Contents
* Option/accessory, for more information, see Introduction.5
03
03 Your driving environment
Instruments and controls.......................... 70
Ignition modes.......................................... 77
Seats......................................................... 79
Steering wheel.......................................... 84
Lighting..................................................... 85
Wipers and washers................................. 91
Power windows......................................... 94
Mirrors....................................................... 96
Power moon roof* .................................... 98
HomeLink® Wireless Control System*. . . 100
Starting the engine.................................. 103
Transmission...........................................107
Brakes..................................................... 110
Hill Descent Control (HDC)..................... 112
Parking brake.......................................... 114
04
04 Comfort and driving pleasure
Menus and messages............................. 120
Climate system....................................... 124
Audio system.......................................... 131
Bluetooth
® hands-free connection......... 145
Trip computer......................................... 151
Compass................................................. 153
Stability system....................................... 154
Active chassis system–Four C................156
Cruise control.......................................... 157
Collision warning with Auto-brake*......... 159
Adaptive Cruise Control (ACC)*.............. 165
Distance alert ......................................... 172
Driver Alert System* ............................... 175
Park assist*............................................. 180
Blind Spot Information System*.............. 183
Passenger compartment convenience. . . 187
05
05 During your trip
Driving recommendations....................... 192
Refueling................................................. 196
Loading................................................... 200
Cargo area ............................................. 205
Towing a trailer....................................... 208
Emergency towing.................................. 210
ProCarManuals.com

Introduction
Important warnings
10
Driver distraction
A driver has a responsibility to do everything
possible to ensure his or her own safety and
the safety of passengers in the vehicle and oth-
ers sharing the roadway. Avoiding distractions
is part of that responsibility.
Driver distraction results from driver activities
that are not directly related to controlling the
vehicle in the driving environment. Your new
Volvo is, or can be, equipped with many fea-
ture-rich entertainment and communication
systems. These include hands-free cellular tel-
ephones, navigation systems, and multipur-
pose audio systems. You may also own other
portable electronic devices for your own con-
venience. When used properly and safely, they
enrich the driving experience. Improperly used,
any of these could cause a distraction.
For all of these systems, we want to provide the
following warning that reflects the strong Volvo
concern for your safety. Never use these devi-
ces or any feature of your vehicle in a way that
distracts you from the task of driving safely.
Distraction can lead to a serious accident. In
addition to this general warning, we offer the
following guidance regarding specific newer
features that may be found in your vehicle
•Never use a hand-held cellular telephone
while driving. Some jurisdictions prohibitcellular telephone use by a driver while the
vehicle is moving.
•If your vehicle is equipped with a naviga-
tion system, set and make changes to your
travel itinerary only with the vehicle parked.
•Never program your audio system while
the vehicle is moving. Program radio pre-
sets with the vehicle parked, and use your
programmed presets to make radio use
quicker and simpler.
•Never use portable computers or personal
digital assistants while the vehicle is mov-
ing.
Accessory installation
•We strongly recommend that Volvo owners
install only genuine, Volvo-approved
accessories, and that accessory installa-
tions be performed only by a trained and
qualified Volvo service technician.
•Genuine Volvo accessories are tested to
ensure compatibility with the performance,
safety, and emission systems in your vehi-
cle. Additionally, a trained and qualified
Volvo service technician knows where
accessories may and may not be safely
installed in your Volvo. In all cases, please
consult a trained and qualified Volvo serv-
ice technician before installing any acces-
sory in or on your vehicle.
•Accessories that have not been approved
by Volvo may or may not be specifically
tested for compatibility with your vehicle.
Additionally, an inexperienced installer
may not be familiar with some of your car's
systems.
•Any of your car's performance and safety
systems could be adversely affected if you
install accessories that Volvo has not tes-
ted, or if you allow accessories to be instal-
led by someone unfamiliar with your vehi-
cle.
•Damage caused by unapproved or
improperly installed accessories may not
be covered by your new vehicle warranty.
See your Warranty and Service Records
Information booklet for more warranty
information. Volvo assumes no responsi-
bility for death, injury, or expenses that
may result from the installation of non-gen-
uine accessories.
ProCarManuals.com

03 Your driving environment
Instruments and controls
03

* Option/accessory, for more information, see Introduction.71
FunctionPage
Menus and mes-
sages, turn signals,
high/low beams,
trip computer120, 88,
85, 151
Cruise control157
Horn, airbag84, 20
Main instrument
panel71
Menu system, audio
controls131
Ignition slot77
START/STOP
ENGINE button77
Hazard warning
flashers88
Door handle–
In-door control pan-
els (power win-
dows, mirrors,
power child safety
locks, central lock-
ing button)94, 96,
49, 63
FunctionPage
Menu controls,
audio and climate
control systems120, 132,
126
Center console but-
tons120
Gear selector107
Controls for active
chassis (Four-C) -
certain models only156
Wipers and washers91, 92
Steering wheel
adjustment84
Parking brake114
Hood opening con-
trol217
Power seat* adjust-
ment controls79
Lighting panel, but-
tons for opening
fuel filler door and
unlocking the tail-
gate85, 198,
64
Information displays
G010604
Information displays in the instrument panel
The information displays (1) show information
on some of the vehicle's functions, such as
cruise control, the trip computer and mes-
sages. The information is shown with text and
symbols.
More detailed information can be found in the
descriptions of the functions that use the infor-
mation displays.
ProCarManuals.com

03 Your driving environment
Ignition modes
03

* Option/accessory, for more information, see Introduction.77 Inserting and removing the remote key
Ignition slot with remote key and START/STOP
ENGINE button.
Inserting the remote keyHolding the end of the remote key with the
base of the key blade, insert the remote key
into the ignition slot, with the buttons facing up,
as shown in the illustration.
CAUTION
Foreign objects in the ignition slot can
impair function or damage the lock.
Removing the remote keyThe remote key can be removed from the igni-
tion slot by pressing the key in lightly. It will
then be ejected slightly and can be removedfrom the slot. The gear selector must be in
position P (Park).
Ignition modesThe various ignition modes are accessed with
the remote key in the ignition slot.
Posi-
tionFunction
0Odometer, clock and tempera-
ture gauge are illuminated. Steer-
ing lock is deactivated. The audio
system can be used.
IMoonroof*, power windows,12-
volt sockets, navigation system*,
climate system blower, ECC,
windshield wipers can be used.
IIThe headlights come on. Warn-
ing/indicator lights come on for
5 seconds. All equipment oper-
ates apart from heated seats and
rear window defroster, which
only work when the engine is run-
ning.
IIIThe starter motor will operate
until the engine has started.
NOTE
The brake pedal must not be depressed
when accessing ignition modes I or II.
Ignition mode 0
Insert the remote key in the ignition slot and
press it lightly. It will be drawn into the slot.
Ignition mode I
Press the remote key into the ignition slot
and press START/STOP ENGINE.
Ignition mode II
Press the remote key into the ignition slot
and press START/STOP ENGINE for
approx. 2 seconds.
Ignition mode III (engine start)Start the engine, see page 103.
Stopping the engine
Press START/STOP ENGINE. (If the
engine is running and the vehicle is mov-
ing, keep the button depressed until the
engine stops).
Return to ignition mode 0
Press START/STOP ENGINE to return
from I, II, or III to ignition mode 0.
ProCarManuals.com

03 Your driving environment
Ignition modes
03
78
Functions with timerThe audio system can be operated without a
key for 15 minutes at a time by pressing the
POWER button. The power windows work for
several minutes after the key has been
removed, although not after the door has been
opened.
NOTE
Use the POWER button for the audio sys-
tem when the engine is not running to avoid
discharging the battery.
ProCarManuals.com

03 Your driving environment
Steering wheel
03
84* Option/accessory, for more information, see Introduction.
Adjusting
G021138
Adjusting the steering wheel
Lever for releasing/locking the steering
wheel
Possible positions
The steering wheel can be adjusted for both
height and reach:
1. Pull the lever toward you to release the
steering wheel.
2. Adjust the steering wheel to the position
that suits you.
3. Push back the lever to lock the steering
wheel in place. If the lever is difficult to
push into place, press the steering wheel
lightly at the same time as you push the
lever.
WARNING
Never adjust the steering wheel while driv-
ing.
With the optional speed-dependent power
steering the level of steering force can be
adjusted, see page 156.
Keypads
Keypads in the steering wheel
Cruise control, see page 157. Adaptive
cruise control*, see page 165.
Audio controls, see page 131.
Horn
Horn

Press the steering wheel hub to sound the
horn.
ProCarManuals.com

G020908
118* Option/accessory, for more information, see Introduction.
Menus and messages........................................................................... 120
Climate system..................................................................................... 124
Audio system........................................................................................ 131
Bluetooth
® hands-free connection....................................................... 145
Trip computer........................................................................................ 151
Compass............................................................................................... 153
Stability system..................................................................................... 154
Active chassis system–Four C.............................................................. 156
Cruise control........................................................................................ 157
Collision warning with Auto-brake*.......................................................159
Adaptive Cruise Control (ACC)*............................................................ 165
Distance alert ....................................................................................... 172
Driver Alert System* ............................................................................. 175
Park assist*........................................................................................... 180
Blind Spot Information System*............................................................ 183
Passenger compartment convenience................................................. 187
ProCarManuals.com

04 Comfort and driving pleasure
Menus and messages
04

* Option/accessory, for more information, see Introduction.121
Door mirror settings
Parking camera settings (accessory)
Lane departure warning*
Steering force level*
Information
Climate settings
Automatic blower adjust
Recirculation timer
Auto. rear defroster
Reset climate settings
Main menu AMHD radio
Audio settings
2
Sound stage
Equalizer, front
Equalizer, rear
Auto. volume control
Resets all audio settings.
Main menu FMHD radioFM settings
Radio text
Advanced radio settings
Audio settings
Main menu CDRandom
Off
Folder
Disc
Single disc
All discs
CD settings
Track information*
Audio settings
Main menu AUXVolume, AUX input
Audio settings
Main menu USBUSB settings
Audio settingsTrack information*
Main iPod menuiPod settings
Audio settings
Track information*
Main Bluetooth menuLast 10 missed calls
Last 10 received calls
Last 10 dialled calls
Phone book
Search
Copy fr. mobile phone
Bluetooth*
Connect phone
Change phone
Remove phone
Phone settings
Call options
Sounds and volume
Synchronize phone book
1Certain models2The menu option for audio settings is available in all audio sources.
ProCarManuals.com

04 Comfort and driving pleasure
Menus and messages
04
123
MessageDescription
Service requiredHave the vehicle
checked by an
authorized Volvo
workshop as soon
as possible.
See manualRead the owner's
manual.
Book time for
maintenanceTime to book service
at an authorized
Volvo retailer.
Time for regular
maintenanceTime for regular
service at an author-
ized Volvo work-
shop. The timing is
determined by the
number of miles
driven, number of
months since the
last service, engine
running time.
MessageDescription
Maintenance over-
dueIf the service inter-
vals are not fol-
lowed, the warranty
does not cover any
damaged parts.
Contact an author-
ized Volvo workshop
for service.
Temporarily OFFA function has been
temporarily
switched off and is
reset automatically
while driving or after
starting again.
Power save modeThe audio system is
switched off to save
current. Charge the
battery.
ProCarManuals.com

04 Comfort and driving pleasure
Audio system
04

* Option/accessory, for more information, see Introduction.131 Introduction
The audio system is available in two versions:
High Performance and Premium Sound. The
system version is shown in the display when
the audio system is switched on.
If the audio system is on when the ignition is
switched off, it will come on automatically the
next time the ignition is put in mode I or higher.
The audio system can be operated without a
key in the ignition slot for 15 minutes at a time
by pressing the POWER button (the driver's
door must be closed on vehicles with the
optional keyless drive).
Some functions are controlled from the menu
system in the center console. For more infor-
mation on menus, see page 120.
Dolby Surround Pro Logic II and the sym-
bol are trademarks of Dolby Laboratories
Licensing Corporation. The Dolby Surround
Pro Logic II System is manufactured under
license from Dolby Laboratories Licensing Cor-
poration.
Overview
Socket for external audio source (AUX,
USB, iPodŸ1)*
Steering wheel keypad
Center console control panel
Control panel with headphones socket*
Steering wheel keypad
Confirm selection in menu system and
controls for a bluetooth-connected cell
phone (see page 145).
Go higher in the menu system. Interrupt
current function.
Volume
A short press scrolls between CD tracks or
preset radio stations. A long press
searches within CD tracks or searches for
radio stations automatically.
Please note that these functions are also avail-
able through the audio system controls on cen-
ter console.
1iPod is a registered trademark of Apple Inc.
ProCarManuals.com
