10 Specifications
Specifications
10
386
Specification/ Model5-cyl.3.0T2.0 4-cyl. T92.0 4-cyl. T102.0 4-cyl. T112.0 4-cyl. T12
Torque (Nm/rps)360/30-70440/35 – 70400/35–75400/35–75350/1500-4500350/1500-4500
Torque (ft. lbs./ rpm)266/1800-4200325/2100 – 4200295/2100–4500295/2100–4500258/1500–4500258/1500–4500
No. of cylinders564444
Bore (in/mm)3.27/833.23/823.27/823.27/823.27/823.27/82
Stroke (in/mm)3.63/92.33.67/93.23.63/93.23.63/93.23.63/93.23.63/93.2
Displacement2.497 liters / (152.4 cu. in.)2.95 liters (175 cu. in.)1.97 liters (120.2 cu. in.)1.97 liters (120.2 cu. in.)1.97 liters (120.2 cu. in.)1.97 liters (120.2 cu. in.)
Compression ratio9.5:19.3:110.3:110.3:110.8:110.8:1
Oil specifications
Full synthetic engine oil meeting the minimum ACEA A5/B5 must be used. Lower quality oilsmay not offer the same fuel economy, engineperformance, or engine protection. Volvo recommends:
Refer to the warranty and Service Records information booklet for information on oilchange intervals and oil type requirements.
NOTE
This vehicle comes from the factory with synthetic oil.
Oil additives must not be used.
Oil viscosityIncorrect viscosity oil can shorten engine life under normal use. SAE 5W-30 will provide
