ECO mode VOLVO C70 CONVERTIBLE 2010 Owner´s Manual

10 Audio
Radio functions
10
246
channels will be displayed as 93.9 – 2
WNYC, 93.9 - 3 WNYC, etc.
•Reception coverage area: Due to current
IBOC transmitter power limitations, the
reception coverage area in digital mode is
somewhat more limited than the station's
analogue coverage area. Please be aware
that as with any radio broadcast technol-
ogy, terrain, time of day, foliage level and
building location can have positive or neg-
ative effects on radio reception.
•Analogue to digital/digital to analogue
blending: Analogue to digital blending will
occur as the signal strength reaches a pre-
set threshold in the receiver. This will be
noticeable in fringe areas (areas with weak
reception) and is normal.
NOTE
There may be a noticeable difference in
sound quality when a change from analogue
to digital or digital to analogue occurs, such
as:
•Volume increase or decrease
•Equalizer settings, i.e. Bass/ Midrange/
Treble cut or boost
•Time alignment (Digital program mate-
rial in extreme cases can be as much as
8 seconds behind the analogue). This
will noticeable as a "stuttering" effect.
The above items are dependant on the
broadcaster's equipment settings and do
not indicate a fault in the vehicle's radio
receiver or antenna systems.
Switching HD on or offThe factory setting for HD radio is on. However,
when driving through areas with weak HD sig-
nals (fringe areas), you may experience that the
radio repeatedly switches between analogue/
digital and digital/analogue reception. If this
happens, it may be desirable to switch HD off.
To do so:
1. Be sure the audio system is switched on
and in AM or FM mode.
2.
Press MENU in the center console control
panel.3.
Press ENTER to turn HD off (the X will dis-
appear from the box on the display screen).
This will disable the radio's capability to receive
digital broadcasts but it will continue to func-
tion as a conventional (analogue) AM/FM
receiver. Please note that when HD is switched
off, it will not be possible to tune to sub-chan-
nels (see the following section for a more
detailed explanation of sub-channels).
Repeat steps 2 and 3 above to reactivate HD
(an X will appear in the box on the display
screen).
Sub-channels
Example of an HD Radio station with sub-channels

10 Audio
Radio functions
10

247
In many cases, a main HD Radio station (FM
wavebands only) will also have sub-channels
offering additional types of programming or
music.
In such cases, the “>” symbol will be displayed
to the left of the frequency number and a num-
ber will be displayed to the right of the fre-
quency number indicating that the currently
tuned frequency has at least one sub-channel.
The "2" in the illustration indicates that you are
currently listening to the first sub-channel on
frequency 93.9.
Selecting sub-channelsTo listen to a station's sub-channel(s), press
the right arrow key on the center console or on
the steering wheel keypad. To go back to the
main channel, press the left arrow key. To go
to subchannel 2 (if available), press the right
arrow key.
If you are currently tuned to a frequency's main
channel, pressing the left arrow key will tune to
the next lower radio frequency.
NOTE
•When the radio has gone into HD mode,
it may take several seconds before the
">" symbol (if the current frequency has
any sub-channels) is displayed to the
right of the frequency. Pressing the
arrow keys before the number is dis-
played will cause the radio to tune to the
next available radio station, not to the
current station's sub-channels.
•When you are no longer in broadcasting
range of the currently tuned sub-chan-
nel,
No HD reception will be dis-
played. The radio will then be muted
and it will be necessary to tune to or
search for a new radio station.
Sub-channels can also be stored as presets,
see page 243 for information on storing sta-
tions.
If you press a sub-channel's preset button, it
may take up to 6 seconds before the channel
becomes audible. If you press this button while
you are out of digital range of the transmitter,
No HD reception will be displayed.
Listening to satellite radio
The Sirius satellite system consists of a number
of high elevation satellites in geosynchronous
orbit.
NOTE
•The digital signals from the Sirius satel-
lites are line-of-sight, which means that
physical obstructions such as bridges,
tunnels, etc, may temporarily interfere
with signal reception.
•Avoid any obstructions, such as metal-
lic objects transported on roof racks or
in a ski box, or other antennas that may
impede signals from the SIRIUS satel-
lites.
Selecting Sirius radio mode1. Press Power to switch on the audio system
(see page 243 for information on the stand-
ard radio functions).
2.
Press the MODE button repeatedly until
Sirius 1 or 2 is displayed.
Activating Sirius radio1. Tune to a satellite channel that has no
audio, which means that the channel is
unsubscribed and the text "
Call 888-539-
SIRIUS TO SUBSCRIBE" is displayed

10 Audio
CD player/CD changer
10

* Option/accessory, for more information, see Introduction.251 CD function controls
G026367
MENU NAVIGATION CONTROL–press
the up or down arrow keys to scroll in a
menu, or the keys on the left/right sides of
the control to change CD tracks/fast for-
ward/back
Buttons for selecting a disc in the
optional CD changer
CD eject button
CD slot
MODE button
TUNING dial for selecting tracks
Playing a CD
Single CD playerStart the CD player by pressing the MODE but-
ton (5) and inserting a disc in the slot (4). If there
is already a disc inserted, it will begin to play.
NOTE
If a CD is in the slot when the audio system
is in CD mode, the CD will be played auto-
matically.
CD changer*
The CD changer can hold up to six discs.
1. Start the CD changer by pressing the
MODE button (5).
2. Select an empty position using the 1 – 6
buttons or the up/down keys on the MENU
NAVIGATION CONTROL. The display
shows which positions are empty.
3. Insert a disc into the slot (4).
NOTE
•Ensure that INSERT DISC is displayed
before inserting a disc.
•If a CD position in the changer contain-
ing a disc is selected, and the audio
system is in CD mode when it is
switched on, the CD will play automati-
cally.
CD eject
Eject from Single CD player

Press the eject button (3) to eject the disc.
Eject from CD changerThis function makes it possible to eject a single
disc, or to eject all of the discs in the changer.

Press the eject button (3) briefly to eject the
disc that is currently playing.

A longer press (more than two seconds)
starts the process of ejecting all of the
discs in the changer.

10 Audio
CD player/CD changer
10
252
NOTE
•The EJECT ALL function can only be
used while the vehicle is at a standstill
and will be cancelled if the vehicle
begins to move.
•For reasons of traffic safety, the ejected
CD must be removed within 12 seconds
or it will be automatically drawn back
into the slot and the CD player will enter
pause mode. Press the CD button to
restart the disc.
CD PauseWhen the audio system volume is turned off
completely, the CD player will pause and will
resume playing when the volume is turned up
again.
Audio filesIn addition to playing normal music CDs, the
CD player/changer can also play discs con-
taining files in mp3 or wma format.
NOTE
Certain discs that are copy protected can-
not be read by the player.
When a disc with audio files is inserted in the
player, the player scans the disc's folders
before it begins playing the files. The length oftime that this takes depends on the quality of
the disc.
Navigating the disc and playing tracksIf a disc with audio files is in the CD player,
press ENTER to display a list of folders on the
disc.
Use the up and down arrows in the navigation
control (see the illustration on page 251) to
move among the folders on the disc. Audio files
have the
symbol and folders containing
these files have the
symbol. Press
ENTER to play a selected folder or a file.
When the music file has been played, the
player will continue to play the rest of the files
in the current folder. When all of the files in the
folder have been played, the player will auto-
matically go to the next folder and play the files
in it.
Press the left or right arrow key on the naviga-
tion control if the entire name of the current
track does not fit in the display.
Changing tracksBriefly press the left or right arrow keys on the
MENU NAVIGATION CONTROL to skip to the
previous or next track/file.
NOTE
The TUNING dial (6) (turn clockwise to go to
the next track/file, or counterclockwise to
go to the previous track/file) or the steering
wheel keypad can also be used for this pur-
pose.
Fast forward/back
Press and hold down the left or right arrows
keys in the menu navigation control (or the
corresponding keys on the optional steer-
ing wheel keypad) to search within a track/
file or the whole disc. The search continues
for as long as the buttons are held down.
Random playThis function plays the tracks/files on a CD (or
on all of the CDs if the vehicle is equipped with
the optional CD changer) in random order
(shuffle).
Activating/deactivating the random
function-CD player
If a normal CD is being played:
1.
Press MENU followed by ENTER.
2.
Select Random and press ENTER.
If a CD with audio files is being played:1.
Press MENU followed by ENTER.
2.
Select
Random and press ENTER.

10 Audio
CD player/CD changer
10

253
3.
Select Disc or Folder and press ENTER.
Activating/deactivating the random
function-CD changer
If a normal CD is being played:
1.
Press MENU followed by ENTER.
2.
Select
Random and press ENTER.
3.
Select
Single disc or All discs and press
ENTER.
If a CD with audio files is being played:1.
Press MENU followed by ENTER.
2.
Select
Random and press ENTER.
3.
Select
Single disc or Folder and press
ENTER.
NOTE
CD changer only–you can only select the
next random track/file on the current disc.
Press the EXIT button to stop random play.
The random function is automatically deacti-
vated when another disc is selected.
Disc text (CD changer only)Certain CDs contain information about the
disc, such as the titles of the tracks, etc. This
information can be shown in the display by
activating the DISC TEXT function.1.
Press MENU. Select the menu for relevant
sound source and press ENTER.
2.
Select
Disc text in the menu and press
ENTER.
> If information is stored on the disc, it will
now appear in the display.
To deactivate this function, select
Disc text in
the menu and press ENTER.
ScanThis function plays the first 10 seconds of each
track/file on the CD.

Press SCAN.

Press EXIT or SCAN to stop the scan func-
tion and listen to an entire track/file.
CD eject
Single CD player
Press the eject button (3) to eject the disc.
CD changerThis function makes it possible to eject a single
disc, or to eject all of the discs in the changer.
•Press the eject button (3) briefly to eject the
disc that is currently playing.
•A longer press (more than two seconds)
starts the process of ejecting all of the
discs in the changer.
NOTE
•The Eject all function can only be used
while the vehicle is at a standstill and will
be cancelled if the vehicle begins to
move.
•For reasons of traffic safety, the ejected
CD must be removed within 12 seconds
or it will be automatically drawn back
into the slot and the CD player will enter
pause mode. Press the CD button to
restart the disc.
Compact disc care
Keep the following in mind when playing/han-
dling compact discs
•Do not put tape or labels on the disc itself.
They could become stuck in the player.
•CDR discs can cause listening problems
due to the quality of the disc or recording
equipment used.
•DualDisc: The audio side of a DualDisc
(combined CD/DVD) does not meet CD
specifications and may not play in your
audio system.
•Keep the discs clean. Wipe them with a
soft, clean, lint-free cloth, working from the
center outward. If necessary, dampen the
cloth with a neutral soap solution. Dry thor-
oughly before using.

10 Audio
Bluetooth® hands-free connection
10

257
> The audio system will search for cell
phones that are in range. This search
takes approximately 30 seconds. Any
phones detected will be displayed with
their Bluetooth
® names. The hands-free
system’s Bluetooth® name will appear
in the cell phone’s display as My Car.
4. Select one of the cell phones shown in the
audio system’s (center console) display.
5. Using the cell phone’s keypad, enter the
digits shown in the audio system’s display.
Alternative 2–using the cell phone’s menus
1. Activate the hands-free system by briefly
pressing the PHONE button in the center
console. If there is a cell phone connected,
disconnect it from the hands-free system
(by pressing PHONE in the center console
for several seconds).
2. Perform a search using the cell phone’s
Bluetooth
® function (consult the cell
phone’s owner’s manual if necessary).
3.
Select
My Car in the list of devices shown
in the cell phone’s display.
4. When prompted, enter the PIN code 1234
in the cell phone.
5.
Connect to
My Car from the cell phone.The cell phone will be registered and will be
connected automatically to the audio system
while the text
Synchronising is displayed. For
more information on synchronizing a cell
phone, see page 259.
When a connection has been established, the
symbol and the cell phone’s Bluetooth®
name will be displayed. The cell phone can
now be controlled from the audio system.
Making a call1.
Ensure that TELEPHONE is shown at the
top of the center console display and that
the
symbol is visible (by pressing briefly
on PHONE on the center console).
2. Dial the desired phone number or use the
phone book (see page 259).
3.
Press ENTER.
End the call by pressing EXIT.
Disconnecting the cell phoneThe cell phone is automatically disconnected
from the audio system if it is moved out of
range. For more information about connec-
tions, see page 256.
The cell phone can be manually disconnected
from the hands-free system by pressing
PHONE. The hands-free system is also deac-
tivated when the ignition is switched off (or ifthe driver’s door is opened on vehicles equip-
ped with the optional keyless drive).
When the cell phone is disconnected from the
hands-free system, a call in progress can be
continued using the cell phone’s own speaker
and microphone.
NOTE
Certain cell phones may require confirma-
tion from the phone’s keypad when a call is
transferred from hands-free to the cell
phone.
Handling calls
Incoming calls
Press ENTER to answer a call, even if the
audio system is currently in e.g., CD or FM
mode.

Press EXIT to defer a call.
Automatic answerThis function means that incoming calls will be
answered automatically. Activate or deactivate
the function in the menu system under Phone
settings
Call optionsAutomatic
answer.

10 Audio
Bluetooth® hands-free connection
10
258
Call settingsWhile a call is in progress, press MENU or
ENTER on the center console to access the
following functions:
•Microphone off–mute the audio system’s
microphone.
•Transfer call to mobile–transfer the call
from hands-free to the cell phone.
•Phone book–this feature enables you to
search for a stored telephone number.
NOTE
•On certain cell phones, the connection
is broken when the mute function is
used, which is normal. If this happens,
the hands-free system will prompt you
to reconnect.
•A new call cannot be initiated while
another call is in progress.
Sound settings
Call volumeCall volume can be adjusted when the hands-
free system is activated. Use the buttons in the
steering wheel keypad or the audio system’s
volume control.
Audio system volumeWhile a phone call is in progress, volume for
the audio system can be adjusted in the normal
way with the audio system's volume control. In
order to adjust volume during a phone call, the
audio system must be switched to one of the
other modes (FM, CD, etc).
Audio system sound can be automatically
muted when a phone call is received in Phone
settings
Sounds and volumeMute
radio and adjust the volume with the
/
keys on the center console.
Ringing volume
Go to Phone settingsSounds and volume
Ring volume and adjust the volume with
the
/ keys on the center console.
Ringing tonesThe hands-free system’s integrated ringing
tones can be selected in Phone settings
Sounds and volumeRing signalRing
signal 1,2,3....
NOTE
The connected cell phone’s ring tone is not
switched off when one of the hands-free
system's ringing tones is used.
If you prefer to use the connected cell phone’s
ring tone1, go to Phone settingsSounds
and volume
Ring signalUse mobile
phone signal
More information about registering
and connecting cell phones
A maximum of 5 cell phones can be registered
in the hands-free system. Registration only
needs to be done once for each phone. After
registration, the cell phone no longer needs to
be in sight or searchable. Only one cell phone
can be connected to hands-free at a time.
Phones can be unregistered in Bluetooth
Remove telephone
Automatic connectionWhen the hands-free system is active and the
most recently connected cell phone is within
range, it is detected automatically. When the
1Not supported by all cell phones.

11 Specifications
Fuel, oils, and fluids
11

269 Specifications and capacities
CategorySpecificationCapacity
Fuel tankOctane rating: unleaded gasoline, minimum
octane requirement AKI 87, recommended rat-
ing AKI 91 or above.15.9 US gallons (60 liters)
Engine oil (with filter replacement)See page 271 for information on engine oil
specifications.6.1 US quarts (5.8 liters)
Automatic transmission oilJWS 33098.14 US quarts (7.7 liters)
Manual transmission oilBOT 350 M36-speed: 2.0 US quarts (1.9 liters) – turbo models
CoolantVolvo original coolant/antifreeze (50/50 mix-
ture of water and anti-freeze)10.5 US quarts (10 liters) – models with automatic
transmission
10 US quarts (9.5 liters) – models with manual trans-
mission
Brake fluidDOT 4+ boiling point >536 °F (280 °C), P/N
94374330.63 US quarts (0.6 liters)
Power steering fluidWSS M2C204-A or equivalent1.3 US quarts (1.2 liters) – system and reservoir com-
bined
Washer fluid reservoirUse washer fluid solvent in cold weather con-
ditions.6.8 US quarts (6.5 liters)
Air conditioning systemRefrigerant – R134a1.2 lbs. (530 grams)

12 Index
12
279
fluid..................................................... 217
general information............................. 150
Bulbs
headlights........................................... 221
list of................................................... 274
Bulbs, replacing....................................... 221
C
Capacities, fluids..................................... 269
Capacity weight............................... 182, 267
Catalytic converter, three-way................. 276
CD changer.............................................. 251
CD player................................................. 251
Cell phone, hands-free connection......... 256
Central locking system - remote key....... 118
Chains...................................................... 185
Changing a wheel.................................... 188
Child restraints
recalls and registration......................... 43
Child restraint systems.............................. 35
booster cushions.................................. 41
ISOFIX/LATCH anchors........................ 42Child safety................................................ 33
booster cushions.................................. 41
child restraint systems.......................... 35
Climate system
air distribution....................................... 88
air vents................................................ 84
Electronic Climate Control.................... 85
passenger compartment filter.............. 82
refrigerant.....................................82, 269
Climate system, general information......... 82
Clock
setting................................................... 75
Coat hanger............................................. 109
Cold weather precautions........................ 137
Compact disc care..................................253
Compass in rearview mirror....................... 72
Conserving electrical current................... 138
Convertible top (Power retractable hard
top)........................................................... 100
Coolant.................................................... 269
changing............................................. 216
checking level of................................. 216
Courtesy lighting...................................... 106
Crash mode............................................... 32
Cruise control............................................ 65Cup holders.....................................108, 111
Curb weight.....................................182, 267
D
Detachable key blade.............................. 120
Detachable trailer hitch............................ 160
Dimensions.............................................. 266
Disconnecting the front passenger’s air-
bag............................................................. 26
Display.......................................................56
Dolby Pro Logic II (DPL II)........................ 241
Door mirrors............................................... 73
Door Mounted Inflatable Curtain system
(DMIC)........................................................ 30
Driving economically................................ 136
Driving through water..............................136
DSTC, stability system............................ 152
E
Economical driving.................................. 136
Electrical current – conserving................ 138

12 Index
12
283
Seat belt
reminder................................................ 20
Seat belts................................................... 18
Automatic locking retractor/Emergency
locking retractor.................................... 34
buckling................................................ 18
guides...................................................19
maintenance......................................... 20
pretensioners........................................ 18
unbuckling............................................ 18
use during pregnancy........................... 19
Seats, front................................................ 92
Shiftlock
override............................................... 149
Side door mirrors....................................... 73
Side impact airbags................................... 29
Side impact protection (SIPS) airbags....... 29
Sirius satellite radio.................................. 247
Ski hatch.................................................. 115
Snow chains............................................ 185
Snow tires................................................ 185
Sound control, automatic........................242
Sound settings, audio system................. 240
Spare tire................................................. 186Stability system....................................... 152
Dynamic Stability Traction Control
(DSTC)................................................ 152
Starting the engine..................................143
with keyless drive...............................145
Start inhibitor (immobilizer)..............118, 143
STC, stability system............................... 152
Steering wheel
adjusting............................................... 69
keypad................................................ 239
Storage compartments............................ 108
Studded tires........................................... 185
Subwoofer............................................... 241
Supplemental restraint system.................. 21
T
Tachometer................................................ 49
Temporary spare tire............................... 186
Three-way catalytic converter................. 276
Tire inflation............................................. 175
Tire inflation pressure
Canadian models................................ 178
US models.......................................... 177Tire Pressure Monitoring System (TPMS) 195
Tires.........................................................172
age...................................................... 172
changing............................................. 188
changing from summer to winter........ 173
designations....................................... 179
glossary of terms................................ 181
improving economy............................ 172
inflation............................................... 175
inflation pressure, checking................ 176
inflation pressure table, Canadian mod-
els....................................................... 178
inflation pressure table, US models.... 177
load ratings......................................... 176
rotation............................................... 173
snow...................................................185
spare................................................... 186
speed ratings...................................... 176
storing................................................. 173
studded............................................... 185
tire pressure monitoring system......... 195
tire sealing system.............................. 190
tread wear indicator............................ 174
uniform tire quality grading................. 184
winter driving...................................... 185
Tire sealing system.................................. 190
