Manual transmission fluidQuality: Volvo synthetic gearbox oil
1161423
Capacity: 2.2 US qts (2.1 liters)
Power steering fluid Quality: ATF Capacity: 0.95 US qts. (0.9 liters)
Brake fluid Quality: DOT 4+ Capacity: 0.64 US qts. (0.6 liters)
* Add 0.95 qts. (0.9 liters) if the oil cooler has been drained
All specifications are subject to change without notice.
pg. 125 Engine
Engine
Liquid-cooled gasoline, 5-cylinder, in-line engine. Aluminum alloy cylinder block with cast-iron cylinder liners cast
directly into block. Aluminum alloy cylinder head with double overhead camshafts and separate intake and outlet
channels.
Engine lubrication is provided by an eccentric pump driven from the crankshaft. Full-flow type oil filter. Exhaust
emission control accomplished by multiport fuel injection, heated oxygen sensor(s) and three-way catalytic converter.
Designation: Volvo B 5254 T
Output 190 hp at 5100 rpm (142 kw 85 rps)
Max torque 199 ft. lbs. at 1800 -4998 rpm (270 Nm/30 -83.3 rps)
Number of cylinders 5
Bore 3.27" (83 mm)
Stroke 3.54" (90 mm)
Displacement 2.4 liters
Compression ratio 9.0:1
Number of valves 20
Valve clearance Self -adjusting
Designation: Volvo B 5234 T3
Output 236 hp at 5100 rpm (176 kw/85 rps)
Max torque 243 ft. lbs. at 2700 -5100 rpm (330 Nm/45 -85 rps)
Number of cylinders 5
Bore 3.19" (81 mm)
Stroke 3.54" (90 mm)
Displacement 2.3 liters
Compression ratio 8.5:1
Number of valves 20
Valve clearance Self -adjusting
All specifications are subject to change without notice.
Contents | Top of Page
ProCarManuals.com
Page 32 of 39
Chapter 10 - Audio systems
pg. 131 Audio systems
Audio systems
This chapter describes the audio system in your car. SC-813
132
SC-816145
SC-900/901161
General Information184
pg. 132 Audio system SC -813 (certain models)
The following pages describe the use of your SC -813 Cassette radio and CD remote control
1. On/off (push)
2.
3. Volume (turn)
4. Pause/Mute (push)
5. Balance (pull)
6. Active Sound
Control
7. CD changer selector
8.
9. Tape mode selector
10. Tape direction
selector PROG
11. Bass control
12. Treble control
13. Fader control
14.
15. Preset buttons
16. CD-Disc No.
selector
17. PROG - Reversing 11.
Dolby B NR button
12. Cassette eject
13. Not in use
14. Scan
15. Auto seek memory
16.
17. Seek tuning up/down
18. TP-Next/Previous song
19. CD-Next UP/Previous
DOWN track
20.
21. Manual tuning
22. TP-fast forward/Rewind
23. CD-Music search
UP/DOWN
24. RND button 19.
Cassette slot
20. Display
21. Waveband selector (AM)
22. Waveband selectors (FM)
23. Anti-theft LED
TP = Applicable only in Tape Mode
CD = Applicable only when in CD mode and
connected to a CD changer.
ProCarManuals.com
Page 33 of 39
the tape
pg. 133 Anti -theft code
Anti -theft code
The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a
special code must be entered to enable operation of the set.
Refer to the radio code card supplied with your vehicle or ask your retailer for the correct code.
When the car is parked with the ignition key removed, the anti-theft LED will flash.
To enter the code
After installation or when the set has been disconnected from power, the set displays "COdE" when it is switched on.
Enter the 4-digit code using the preset buttons. If the correct code is entered, "on" is displayed and the set is ready to
use.
If you enter an incorrect code you must enter the correct code again from the beginning.
Incorrect code
If an incorrect code has been entered "rPt" is displayed. Enter the correct code.
After three unsuccessful coding attempts the set will lock and remain locked for two hours. "OFF" is displayed.
During this waiting period:
the battery must be connected
the ignition key must be turned to position I
the unit must be turned on
Make sure the headlights are turned off to help prevent battery drain (please refer to page 24 for information on turning
the headlights off). Enter the code again once this time has elapsed.
ProCarManuals.com
Page 34 of 39
Contents | Top of Page
ProCarManuals.com
Page 35 of 39
pg. 188 Index
A
ABS........................................17Adjusting headligh.........................86Air conditioning...........................35Air mix....................................33Air vents..................................33Airbag (SIPS)...............................8Airbag (SRS)................................4Alarm......................................44Ambient temperature sensor.................25Anti -lock Brake System (ABS).........17, 19,70Ashtrays...................................31Audio systems
General information.....................184
SC-813..................................132 SC-816..................................145 SC-900/901..............................161Auto -dim (rear -view mirror)................48Automatic car washing.....................103Automatic daytime running lights...........24Automatic transmission........60,61,62,63,127 Driving mode selector....................62Automatic transmission fluid..........117,124
B
Battery................................72,128Battery drain - avoiding...................54Battery maintenance.......................122Booster cushion............................11Brake failure warning light.............17,18Brake fluid...........................116,124Brake fluid warning light..................18Brake system............................70,71Brake warning light........................17Break -in period............................56Bulb failure warning....................17,19Bulbs.....................................128Bulbs - replacing..........................85
C
Capacities................................127Catalytic converter........................69Central locking button.....................36Chains (snow)..............................77Changing a wheel...........................82Child booster cushion......................11Child Restraint Anchorages..................9Child safety...............................11Clock......................................16Clock - resetting..........................25Clutch fluid..............................116Coolant - checking/changing...............120Coolant level sensor.......................19Coolant level warning light................17Cooling system.........................64,126Courtesy lights - front....................49Cruise control.............................29
D
Daytime running lights.....................24Demister - rear window.....................23Dimensions................................129Distributor ignition system...............126Distributor ignition system...............187Doors and locks............................42Drive belt................................118Driving economy............................58
ProCarManuals.com
Page 36 of 39
E
EBD (Electroinc Brake -force Distribution)..71ECC - Electronic Climate Control........34,35Electrical system......................64,128Electrically heated front seats............30Electrically operated front seats.......46,47Electrically operated sun roof.............41Electrically-operated windows..............36Electroinc Brake Distribution..............71Electroinc Brake -force Distribution........71Emergency towing...........................66Emergency warning flashers.................23Engine....................................125Engine compartment........................121Engine oil........................114,115,124Engine oil - checking/changing............114Engine oil pressure........................17Exterior courtesy lights...................20
F
Fog light - rear........................17,22Fog lights - front.........................22Front courtesy lights......................49Front fog lights...........................22Front seats................................46Front seats - heated.......................30Front seats - memory function..............46Front suspension..........................126Fuel gauge.................................16Fuel level.................................17Fuel requirements..........................56Fuel system...............................126Fuel tank cover - opening...............37,57 opening manually.........................97Fuses................................91,92,93Fuses - replacing..........................91
G
Gas tank cover - opening................37,57 opening manually.........................97Generator..............................17,128Generator warning light....................18
H
Hand brake.................................30Handling...................................65Hazard warning flashers....................23Headlight adjustment.......................86Headlight wiper blades - replacing.........96Headlights.................................20Heated front seats.........................30Heated side -view mirrors...................23Heating....................................35Heating and air conditioning...............33High beams.................................17Hoisting the car..........................110Hood.......................................51
I
Ignition switch............................21Immobilizer(start inhibitor)...............42Instrument illumination....................22Instruments.............................14,15
J
Jack.................................53,82,83Jump starting..............................68
K
ProCarManuals.com
Page 37 of 39
Keyless entry system.......................43Keylock....................................59Keys.......................................42Kick -down..................................61
L
Label information.........................106Lifting the car...........................110Locks......................................42Long distance trips........................74Long load storage..........................50Lubrication...............................113
M
Maintenance schedule......................108Maintenance service.......................107Malfunction indicator lamp..............17,18Manual transmission....................60,127Manual transmission fluid.................124Memory function - front seats..............46Mirrors - rear/side view...................48
O
Occupant safety............................12Octane rating..............................57Odometer...................................16Oil (engine)......................114,115,124Oil pressure warning light.................18On-call...................................130
P
Paint touch -up............................100Parking brake...........................17,30Parking brake reminder light...............18Parking lights.............................20Polishing.................................103Power seats.............................46,47Power steering fluid..................116,124
R
Radio
General information.....................184
SC-813..................................132 SC-816..................................145 SC-900/901..............................161Radio Data System - RDS...................166Reading lights.............................49Rear (side) windows - opening..............37Rear fog light..........................17,22Rear suspension...........................126Rear window demister.......................23Rear/side -view mirrors....................48Refueling..................................57Remote control (central locking system)....43Remote keyless entry system................43Replacing bulbs.............85,86,87,88,89,90Replacing fuses............................91Reporting Safety Defects...................12Roadholding................................65Roof rails/racks...........................65
S
Safety defects (reporting).................12Seat belt maintenance......................12Seat belts.............................2,3,10 Automatic Locking Retractor..............10 Emergency Locking Retractor..............10Seat belts - cleaning.....................104
ProCarManuals.com
Page 38 of 39
Seats......................................46Seats - heated.............................30Securing cargo.............................54Service reminder indicator..............17,19Servicing.........................110,111,112Shift lock..............................59,61Shiftlock release (override)...............97Side Impact Protection System (SIPS)........8Side -view mirrors - heated.................23SIPS........................................8Snow chains................................77Snow tires.................................77Spare tire.................................84Spare tire (sedan).........................53Spark plugs...............................126Spark plugs - replacing...................110Specifications............................123SRS.....................................5,6,7SRS diagnostic system......................19SRS warning light.....................5,17,19Stability and Tranction Control(STC).19,23,71Start Inhibitor (Immobilizer)..............42Starting the engine........................59Steering wheel adjustment..................32Steering wheel lock........................21Storage compartments.......................40Studded tires..............................77Sun roof................................23,41
T
Tachometer.................................16Temperature gauge..........................16Temporary spare tire.......................84Three -way catalytic converter..............69Tire pressure..............................78Tires - changing...........................82Towing..................................66,67Towing a trailer...........................72Trailer towing.............................72Trip computer.....................23,26,27,28Trip odometer..............................16Trunk - opening/locking....................52Trunk light................................53Turn signals............................17,20
U
Uniform tire quality grading...............79Upholstery - cleaning.....................104
V
Vanity mirrors.............................49Vehicle Identification Number (VIN).......106Vehicle loading...........................127Volvo On Call.............................130
W
Warning flashers...........................23Warning lights..........................18,19Warranty..................................107Washer fluid level.........................17Washer fluid reservoir....................119Washing...................................102Waxing....................................103Weights...................................129Wheel changing..........................82,83Wheels and tires...........................76Windows - electrically-operated............36Windshield washer nozzles.................119
ProCarManuals.com
Page 39 of 39
Windshield washers/wipers..................21Windshield wiper blades - replacing........95Winter driving.............................73
