VOLVO S90 T8 2019 Sensus Navigation Manual

NAVIGATION
* Option/accessory.9
Navigation system * in head-up
display*
The navigation system can be presented and controlled in several different ways, e.g. via thehead-up display.
Navigation system in windshield.
The driver can also get guidance and information from the navigation system in the head-up dis-play on the lower section of the windshield. You can make settings to specify if the naviga- tion system should be shown in the head-up dis-play, as well as the position of the informationfield.
Related information
 Navigation system
* in center display (p. 6)
 Navigation system
* in the instrument panel
(p. 8)
Voice control3 for navigation
system *
Several of the navigation system's functions can be activated with voice commands.
Tap on the right-side steering wheel keypad
and say one of the following commands:  "
Navigation" - Starts a navigation dialog
and displays examples of commands.
 "
Take me home" - Guidance is provided to
the location set as Home.
 "
Go to [city]" - Inputs a city as a destination,
e.g. "Go to San Francisco".
 "
Go to [address]" - Inputs an address as a
destination. An address must contain city and street. e.g. "Go to Filbert Street 5, San Fran-cisco".
 "
Add intersection" - Starts a dialog to input
two streets. The destination will then be the intersection of these two streets.
 "
Go to [zip code]" - Input a zip code as the
destination. e.g. "Go to 1 2 3 4 5".
 "
Go to [contact]" - Input an address from
the phone book as the destination. Example "Go to Robyn Smith".
 "
Search [POI category]" - Search Points
of Interest (POI) in a certain category (e.g. restaurants) 4
. To sort the list along the route,
say "
Along the route" when the list of
results is displayed.
"
Search [POI category] i [city]" -
Searches for POIs in a certain category and city. The list of results is sorted based on thecenter point of the city. Example "Look forrestaurant in San Francisco".
 "
Search [POI name]". For example,
"Search Golden Gate Bridge".
 "
Change country/Change state5,6
" -
Changes the search area for navigation.
 "
Show favorites" - Displays locations
marked as favorites in the instrument panel.
 "
Clear itinerary" - Deletes all stored way-
points and destinations in an itinerary.
 "
Repeat voice guidance" - Repeats the
most recent guidance instruction.
 "
Turn off voice guidance" - Guidance off.
 "
Turn on voice guidance" - Guidance on.

NAVIGATION
* Option/accessory.
10
Entering a destination directly onthe map
A destination can be specified in different ways in the navigation system * – tapping a point on
the map with your finger is one of them.
It is often easiest to scroll to the desired position on the map and tap it.
1. Make sure the map is in full-screen mode.
2. Scroll to the desired location on the map.
3. Press and hold the location. An icon will be created and a menu will appear.
4. Select
Go here to start guidance.
Deleting the icon
To delete the location's icon:
 Select
Delete
Changing the icon's location
To change the location of the icon:
 Press and hold the icon, drag it to the desired location and then release it.
Related information

Itinerary (p. 15)
 Entering a destination using an address(p. 10)
Entering a destination with a free text search(p. 11)
 Entering a POI as a destination (p. 12)
 Entering a destination using Recent/Favor-ites/Library (p. 13)
 Entering a destination with Send to Car(p. 14)
 Route settings and guidance (p. 22)
Entering a destination using anaddress
There are several ways to set a destination in the navigation system *. Entering an address is one
of them.
1. When the map appears, expand the toolbar using the down arrow on the left-hand side and tap
Set dest.
> The map will switch to free text search.
2. Tap
Address.
3. It is not necessary to fill in all of the fields. For guidance to a city, for example, you only need to fill in the city and country. You willthen be guided to the center of the city.
4. Select any available field and use the center display's keyboard to type:

Country/State/Province
City/Territory/Zip code
Address
Number
Junction
3 Certain markets only.
4 The user can choose to call the POI or enter it as a destination.
5 For European countries, "country" is used instead of "state".
6 For Brazil and India, search area is changed in the center display.

NAVIGATION
}}
* Option/accessory.11
For vehicles with Volvo On Call
*, it is also possi-
ble to send addresses and destinations to the vehicle's navigation system via the Volvo On Callapp.
Related information
 Itinerary (p. 15)
 Entering a destination directly on the map(p. 10)
 Entering a destination with a free text search(p. 11)
 Entering a POI as a destination (p. 12)
 Entering a destination using Recent/Favor-ites/Library (p. 13)
 Entering a destination with Send to Car(p. 14)
 Route settings and guidance (p. 22)
 Information cards in the navigation system
*
(p. 6)
Entering a destination with a freetext search
A destination can be set in different ways in the navigation system * - with free text searching, for
example, a search can be made using phone numbers, postal codes, streets, cities, coordi- nates and points of interest (POI 7
).
The on-screen keyboard can be used to type most characters and to search for destinations.
1. When the map appears, expand the toolbar
using the down arrow on the left-hand side and tap
Set dest.
> The map will switch to free text search.
2. Enter a search word in the search box or limit the search results by choosing a filter.
> The search results will be listed as youtype. 3.
If the search provided the desired result -
tap a search result to display its information card and select to continue using the searchresult. If the search provided too many results -
tap
Advanced filter to select a position to
search around and then select a search result to continue using it.

Around vehicle
Around destination – only displayed if a
destination has been set.

Along route – only displayed if a destina-
tion has been set.

Around point on map
7 Point of Interest

||
NAVIGATION
* Option/accessory.
12
Coordinates
A destination can also be entered using map coordinates.
 Enter coordinates, e.g. "N 58.1234 E 12.5678" and tap
Search.
Compass directions N, E , S and W can be
entered in different ways, e.g.:
N 58,1234 E 12,5678 (with space)
N 58,1234 E12,5678 (without space)
58,1234 N 12,5678 E (with compass direc-
tions after the coordinates)
58,1234-12,5678 (with hyphen without com-
pass direction)
Either a dot [.] or a comma [,] can be used.
Related information
 Itinerary (p. 15)
 Entering a destination directly on the map (p. 10)
 Entering a destination using an address(p. 10)
 Entering a POI as a destination (p. 12)
 Entering a destination using Recent/Favor-ites/Library (p. 13)
 Entering a destination with Send to Car(p. 14)
 Route settings and guidance (p. 22)
Entering a POI as a destination
A destination can be specified in different ways in the navigation system * - selecting a point of
interest (POI 8
) is one of them.
1. When the map appears, expand the toolbar
using the down arrow on the left-hand side and tap
Set dest.
> The map will switch to free text search.
2. Tap
POI.
3. Tap the desired filter (some alternatives are only shown when a destination or waypoint is specified):

Near the vehicle
Near the destination
Near waypoint
Along route
Around point on map
4. Scroll to the desired POI and select it. 5. Select
Start navigation or Add as
waypoint.
Many POI (e.g. restaurants) have sub-categories (e.g. fast food). Which POI are shown on the map can bechanged via the map settings. This setting doesnot affect searches for POI to be used as desti-nations (even POI that have not been selectedfor display can be shown here as alternate desti-nations). Certain POI will only appear on the map if the scale is greater than 1 km (1 mile).
NOTE

The symbols, number and variants of POIs vary between different markets.
 In connection with map data updating,some symbols may be added and othersdisappear – all symbols for the map sys-tem in question can be found through themenu system.
Related information
Itinerary (p. 15)
 Entering a destination directly on the map (p. 10)
 Entering a destination using an address(p. 10)
 Entering a destination with a free text search(p. 11)
 Entering a destination using Recent/Favor-ites/Library (p. 13)

NAVIGATION
}}
* Option/accessory.13

Entering a destination with Send to Car (p. 14)
 Map settings (p. 21)
Entering a destination usingRecent/Favorites/Library
A destination can be specified in different ways in the navigation system * - selecting from a list is
one of them.
1. When the map appears, expand the toolbar using the down arrow on the left-hand side and tap
Set dest.
> The map will switch to free text search.
2. Select one of these lists at the top of the screen:

Recent
Favorites
Library
After an option in a list has been marked, it can be added as a destination by tapping either the
Start navigation or Add as waypoint button.
Recent
This is a list of previous searches. Scroll through the list and select. This is also available as a menu option in the instrument panel and can be displayed using theright-side steering wheel keypad. To edit the list, tap
Edit.
Favorites
This is a list of locations that have been set as favorites from the Library. Scroll through the list
and select. A position that has been deleted in
Favorites will
remain in Library, but with a grayed-out star. To
return a position to Favorites, go to Library and
mark the position's star again. Use
Set Home address to program a fre-
quently used destination. An entered Home des-
tination is also available as a menu option in the instrument panel and can be displayed using theright-side steering wheel keypad. To edit the list, tap
Edit.
8 Point of Interest

||
NAVIGATION
* Option/accessory.
14
Library
This is a list of saved locations and itineraries. The most recently saved will be shown at the topof the list. Tap the location's star to select/deselect it as a favorite. A location with a selected (filled in) star will also be displayed under the
Favorites head-
ing. If a location is deleted in
Library, it will also be
deleted in Favorites.
The Library can be sorted in various ways:
Added - sort in chronological order.

Name - sort in alphabetical order.

Distance - sort according to distance from
the vehicle's current location.

Received - locations sent to the vehicle
using the Send to Car function will be filtered out. New unread locations have a BLUEmarker that is grayed out once the positionshave been read.
Use
Edit to delete one or more items in the list.
Related information
 Itinerary (p. 15)
 Entering a destination directly on the map (p. 10)
 Entering a destination using an address (p. 10)
Entering a destination with a free text search(p. 11)
 Entering a POI as a destination (p. 12)
 Entering a destination with Send to Car(p. 14)
 Route settings and guidance (p. 22)
Entering a destination with Send toCar
A destination can be specified in different ways in the navigation system * – using the Send to
Car function is one of them.
Sending a location to the vehicleSend to Car is a function that makes it possible to add a destination/location to the vehicle's nav-igation system from a computer. Send to Car can also be performed using the Volvo On Call app. Volvo On Call can also beused to send a destination/location to the vehiclefrom a Volvo On Call customer service center. Please note that the procedure shown here is only one example from one of several map serv-ice providers.
1. Go to wego.here.com on the computer.
> A map service will open.
2. Search for the desired location.
3. Right-click the location and then click the address.
> A side menu/information card will open.
4. Click Share in the side menu.
5. Click Send to car in the side menu.
6. Select the vehicle and enter the vehicle's VIN number or the email address registered to your Volvo ID. Then click Send.

NAVIGATION
* Option/accessory.15
7.
Click Finish .
> The location will be sent to the vehicle.
For more information about other service provid- ers and the Send to Car function, please visit theVolvo Cars support site (support.volvocars.com).
Receiving and using a location in the vehicle
In order for the vehicle to receive data, it must beconnected to the Internet. If the location was sentto the vehicle using Volvo On Call, the vehicle'sintegrated modem will be used to receive thedata, i.e. no other Internet connection is required.
1. When the vehicle has received a location, a notification will appear in the center display. Tap the notification/symbol.
> An information card will open.
2. Select how you would like to use the loca- tion.
Using a stored location
Received locations are saved in the navigation system's library for later use.
Related information
 Itinerary (p. 15)
 Entering a destination directly on the map(p. 10)
 Entering a destination using an address(p. 10)
Entering a destination with a free text search(p. 11)
 Entering a POI as a destination (p. 12)
 Entering a destination using Recent/Favor-ites/Library (p. 13)
 Route settings and guidance (p. 22)
Itinerary
The itinerary is the route that the navigation sys- tem * suggests when the user enters a destina-
tion.
The first location set will be the itinerary's desti-
nation (final destination).
The next locations set will be the itinerary's way-
points (intermediate stops along the route).
An itinerary and its destination and waypoints can be easily edited at any time.
Related information
 Viewing an itinerary (p. 16)
 Editing or clearing an itinerary (p. 16)
 Viewing alternative routes (p. 17)
 Show guidance in the itinerary (p. 18)

NAVIGATION
* Option/accessory.
16
Viewing an itinerary
It is possible to show the itinerary in the naviga- tion system * during road navigation.
1. During guidance, expand the toolbar using
the down arrow and then the three dots. 2.
Tap the Itinerary symbol to open the itiner-
ary.
Related information
 Editing or clearing an itinerary (p. 16)
 Viewing alternative routes (p. 17)
 Show guidance in the itinerary (p. 18)
Editing or clearing an itinerary
It is possible to remove waypoints or the entire itinerary in the navigation system * while guidance
is being provided.
1. Expand the toolbar using the down arrow first and then the three dots.
2.
Tap the Itinerary symbol to open the itiner-
ary.
3. Tap the recycling bin to delete a waypoint from the itinerary or tap
Clear itinerary to
delete the entire itinerary.
Related information
 Viewing alternative routes (p. 17)
 Viewing points of interest along the route (p. 17)
 Show guidance in the itinerary (p. 18)

NAVIGATION
* Option/accessory.17
Viewing alternative routes
It is possible to search for alternate routes in the navigation system * while guidance is being pro-
vided.
1. Expand the toolbar using the down arrow first and then the three dots.
2.
Tap the Itinerary symbol to open the itiner-
ary.
3. Tap
Alternative routes.
4. Select an alternative route:

Eco
Fast
Scenic
5. Tap the map. > The updated route will be displayed onthe map and guidance will resume.
Related information
 Editing or clearing an itinerary (p. 16)
 Show traffic disruptions along the route (p. 19)
 Selecting a detour in the navigation system
*
(p. 19)
Route settings and guidance (p. 22)
Viewing points of interest along theroute A list of points of interest (POI 9
) along your
route can be displayed in the navigation system *.
1.
Tap Ahead.
2. Tap
POI.
> POIs along the route are displayed according to their distance from the vehi- cle.
3. If there are multiple POIs in the same loca- tion, they will be displayed as a group. Tapthe group for a list of the POIs.
4. Select a POI.
5. Select one of the information card's options and follow the instructions.
Related information
 Information cards in the navigation system
*
(p. 6)
 Map settings (p. 21)

NAVIGATION
* Option/accessory.
18
Show guidance in the itinerary
A list of coming guidance points helps the driver prepare in advance for upcoming maneuvers,e.g. moving into the correct lane before making aturn.
To display a list of upcoming turns in the itinerary in the navigation system *:
1. Expand the toolbar using the down arrow on the left-hand side.
2. Expand the toolbar further using the three dots.
3. Tap the
Turn-by-Turn symbol (see image).
A list of guidance points on the itinerary will be displayed instead of the toolbar (you can scroll through the list). Tap the arrow pointing to the left to minimize the list. The next guidance point is always shown at the top of the list.
Tap one of the guidance points in thelist to show the location on the map.Tap the map's crosshairs (see image)to return to the map guidance view,
where the map shows the vehicle's current loca-tion.
Traffic disruptions on map10
The navigation system * receives information on
traffic events and traffic disruptions and displays these on the map.
NOTE
Traffic information is not available in all areas/countries. Coverage areas for traffic information is con- tinuously extended.
It is possible to make settings to determine which traffic-related information is shown on the map. Traffic disruptions, such as congested and slow- moving traffic, road work and accidents, areshown with different symbols when the map iszoomed in.
Road construction, for example, is indi-cated by this symbol. Sections of roadwith major traffic disruptions are alsoshown with a red line on the side of the
road affected. The line also indicates which direc-tion of traffic is affected. If the disruption affectsboth directions of traffic, the section of road ismarked with red lines on both sides of the road.
Information on traffic disruptions
–Tap the traffic disruption symbol.
> An information card will be displayed. Information may include e.g. the location of the traffic disruption with the streetname/road number and its type/extent/duration.
Avoiding traffic disruptions
If there are traffic disruptions along the route, theAvoid option can be selected. The system will
then calculate an alternate route.
Real Time Traffic Information (RTTI)11
If the vehicle is connected to the Internet, enhanced traffic information can be retrieved using RTTI 12
.
Related information
 Traffic information settings (p. 23)
 Map settings (p. 21)
 Show traffic disruptions along the route (p. 19)
 Real Time Traffic Information (RTTI) (p. 20)
 Information cards in the navigation system
*
(p. 6)
9 Point of Interest
