CD player VOLVO XC70 2003 Owners Manual

2003 VOLVO XC70
l BACK without SAVE (See above).
The following functions are available on the HU-803 only:
l AF SWITCHING ON/OFF (automatic frequency update) - The AF function ens\
ures that the strongest
available transmitter for a program is selected.
l REGIONAL ON/OFF (regional radio program) - This function makes it poss\
ible to continue to listen
to a regional transmitter, even if the signal is weak.
l EON (Enhanced Other Networks) LOCAL/DISTANT - This function determines\
whether the radio
program you are listening to is to be switched off before e.g. a traffic\
report or news broadcast (if these
functions are selected) only if the signal is strong (LOCAL) or wheth\
er the radio must also try to capture
weaker signals (DISTANT).
l NETWORK ALL/TUNED - With this function you can decide whether the radio \
program you are
listening to is to be switched off before e.g. a traffic report or news \
broadcast (if these functions are
selected) only if the report is on the channel you are listening to (T\
UNED), or whether the program is to
be switched off regardless of which radio channel the report/broadcast i\
s on (ALL).

pg. 160 Audio system HU-613/HU-803 - CD player

CD player - on
HU-613: Insert a CD.
HU-803: Insert a CD. If you would like to insert another disc (a maximum of 4 C\
D's can be inserted in
the player), turn the "1-20/DISC" button so that "CD 2 Load Disc" is di\
splayed. Insert the CD. Repeat
this procedure for discs 3 and 4.
Once the disc(s) have been inserted, select the CD function by turning\
the "SOURCE" knob.
Selecting a disc (HU-803 only)
file:///K|/ownersdocs/2003/2003_XC70/03xc70_10b.htm (4 of 13)12/30/200\
6 4:18:07 PM

2003 VOLVO XC70
Turn the "1-20/DISC" knob. The number of the disc and track is displayed\
.
CD eject
HU-613: If you press this button the CD stops playing and the disc is ejected. \
HU-803: The CD currently playing will be ejected. If more than one CD has been i\
nserted, turn the "1-
20/DISC" to display the number of the CD you would like to eject and pre\
ss the CD eject button.
NOTE: For traffic safety reasons, the ejected CD must be removed within 12 sec\
onds or it will be
automatically reinserted into the CD player.
Fast winding
Press " " or " " to seek within a track.
Next/previous track
Press " " to skip to the next track or " " to skip to the previous track. The track number is shown
in the display. If you have the key pad in the steering wheel you can al\
so use these arrows in the same
way.
Random
file:///K|/ownersdocs/2003/2003_XC70/03xc70_10b.htm (5 of 13)12/30/200\
6 4:18:07 PM

2003 VOLVO XC70
Armrest (center) - 3-section rear seat 65
Ashtray
39, 59
Audio systems
151
- cassette deck
162
- CD player
160
- HU-613 - overview
152
- HU-803 - overview
153
- specifications
165
AUM (Advanced User Mode) - radio
159
Automatic car washing
128
Automatic Locking Retractor (ALR)
14
Automatic transmission
90, 91, 145
- Geartronic
92, 93
- Kickdown
91, 92
Automatic transmission - cold starts
91
Auxiliary socket
31, 39
AWD
- general information
94
- using snow chains
109
B
Backrest (center) - 3-section rear seat
64
Battery
104, 148
Battery maintenance
138, 139
- Replacing the battery
139
- Ventilation hose
139
Booster cushion
12, 16
Brake failure warning light
28
Brake fluid
137
Brake system
18
Bulbs (list)
148
Bulbs - replacing
120-125
C
file:///K|/ownersdocs/2003/2003_XC70/03xc70_12.htm (2 of 12)12/30/2006\
4:18:08 PM
