02 Instruments and controlsLighting panel
0260
Fog lightsFront fog lights (option)The front fog lights can be used in combination
with either the headlights or the parking lights.•
Turn the ignition key to position II.
•
Press button 2 to turn on the front fog
lights.
An indicator light in the button illuminates when
the front fog lights are on.
Rear fog lightThe single rear fog light is located in the driver's
side tail light cluster.
The rear fog light will only function in combi-
nation with the high/low beam headlights or the
optional front fog lights.•
Turn the ignition key to position II.
•
Press button 3 to turn on the rear fog light.
An indicator light in the button illuminates when
the rear fog light is on.NOTE
The rear fog light is considerably brighter
than the normal taillights and should be
used only when conditions such as fog, rain,
snow, smoke or dust reduce visibility for
other vehicles to less than 500 ft.
(150 meters).
Instrument panel lightingThe instrument panel lighting illuminates when
the ignition key is in position IIand the light
switch (1) is in either position
or
.
•
Move the thumb wheel (4) up to increase
brightness or down to decrease bright-
ness.
Unlocking the fuel filler doorPress button 5 when the vehicle is at a stand-
still to unlock the fuel filler door. Please note
that the fuel filler door will remain unlocked until
the vehicle begins to move forward. An audible
click will be heard when the fuel filler door
relocks.
NOTE
If the fuel filler door does not unlock after the
button has been pressed, drive the vehicle
at a speed of at least 5 mph (8 km/h), stop
the vehicle, and press the button again.See page 61 for information on unlocking the
fuel filler door manually.
