engine VOLVO S60 2009 Owner´s Manual

Contents
7
09
09 Maintenance and servicingVolvo service........................................... 184
Maintaining your vehicle......................... 185
Emission inspection readiness............... 186
Working on your vehicle......................... 187
Hood and engine compartment.............. 189
Engine oil................................................ 190
Fluids....................................................... 192
Wiper blades........................................... 194
Battery..................................................... 195
Replacing bulbs...................................... 198
Fuses....................................................... 206
10
10 AudioIntroduction............................................. 216
Audio system HU-650 - overview........... 217
Audio system HU-850 - overview........... 218
Radio functions HU-650/HU-850............ 219
RBDS functions HU-650/HU-850........... 223
HU-650 - CD player................................ 226
HU-850 - internal CD changer................ 227
External CD changer (option).................. 228
Dolby Surround Pro Logic II - HU-850
only.........................................................229
Audio systems - specifications...............230
11
11 SpecificationsLabel information.................................... 234
Dimensions............................................ 236
Weights ..................................................238
Capacities............................................... 240
Engine specifications.............................. 242
Bulbs....................................................... 243
Electrical system..................................... 244
Three-way catalytic converter................. 245
Suspension............................................. 246
Volvo programs....................................... 247

IntroductionGeneral information
10
ShiftlockWhen your vehicle is parked, the gear selector
is locked in the (P)ark position. To release the
selector from this position, turn the ignition key
to position II (or start the engine), depress the
brake pedal, press the button on the front side
of the gear selector and move the selector from
(P)ark.Keylock (automatic transmission)When you switch off the ignition, the gear
selector must be in the (P)ark position before
the key can be removed from the ignition
switch.Anti-lock Brake System (ABS)The ABS system in your vehicle performs a
self-diagnostic test when the vehicle first rea-
ches the speed of approximately 12 mph
(20 km/h). The brake pedal will pulsate several
times and a sound may be audible from the
ABS control module. This is normal.Fuel filler doorPress the button on the light switch panel when
the car is at a standstill to open the fuel filler
door.Fuel filler capThe fuel filler door, located on the right rear
fender, is connected to your vehicle's central
locking system.Press the button on the light switch panel (see
illustration see page 59) when the vehicle is
at a standstill to unlock the fuel filler door.
Please note that the fuel filler door will remain
unlocked until the vehicle begins to move for-
ward. An audible click will be heard when the
fuel filler door relocks.
Points to keep in mind•
Before you operate your vehicle for the first
time, please familiarize yourself with the
new-engine oil consumption information
see page 191. You should also be familiar
with the information in chapters one, two
and eight of this manual.
•
Information contained in the balance of the
manual is extremely useful and should be
read after operating the vehicle for the first
time.
•
The manual is structured so that it can be
used for reference. For this reason, it
should be kept in the vehicle for ready
access.
•
Do not export your Volvo to another coun-
try before investigating that country's
applicable safety and exhaust emission
requirements. In some cases it may be dif-
ficult or impossible to comply with these
requirements. Modifications to the emis-
sion control system(s) may render your
Volvo not certifiable for legal operation in
the U.S., Canada and other countries.
•
All information, illustrations and specifica-
tions contained in this manual are based on
the latest product information available at
the time of publication. Please note that
some vehicles may be equipped differ-
ently, depending on special legal require-
ments. Optional equipment described in
this manual may not be available in all mar-
kets.
•
Volvo reserves the right to make model
changes at any time, or to change specifi-
cations or design without notice and with-
out incurring obligation.WARNING
If your vehicle is involved in an accident,
unseen damage may affect its drivability
and safety.

Introduction
Volvo and the environment
11
WARNING
CALIFORNIA proposition 65
Engine exhaust, some of its constituents,
and certain vehicle components contain or
emit chemicals known to the state of Cali-
fornia to cause cancer, and birth defects or
other reproductive harm. In addition, certain
fluids contained in vehicles and certain
products of component wear contain or
emit chemicals known to the State of Cali-
fornia to cause cancer, and birth defects or
other reproductive harm.Volvo is committed to the well being of its cus-
tomers. As a natural part of this commitment,
we care about the environment in which we all
live. Caring for the environment means an
everyday involvement in reducing our environ-
mental impact. Volvo's environmental activities
are based on a holistic view, which means we
consider the overall environmental impact of a
product throughout its complete life cycle. In
this context, design, production, product use,
and recycling are all important considerations.
In production, Volvo has partly or completely
phased out several chemicals including CFCs,
lead chromates, asbestos, and cadmium; and
reduced the number of chemicals used in our
plants 50% since 1991.
Volvo was the first in the world to introduce into
production a three-way catalytic converter witha Lambda sond, now called the heated oxygen
sensor, in 1976. The current version of this
highly efficient system reduces emissions of
harmful substances (CO, HC, NOx) from the
exhaust pipe by approximately 95-99% and
the search to eliminate the remaining emis-
sions continues. Volvo is the only automobile
manufacturer to offer CFC-free retrofit kits for
the air conditioning system of all models as far
back as the 1975 model 240. Advanced elec-
tronic engine controls and cleaner fuels are
bringing us closer to our goal. After Volvo vehi-
cles and parts have fulfilled their use, recycling
is the next critical step in completing the life
cycle. The metal content is about 75% of the
total weight of a vehicle, which makes the vehi-
cle among the most recycled industrial prod-
ucts. In order to have efficient and well-
controlled recycling, dismantling information is
available for all Volvo models. For Volvo, all
homogeneous plastic parts weighing more
than 3.4 oz. (100 grams) are marked with inter-
national symbols that indicate how the com-
ponent is to be sorted for recycling. In addition
to continuous environmental refinement of
conventional gasoline-powered internal com-
bustion engines, Volvo is actively looking at
advanced technology alternative-fuel vehicles.
When you drive a Volvo, you become our part-
ner in the work to lessen the car's impact onthe environment. To reduce your vehicle's
environmental impact, you can:
•
Maintain proper air pressure in your tires.
Tests have shown decreased fuel econ-
omy with improperly inflated tires.
•
Follow the recommended maintenance
schedule in your Warranty and Service
Records Information booklet.
•
Drive at a constant speed whenever pos-
sible.
•
See a trained and qualified Volvo service
technician as soon as possible for inspec-
tion if the check engine (malfunction indi-
cator) light illuminates, or stays on after the
vehicle has started.
•
Properly dispose of any vehicle-related
waste such as used motor oil, used batter-
ies, brake pads, etc.
•
When cleaning your vehicle, please use
genuine Volvo car care products. All Volvo
car care products are formulated to be
environmentally friendly.
For additional information regarding the envi-
ronmental activities in which Volvo Cars of
North America, LLC and Volvo Car Corporation
are involved, visit our Internet home page at:
http://www.volvocars.us.

01 SafetySupplemental Restraint System
0120
Supplemental Restraint System (SRS)
G027284
SRS warning lightAs an enhancement to the three-point seat
belts, your Volvo is equipped with a Supple-
mental Restraint System (SRS). Volvo's SRS
consists of seat belt pretensioners, front air-
bags, side impact airbags, the occupant
weight sensor, and inflatable curtains. All of
these systems are monitored by the SRS con-
trol module. An SRS warning light in the instru-
ment panel (see the illustration) illuminates
when the ignition key is turned to position I,
II, or III, and will normally go out after approx-
imately 7 seconds if no faults are detected in
the system.Where applicable, a text message will also be
displayed when the SRS warning light illumi-
nates. If this warning symbol is not functioning
properly, the general warning symbol
illuminates and a text message will
be displayed.
WARNING
•
If the SRS warning light stays on after
the engine has started or if it illuminates
while you are driving, have the vehicle
inspected by a trained and qualified
Volvo service technician as soon as
possible.
•
Never try to repair any component or
part of the SRS yourself. Any interfer-
ence in the system could cause mal-
function and serious injury. All work on
these systems should be performed by
a trained and qualified Volvo service
technician.
WARNING
If your vehicle has been subjected to flood
conditions (e.g. soaked carpeting/standing
water on the floor of the vehicle) or if your
vehicle has become flood-damaged in any
way, do not attempt to start the vehicle or
put the key in the ignition before discon-
necting the battery. This may cause airbag
deployment which could result in personal
injury. Have the vehicle towed to a trained
and qualified Volvo service technician for
repairs.
Automatic transmission:
Before attempting to tow the vehicle, use
the following procedure to override the
shiftlock system to move the gear selector
to the neutral position:•
Switch off the ignition for at least
10 minutes and disconnect the battery
•
Wait at least one minute.
•
Insert the key in the ignition and turn it
to position II.
•
Press firmly on the brake pedal.
•
Move the gear selector from (P)ark to
the (N)eutral position.

02 Instruments and controlsInstrument panel
0250
Instrument panel
G027133
Turn signal indicators – right/leftText window – The text window displays
information and warning messages.Temperature gauge – The pointer should
be approximately midway on the gauge
when driving. Do not drive the vehicle if
the warning light is on. The text window
will provide you with additional informa-
tion. If the engine temperature remains
high, check coolant level – see page 192.Trip odometer – The trip odometers are
used for measuring shorter distances. The
right-hand digit gives tenth of a mile/kilo-
meter. Press the button for more than
2 seconds to reset. Change between tripodometers 1 and 2 using one short press
on the button. – The display presents infor-
mation and warning messages, the ambi-
ent temperature, and the clock, etc. When
the ambient temperature is between 23°
and 36 °F (–5° and +2 °C), a snowflake
symbol is shown in the display. This sym-
bol serves as a warning for possible slip-
pery road surfaces. Please note that this
symbol does not indicate a fault with your
car. At low speeds, or when the car is not
moving, the temperature readings may be
slightly higher than the actual ambient tem-
perature.
Odometer
SpeedometerWarning symbolHigh beam indicatorTachometer – The tachometer shows
engine speed in thousands of revolutions
per minute (rpm). Do not drive continuously
with the needle in the red area of the dial,
which indicates maximum allowable
engine rpm range. Instead, shift to a higher
gear or slow the vehicle down. The engine
management system will automatically
prevent excessively high engines speeds.
This will be noticeable as a pronounced
unevenness in engine speed.

02 Instruments and controls
Instrument panel
0251
Gear and driving mode indicator – The cur-
rently selected driving mode is displayed
here. If you use the Geartronic function on
the automatic transmission, the currently
selected gear will be displayed.Ambient temperature gauge – This display
indicates the air temperature outside your
vehicle. A "snowflake" symbol in the text
window is displayed when the temperature
is in the range of 23 – 36 °F (–5 – +2 °C).
Please note that this symbol does not indi-
cate a fault with your vehicle. At low
speeds or when the vehicle is not moving,
the temperature readings may be slightly
higher than the actual ambient tempera-
ture.Clock/set button – Turn the button to set
the clock.Fuel gauge - see page 240 for more infor-
mation on fuel tank volume. When the
warning light in the gauge comes on, the
vehicle should be refueled as soon as pos-
sible. The Trip computer section (see
page 67) provides more information on
fuel level and consumption.Indicator and warning symbols – The indi-
cator and warning symbols
1light up when
you turn the ignition key to the driving posi-
tion (position II) before starting.
1On certain engines, the symbol for low oilpressure is not used. Instead, a text warning is provided in the information display.

02 Instruments and controlsIndicator and warning symbols
0252
Warning symbol in the center of the
instrument panel
This symbol shines as a red or yel-
low light depending on the severity
of the discovered fault.
Red symbol - Stop the vehicle as soon as pos-
sible in a suitable location and read the mes-
sage shown in the text window. The symbol
and accompanying text will remain on until the
fault has been corrected.
Yellow symbol - Follow the instructions shown
in the text window. The text can be erased by
pressing the READ button, see page 71, or
will disappear automatically after two minutes.
When the message "
TIME FOR REGULAR
SERVICE
" is displayed, the text can be erased
and the yellow symbol light can be turned off
by pressing the READ button. The text will dis-
appear and the symbol light will go out auto-
matically after two minutes.
Symbols in the instrument panel
G027134
The indicator and warning symbols
1 light up
when you turn the ignition key to the driving
position (position II) before starting. This shows
that the symbols are functioning. When the
engine starts, all symbols go out. If the engine
is not started within 5 seconds, all symbols
exceptCHECK ENGINE and
go
out. Certain symbols may not have their func-
tions illustrated, depending on the vehicle's
equipment. The symbol for the parking brake
goes out when the parking brake is released.
Seat belt reminder
This symbol lights up to indicate
that the driver has not fastened his/
her seat belt.
Supplemental Restraint System SRS
If this light comes on while the
vehicle is being driven, or remains
on for longer than approximately
10 seconds after the vehicle has
been started, the SRS system's
diagnostic functions have detected a fault in a
seat belt lock or pretensioner, a front airbag,
side impact airbag, and/or an inflatable curtain.
Have the system(s) inspected by a trained and
qualified Volvo service technician as soon as
possible.
BRAKE - Brake failure warning lightIf the light comes on while driving or braking,
stop immediately, open the hood and check
the brake fluid level in the reservoir, see
page 193.
Canadian models are equipped
with this warning light.
1On certain engines, the symbol for low oil pressure is not used. Instead, a text warning is provided in the information display.

02 Instruments and controls
Indicator and warning symbols
02``53
If the BRAKE and ABS warning lights come
on at the same time, this could indicate a
fault in the brake system.
1. Stop the vehicle in a suitable place and
switch off the engine.
2. Restart the engine.
3. If both warning lights go off, no further
action is required.
4. If both lights are still on after the engine has
been restarted, switch off the engine again
and check the brake fluid level (see
page 193 for the location of the brake fluid
reservoir).
5.
If the brake fluid level is above the MIN
mark, drive carefully to a trained and quali-
fied Volvo service technician and have the
brake system inspected.
WARNING
If the fluid level is below the MIN mark in the
reservoir or if a "
Brake failure - Service
urgent
" message is displayed in the text
window:DO NOT DRIVE. Have the vehicle
towed to a trained and qualified Volvo serv-
ice technician and have the brake system
inspected.
PARK BRAKE - Parking brake appliedThis light will be on when the parking brake
(hand brake) is applied. The parking brake lever
is situated between the front seats. For addi-
tional information, see page 71.
Canadian models are equipped
with this symbol.Low oil pressure
2
If the light comes on while driving,
stop the vehicle and then stop the
engine immediately and check the
engine oil level, see page 191.
If the light stays on after restart, have the vehi-
cle towed to the nearest trained and qualified
Volvo service technician. After hard driving, the
light may come on occasionally when the
engine is idling. This is normal, provided it goes
off when the engine speed is increased.Generator warning light
If the light comes on while the
engine is running, have the charg-
ing system checked.
Rear fog light
This light indicates that the fog
light is on.
CHECK ENGINE - Malfunction indicator
lightOn-Board Diagnostics II (OBDII): As you drive,
a computer called "OBDII" monitors your vehi-
cle's engine, transmission, electrical and emis-
sion systems. The CHECK ENGINE light will
light up if the computer senses a condition that
potentially may need correcting. When this
happens, please have your vehicle checked by
a trained and qualified Volvo service technician
as soon as possible.
ACHECK ENGINE light may have many cau-
ses. Sometimes, you may not notice a change
in your vehicle's behavior. Even so, an uncor-
rected condition could hurt fuel economy,
emission cleanliness, and driveability.
Extended driving without correcting the cause
could even damage other components in your
vehicle.
Canadian models are equipped
with this warning light.
2On certain engines, the symbol for low oil pressure is not used. Instead, a text warning is provided in the information display.

02 Instruments and controls
Indicator and warning symbols
0255
Message
Meaning
STOP SAFELY
Stop the car in a safe place and switch off the engine to help prevent the risk of serious
damage.
STOP ENGINE
Stop the car in a safe place and switch off the engine to help prevent the risk of serious
damage.
SERVICE URGENT
Take your vehicle to a trained and qualified Volvo service technician for inspection immedi-
ately.
SEE MANUAL
Refer to your owner's manual. For additional information, please contact your Volvo retailer.
SERVICE REQUIRED
Take your vehicle to a trained and qualified Volvo service technician for inspection at your
convenience (but preferably before the next scheduled maintenance service).
FIX NEXT SERVICE
Have the system affected inspected at the next scheduled maintenance service.
TIME FOR REGULAR SERVICE
This message will be displayed at 7,500 mile (12,000 km) intervals, after 750 hours of driving
or after 12 months, whichever occurs first, to remind the driver that the service interval has
been exceeded. The message will be displayed for 2 minutes each time the vehicle is started
until reset by a trained and qualified Volvo service technician.
OIL LEVEL LOW - FILL OIL
Check the oil level and top up if necessary. See page 191.
OIL LEVEL LOW - STOP SAFELY
Stop as soon as possible and switch off the engine, check the oil level and top up if necessary.
see page 191.
OIL LEVEL LOW - STOP ENGINE
Stop as soon as possible and switch off the engine, check the oil level and top up if necessary,
see page 191.
OIL LEVEL LOW - SEE MANUAL
Stop as soon as possible and switch off the engine, check the oil level and top up if necessary,
see page 191.
DSTC SPIN CONTROL OFF
The stability system's spin control function has been turned off. See page 138 for details.

02 Instruments and controlsButtons in the center console
0256
G027194
The positions of these button may vary, depending on the specifications of the vehicle.Folding head restraints
This button is used to fold down
the outboard rear head
restraints. The ignition key must
be in position I or II or the
engine must be running.
NOTE
If the head restraints have been folded
down, they must be returned to their original
position manually. The head restraints
should be in the upright position before the
rear seat backrests are folded down.
WARNING
For safety reasons, no one should be
allowed to sit in the outboard rear seat posi-
tions if the head restraints are folded down.
If these positions are occupied, the head
restraints should be in the upright (fixed)
position.
Valet lock (trunk lock)
Pressing this button locks the
trunk, even if the doors are
unlocked. The trunk will remain
locked even if the doors are
locked/unlocked using the
master key or the remote con-
trol.
To use this function:
1.
Turn the master key to position II.
2. Press the "Valet lock" button. An LED in the
button will light up and "
VALET LOCK
ON
" will be displayed in the text window to
indicate that this function is activated.
