01 SafetyChild safety
01``33 Children should be seated safely
Volvo recommends the proper use of restraint
systems for all occupants including children.
Remember that, regardless of age and size, a
child should always be properly restrained in a
vehicle.
Your vehicle is also equipped with ISOFIX/
LATCH attachments, which make it more con-
venient to install child seats.
Some restraint systems for children are
designed to be secured in the vehicle by lap
belts or the lap portion of a lap-shoulder belt.
Such child restraint systems can help protect
children in vehicles in the event of an accident
only if they are used properly. However, chil-
dren could be endangered in a crash if the child
restraints are not properly secured in the vehi-
cle. Failure to follow the installation instructions
for your child restraint can result in your child
striking the vehicle's interior in a sudden stop.
Holding a child in your arms is NOT a suitable
substitute for a child restraint system. In an
accident, a child held in a person's arms can
be crushed between the vehicle's interior and
an unrestrained person. The child could also be
injured by striking the interior, or by being ejec-
ted from the vehicle during a sudden maneuver
or impact. The same can also happen if the
infant or child rides unrestrained on the seat.
Other occupants should also be properlyrestrained to help reduce the chance of injuring
or increasing the injury of a child.
All states and provinces have legislation gov-
erning how and where children should be car-
ried in a vehicle. Find out the regulations
existing in your state or province. Recent acci-
dent statistics have shown that children are
safer in rear seating positions than front seating
positions when properly restrained. A child
restraint system can help protect a child in a
vehicle. Here's what to look for when selecting
a child restraint system:
It should have a label certifying that it meets
applicable Federal Motor Vehicle Safety
Standards (FMVSS 213) – or in Canada,
CMVSS 213.
Make sure the child restraint system is
approved for the child's height, weight and
development – the label required by the stand-
ard or regulation, or instructions for infant
restraints, typically provide this information.
In using any child restraint system, we urge you
to carefully look over the instructions that are
provided with the restraint. Be sure you under-
stand them and can use the device properly
and safely in this vehicle. A misused child
restraint system can result in increased injuries
for both the infant or child and other occupants
in the vehicle.When a child has outgrown the child safety
seat, you should use the rear seat with the
standard seat belt fastened. The best way to
help protect the child here is to place the child
on a cushion so that the seat belt is properly
located on the hips (see the illustration on page
41). Legislation in your state or province may
mandate the use of a child seat or cushion in
combination with the seat belt, depending on
the child's age and/or size. Please check local
regulations.
A specially designed and tested booster cush-
ion (not available in Canada) can be obtained
from your Volvo retailer for children weighing
33 – 80 lb. (15 – 36 kg) and 38 – 54 inches
(97 – 137 cm) in height.
WARNING
•
Do not use child safety seats or child
booster cushions/backrests in the front
passenger's seat. We also recommend
that children under 4 feet 7 inches
(140 cm) in height who have outgrown
these devices sit in the rear seat with the
seat belt fastened.
•
On hot days, the temperature in the
vehicle interior can rise very quickly.
Exposure to these high temperatures
for even a short period of time can
cause heat-related injury or death.
Small children are particularly at risk.
ProCarManuals.com

01 Safety
Child restraint systems
01``35 Child restraints
G022840
Infant seatThere are three main types of child restraint
systems: infant seats, convertible seats, and
booster cushions. They are classified accord-
ing to the child's age and size.
The following section provides general infor-
mation on securing a child restraint using a
three-point seat belt. Refer to page 42–43
for information on securing a child restraint
using ISOFIX lower anchors and/or top tether
anchorages.
G022847
Convertible seat
WARNING
A child seat should never be used in the
front passenger seat of any vehicle with a
front passenger airbag – not even if the
"Passenger airbag off" symbol near the
rear-view mirror is illuminated (on vehicles
equipped with Occupant Weight Sensor). If
the severity of an accident were to cause the
airbag to inflate, this could lead to serious
injury or death to a child seated in this posi-
tion.
G023269
Booster cushion
WARNING
Always refer to the child restraint manufac-
turer's instructions for detailed information
on securing the restraint.
ProCarManuals.com

01 SafetyInfant seats
01``37 Securing an infant seat with a seat belt
G022844
Do not place the infant seat in the front passeng-
er's sea
NOTE
Refer to page 42–43 for information on
securing a child restraint using ISOFIX lower
anchors and/or top tether anchorages.1. Place the infant seat in the rear seat of the
vehicle.
2. Attach the seat belt to the infant seat
according to the manufacturer's instruc-
tions.
G023270
Positioning the seat belt through the infant seat
WARNING
•An infant seat must be in the rear-facing
position only.•The infant seat should not be positioned
behind the driver's seat unless there is
adequate space for safe installation.
WARNING
A child seat should never be used in the
front passenger seat of any vehicle with a
front passenger airbag – not even if the
"Passenger airbag off" symbol near the
rear-view mirror is illuminated (on vehicles
equipped with Occupant Weight Sensor). If
the severity of an accident were to cause the
airbag to inflate, this could lead to serious
injury or death to a child seated in this posi-
tion.3. Fasten the seat belt by inserting the latch
plate into the buckle (lock) until a distinct
click is audible.
G023271
Fasten the seat belt
ProCarManuals.com

01 SafetyISOFIX lower anchors
0142
Using the ISOFIX lower child seat
anchors
G021064
ISOFIX lower child restraint anchorsLower anchors for ISOFIX-equipped child
seats are located in the rear, outboard seats,
hidden below the backrest cushions. Symbols
on the seat back upholstery mark the anchor
positions as shown. To access the anchors,
kneel on the seat cushion and locate the
anchors by feel. Always follow your child seat
manufacturer's installation instructions, and
use both ISOFIX lower anchors and top tethers
whenever possible.To access the anchors1. Put the child restraint in position.2. Kneel on the child restraint to press down
the seat cushion and locate the anchors by
feel.
3. Fasten the attachment on the child
restraint's lower straps to the ISOFIX lower
anchors.
4. Firmly tension the lower child seat straps
according to the manufacturer's instruc-
tions.
NOTE
•
The rear seat's center position is not
equipped with ISOFIX lower anchors.
When installing a child restraint in this
position, attach the restraint's top tether
strap (if it is so equipped) to the top
tether anchorage point and secure the
restraint with the vehicle's center seat
belt.
•
Always follow your child seat manufac-
turer's installation instructions, and use
both ISOFIX lower anchors and top
tethers whenever possible.
G018631
Fasten the attachment correctly to the ISOFIX
lower anchors
WARNING
•
Be sure to fasten the attachment cor-
rectly to the anchor (see the illustration).
If the attachment is not correctly fas-
tened, the child restraint may not be
properly secured in the event of a colli-
sion.
•
The ISOFIX lower child restraint
anchors are only intended for use with
child seats positioned in the outboard
seating positions. These anchors are
not certified for use with any child
restraint that is positioned in the center
seating position. When securing a child
restraint in the center seating position,
use only the vehicle's center seat belt.
ProCarManuals.com

07 Index
07278
introduction......................................... 224
license plate lights.............................. 229
side marker lights...............................227
specifications...................................... 230
taillight................................................ 228
CCapacity weight....................................... 251
Cargo area
changing bulbs................................... 229
floor rails............................................. 204
hooks for securing loads.................... 204
steel grid............................................. 207
Cargo area cover..................................... 208
Cargo area net......................................... 208
Catalytic converter................................... 200
CD player/changer........................... 135, 136
Cell phone, hands-free connection......... 143
Central locking system, introduction......... 52
Chains...................................................... 253
Check engine light..................................... 72
Child restraints
recalls and registration......................... 44Child restraint systems.............................. 35
booster cushions.................................. 41
convertible seats.................................. 39
infant seats........................................... 37
ISOFIX/LATCH anchors........................ 42
top tether anchors................................ 43
Child safety.......................................... 33, 34
booster cushions.................................. 41
child restraint systems.......................... 35
convertible seats.................................. 39
infant seats........................................... 37
Child safety locks...................................... 48
Climate system........................................ 128
air distribution............................. 125, 130
air vents.............................................. 125
Interior Air Quality System.................. 125
introduction......................................... 124
passenger compartment filter............ 124
refrigerant........................................... 124
Clock, setting............................................. 76
Cold weather driving................................ 196
Collision warning system......................... 160
Compass in rearview mirror..................... 153
Conserving electrical current................... 195
Convertible seats....................................... 39
Coolant............................................222, 274Cooling system, general information....... 195
Courtesy lighting.................................. 88, 89
Crash mode............................................... 32
Cruise control..................................158, 159
adaptive......................166, 167, 168, 169
Curb weight............................................. 251
Current, conserving................................. 195
DDefroster.................................................. 128
Detachable key blade..........................57, 59
Dimensions
V70...................................................... 268
XC70................................................... 270
Disconnecting the front passenger’s air-
bag....................................................... 23, 24
Dome lighting....................................... 88, 89
Door mirrors............................................... 96
Driver distraction warning............................ 9
Driving economically................................ 194
Driving in cold weather............................ 196
Driving through water..............................195
ProCarManuals.com

07 Index
07280
Headlights
active bi-xenon lights........................... 86
changing bulbs...........................225, 226
high/low beams.................................... 85
high beam flash.................................... 85
switch................................................... 85
Headlight washers..................................... 92
Head restraints, rear seat.......................... 82
Heartbeat sensor (alarm system)............... 55
Heated front seats................................... 126
Heated oxygen sensors........................... 201
Heated rear seats.................................... 127
High beams................................................ 85
indicator light........................................ 73
Hill Descent Control................................. 112
Home safe lighting..................................... 89
Hood, opening/closing............................219
Horn........................................................... 84IIgnition modes........................................... 77
Immobilizer................................................ 52
Important information.................................. 8Indicator lights...............................71, 72, 73
Infant seats................................................ 37
Inflatable Curtain........................................ 29
Inflation pressure.............................246, 247
Inflation pressure tables..................248, 249
Information lights...........................71, 72, 73
Information symbol.................................... 73
Inspection readiness................................ 217
Instrument lighting..................................... 85
Instrument overview............................70, 71
Instrument panel...................................... 121
Integrated two-stage booster cushion...... 45
Interior Air Quality System....................... 125
Interior lighting..................................... 88, 89
iPOD connector (audio system)...............132
ISOFIX anchors.......................................... 42
JJack
attaching.............................................256
location of........................................... 255
Jump starting........................................... 105
KKey blade.......................................52, 57, 59
private locking...................................... 59
Keyless drive
starting the engine.............................. 104LLabels
list of................................................... 267
location of........................................... 266
LATCH anchors......................................... 42
Leather care............................................. 263
Lighting panel............................................ 85
Load anchoring eyelets........................... 203
Loading
floor rails............................................. 204
hooks for securing loads.................... 204
Loading the vehicle.......................... 202, 251
roof loads............................................ 206
Locking the vehicle.................................... 54
Locks, child safety..................................... 48
Low beams................................................ 85
ProCarManuals.com
