2 0 0 4
VOLVO
S40 & V40
Chapter 10 - Audio systems
pg. 129 Audio systems
Audio systems
This chapter describes the audio system in your car. Audio system overview
130
Anti-theft code131
Radio - general functions132
Radio - program type135
Radio - Traffic information137
CD player138
CD changer139
Menu structure140
RDS142
Compact disc care143
Technical data144
pg. 130 Audio system overview
ProCarManuals.com
Compact disc care
Before using a new disc for the first time, remove any burrs in the center/outer edge by running the stem of a pen or
similar object around the hole/edge of the disc.
Use high quality discs only.
Keep the discs clean. Wipe them with a soft, clean, lint-free cloth, working from the center outwards. If necessary,
dampen the cloth with a neutral soap solution. Dry thoroughly before using.
Never use cleaning spray or anti-static liquid. Use only cleaners specifically made for CD's.
Use discs of the correct size only
NOTE: Never use 3.5" discs.
Do not put tape or labels on the disc itself.
Volvo does not recommend the use of plastic outer rings on the disc.
Condensation may occur on discs/optical components of the changer in cold winter weather. The disc can be dried
with a clean, lint-free cloth. Optical components in the CD changer may, however, take up to one hour to dry off.
Never attempt to play a disc which is damaged in any way.
When not in use, the discs should be stored in their covers. Avoid storing discs in excessive heat, direct sunlight or
dusty locations.
pg. 144 Technical data
Radio
Frequency: AM 530 - 1710 kHz
FM 87.7 - 107.9 MHz
General
Connections: CD-changer, external amplifier
Output: 4 x 25 W
Impedance: 4 Ohm.
Voltage required: 12 V, negative ground
Speaker options
Level 1, S 40: Base performance: 4 speakers in front only
V 40: Base performance: 4 speakers in front only
Level 2, S 40: Base performance: 6 speakers
V 40: Base performance: 7 speakers
Level 3, S 40: High performance: 6 speakers and external amplifier
V 40: High performance: 7 speakers and external amplifier
