 12 – 20 inches
(31 – 50 cm) Beep tone if
automatically
activated.
Yellow
Rear: about 12 – 20 inches (
31 – 50 cm)
About 0 – 12 inches (0 –
30 cm) front or rear
Continuous
tone. Red

The distance at which the continuous tone sounds is somewhat greater for vehicles with a factory-installed trailer hitch.
Infotainment System settings for OPS
A number of settings can be selected in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Assist systems function key on the screen.
x Select Parking Distance Warning System from the list.

Function key: Actions
Front volume/tone level : Different volume and pitches can be separately
selected for front by tapping the - or + function keys or by moving the
slider.
Rear volume/tone level : Different volume and pitches can be separately
selected for rear by tapping the - or + function keys or by moving the slid-
er.
Reduced audio volume : Different volume and pitches can be separately
selected for front and rear by tapping the - or + function keys or by mov-
ing the slider.

Function key: Actions
Automatic activation of mini-OPS : If the check box in the function key is
checked =, the small screen OPS display is automatically switched on
when you slowly approach an obstacle. To switch off this feature, tap Au-
tomatic activation of mini-OPS . After deactivation, there will not be any
warning when you approach an obstacle.
Reset settings : Resets all settings to the factory settings.

When towing a trailer
On vehicles with a factory-installed trailer hitch and an electrically connected trailer, a corresponding graphic is displayed on the screen. Distance values behind the vehicles will not be displayed.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on the Radio or Navigation system screen. Tap the function key again to reactivate the acoustic signals.
Muting is cancelled by switching Park Distance Control back on after it was switched off. The warning messages cannot be switched off.
If the display has been switched off manually and PDC remains active, the mute setting is also can-celled.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
WARNING
Never rely completely on the OPS for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The OPS sensors have blind spots where they cannot detect persons or objects.
x Never pay so much attention to the OPS and the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
NOTICE
Automatic activation of OPS when approaching an obstacle works only when your speed falls below a threshold of about 5 - 10 mph (10 - 15 km/h). If you then close the display, you must either switch the ignition off and back on or exceed the speed threshold and then reduce speed to under the threshold a second time in order for it to activate automatically again.
Volkswagen recommends practice parking with Park Distance Control and the Optical Parking System on a parking lot or other place where there is little traffic to get used to how the system works.

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious person-al injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Maximum heating output and fast defrosting will only be possible after the engine has reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the heating and ventilation systems as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, colli-sions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation a long period of time because no fresh air will come into the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen rec-ommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation sys-tem can leave residue on the evaporator and on the dust and pollen active carbon filter, result-ing in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal con-venience settings and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Climatronic controls

Fig. 301 In the front center console: Climatronic controls.

Button/Knob More information. Front Climatronic controls ⇒ fig. 301.

Defog / defrost button: The incoming outside air is directed
to the windshield, and air recirculation is automatically dis-
abled. At temperatures above +38 °F (+3 °C), the air is
dehumidified and the fan is set a to high speed so as to
defog/defrost the windshield as quickly as possible.
39.# Apply the driver settings to all climate zones ⇒ page 526.
3 Air recirculation
=
Rear window defroster: works only when the engine is run-
ning or, on hybrid vehicles, when the vehicle is ready to
drive; switches itself off after 10 minutes at the latest.
!

Operation via the Infotainment System

Fig. 302 Infotainment System: Front climate control settings.

Function
key More information. Front Climatronic controls ⇒ fig. 302.

x Press the Units feature key.
x Select the desired unit.
Automatic window fog detection
Automatic window fog detection checks whether the windows are fogged up and if necessary automat-ically adjusts the air flow to the windshield and side windows or switches on the windshield heating. If the fan or the air conditioner !

Air vents

Fig. 303 Air vents in the instrument panel.
