dimensions VOLVO V70/XC70 2010 Owner´s Manual

06 Maintenance and specifications
Wheels and tires
06
252
Consult your Volvo retailer for additional snow
chain information.
CAUTION
•Check local regulations regarding the
use of snow chains before installing.
•Use single-sided snow chains only.
•Always follow the chain manufacturer's
installation instructions carefully. Install
chains as tightly as possible and
retighten periodically.
•Never exceed the chain manufacturer's
specified maximum speed limit. (Under
no circumstances should you exceed
31 mph (50 km/h).
•Avoid bumps, holes or sharp turns
when driving with snow chains.
•The handling of the vehicle can be
adversely affected when driving with
chains. Avoid fast or sharp turns as well
as locked wheel braking.
Snow tires, studded tires2
Tires for winter use:
•Owners who live in or regularly commute
through areas with sustained periods of
snow or icy driving conditions are stronglyadvised to fit suitable winter tires to help
retain the highest degree of traction.
•It is important to install winter tires on all
four wheels to help retain traction during
cornering, braking, and accelerating. Fail-
ure to do so could reduce traction to an
unsafe level or adversely affect handling.
•Do not mix tires of different design as this
could also negatively affect overall tire road
grip.
•Winter tires wear more quickly on dry roads
in warm weather. They should be removed
when the winter driving season has ended.
•Studded tires should be run-in
300 – 600 miles (500 – 1000 km) during
which the vehicle should be driven as
smoothly as possible to give the studs the
opportunity to seat properly in the tires.
The tires should have the same rotational
direction throughout their entire lifetime.
NOTE
Please consult state or provincial regula-
tions restricting the use of studded winter
tires before installing such tires.
Temporary Spare
The spare tire in your vehicle3 is called a "Tem-
porary Spare".
Recommended tire pressure (see the placard
on the B-pillar or on the fuel filler door) should
be maintained irrespective of which position on
the vehicle the temporary spare tire is used on.
In the event of damage to this tire, a new one
can be purchased from your Volvo retailer.
WARNING
Current legislation prohibits the use of the
"Temporary Spare" tire other than as a tem-
porary replacement for a punctured tire. It
must be replaced as soon as possible by a
standard tire. Road holding and handling
may be affected with the "Temporary
Spare" in use. Do not exceed 50 mph
(80 km/h).
CAUTION
The vehicle must not be driven with wheels
of different dimensions or with a spare tire
other than the one that came with the vehi-
cle. The use of different size wheels can
seriously damage your car's transmission.
2Where permitted3Not on models equipped with the Tire sealing system.

06 Maintenance and specifications
Specifications
06
270
Dimensions–V70
V70
PositionDimensionin (mm)
AWheelbase110.9 (2816)
BLength189.9 (4823)
CLoad length, floor, seatback down73.9 (1878)
DLoad length, floor42.9 (1089)
EHeight60.9 (1547)
FLoad height28.5 (724)
GTrack, front62.5 (1588)

06 Maintenance and specifications
Specifications
06
272
Dimensions-XC70
G017405
XC70
PositionDimensionin (mm)
AWheelbase110.8 (2815)
BLength190.5 (4838)
CLoad length, floor, seatback down73.9 (1878)
DLoad length, floor42.9 (1089)
EHeight63.1 (1604)
FLoad height28.5 (724)
GTrack, front63.1 (1604)

07 Index
07
281
introduction......................................... 222
license plate lights.............................. 227
side marker lights...............................225
specifications...................................... 228
taillight................................................ 226
C
Capacity weight....................................... 249
Cargo area
changing bulbs................................... 227
floor rails............................................. 202
hooks for securing loads.................... 202
steel grid............................................. 205
Cargo area cover..................................... 206
Cargo area net......................................... 206
Catalytic converter................................... 199
CD player/changer................................... 142
Cell phone, hands-free connection......... 145
Central locking system, introduction......... 52
Chains...................................................... 251
Check engine light..................................... 72
Child restraints
recalls and registration......................... 45Child restraint systems.............................. 36
booster cushions.................................. 42
convertible seats.................................. 40
infant seats........................................... 38
ISOFIX/LATCH anchors........................ 43
top tether anchors................................ 44
Child safety.......................................... 34, 35
booster cushions.................................. 42
child restraint systems.......................... 36
convertible seats.................................. 40
infant seats........................................... 38
Child safety locks...................................... 49
Climate system........................................ 128
air distribution............................. 125, 130
air vents.............................................. 125
Interior Air Quality System.................. 125
introduction......................................... 124
passenger compartment filter............ 124
refrigerant........................................... 124
Clock, setting............................................. 76
Cold weather driving................................ 194
Collision warning system......................... 159
Compass in rearview mirror..................... 153
Conserving electrical current................... 193
Convertible seats....................................... 40
Coolant............................................220, 277Cooling system, general information....... 193
Courtesy lighting........................................ 89
Crash mode............................................... 33
Cruise control..................................157, 158
adaptive.............................................. 165
Curb weight............................................. 249
Current, conserving................................. 193
D
Defroster.................................................. 128
Detachable key blade..........................57, 59
Dimensions
V70...................................................... 270
XC70................................................... 272
Disconnecting the front passenger’s air-
bag....................................................... 24, 25
Dome lighting............................................. 89
Door mirrors............................................... 96
Driver distraction warning.......................... 10
Driving economically................................ 192
Driving in cold weather............................ 194
Driving through water..............................193

07 Index
07
287
U
Uniform Tire Quality Grading...................251
Unlocking the vehicle................................ 54
Upholstery care....................................... 265
V
Vanity mirror............................................ 189
changing bulbs................................... 228
Vehicle dimensions
V70...................................................... 270
XC70................................................... 272
Vehicle Event Data............................... 9, 214
Vehicle loading................................200, 249
roof loads............................................ 204
Vehicle maintenance................................ 214
performed by the owner.....................215
Vehicle weights........................................ 273
Ventilated seats....................................... 126
Volvo and the environment........................ 11
Volvo Inflatable Curtain.............................. 30
Volvo maintenance.................................. 214
Volvo On Call Roadside Assistance........ 279Volvo programs.......................................279
W
Warning flashers, hazard........................... 88
Warning lights.......................... 71, 72, 73, 74
Warning symbol......................................... 75
Warning system, collision........................ 159
Warranties................................................ 214
Washer fluid..................................... 230, 277
Washers
headlight............................................... 92
windshield............................................. 91
Water, driving through............................. 193
Waxing..................................................... 264
Weights.................................................... 273
Wheels.....................................................242
changing............................................. 253
storing................................................. 243
Whiplash Protection System..................... 31
Windows
power.................................................... 94Windshield
IR coating............................................. 93
rain sensor............................................ 91
washers................................................ 92
wipers/washers..................................... 91
Windshield washer fluid................... 230, 277
Windshield wipers.................................... 229
Wiper blades
replacing tailgate wiper...................... 230
replacing windshield wipers............... 229
