2004 VOLVO XC90
programmed button does not activate the garage door, your garage door op\
ener may have a rolling code.
l Press the programmed HomeLink® button. If the garage door opener has \
the rolling code feature, the
HomeLink® indicator light flashes rapidly and then glows steadily aft\
er approximately 2 seconds.
To train a rolling code garage door opener,
follow these instructions after programming the desired transceiver butt\
on according to "Programming
the transceiver." The help of a second person may make training easier.
1. Locate the training button on the garage door opener motor head unit.\
The location and color of the
training button may vary. If you encounter difficulty, refer to the gara\
ge door opener owner's manual or
call toll-free 1-800-355-3515 (Internet:
www.HomeLink.com).
2. Press the "training" button on the garage door opener motor head unit\
until the "training" light comes
on.
3. Press and release the programmed HomeLink® button. Press and relea\
se the programmed
HomeLink® button a second time to complete the training process.
4. Some garage door openers may require you to do this procedure a third\
time to complete the training.
5. The programmed button on your HomeLink® Universal Transceiver shou\
ld now operate your garage
door opener. The original hand-held transmitter can also be used, as des\
ired, to operate the garage door.
The remaining two HomeLink® buttons can be programmed in the same way\
. In the event of any
problems in programming the HomeLink® Universal Transceiver, call tol\
l-free 1-800-355-3515
(Internet:
www.HomeLink.com).
Operating the HomeLink® Universal Transceiver
Once programmed, the HomeLink® Universal Transceiver can be used in p\
lace of your handheld
transmitters.
To operate, the key must be turned to the "accessory" position (II) or\
the engine must be running. Press
the programmed HomeLink® button to activate the garage door, driveway\
gate, security lighting, home
security system, etc.
pg. 182 Audio
Your original hand-held transmitters may, of course, be used at any time\
.
Erasing programmed buttons
Individual buttons cannot be erased. To erase all three programmed butto\
ns:
1. Turn the ignition key to the "accessory" position (II).
2. Hold down the two outside buttons on the HomeLink® Universal Trans\
ceiver for about 20 seconds,
until HomeLink®'s indicator light begins to flash.
3. Release both buttons.
file:///K|/ownersdocs/2004/2004_XC90/04xc90_11b.htm (10 of 11)12/30/20\
06 4:35:32 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
The HomeLink® buttons can be reprogrammed using the procedures descri\
bed on the previous page.
Reprogramming a single HomeLink® button
1. Press and hold the desired HomeLink® button. Do not release the bu\
tton until step 3 has been
completed.
2. When the indicator light begins to flash slowly (after approximately\
20 seconds), position your hand-
held transmitter 2 to 5 in. (5 to 12 cm) away from the HomeLink® su\
rface.
3. Press and hold the hand-held transmitter button. The HomeLink® ind\
icator light will flash first
slowly, then rapidly. When the indicator light flashes rapidly, release \
both buttons.
The previously programmed device has now been erased and the new device \
can be activated by
pressing the HomeLink® button that has just been programmed. This pro\
cedure will not affect any other
programmed HomeLink® buttons.
NOTE:
l Retain the original transmitter(s) for future programming procedures (\
e.g., if you purchase a new
vehicle).
l For your own security, erase all programmed buttons on the HomeLink® \
Universal Transceiver when
you sell your vehicle.
l Metallic sun protection films should not be used on any windows in a veh\
icle equipped with
HomeLink® Universal Transceiver. This could interfere with the transc\
eiver's function.




Contents | Top of Page
file:///K|/ownersdocs/2004/2004_XC90/04xc90_11b.htm (11 of 11)12/30/20\
06 4:35:32 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
2 0 0 4
VOLVO XC90
Index

pg. 183-186 Index
A
A/C (air conditioning)
50
ABS
ii, 25, 96
Adjustable steering wheel
30
Advanced user functions
172
Air bags - dual threshold/stage
5
Air cleaner
128
Air distribution
47, 50
Air Quality sensor
51
Air vents
47
Airbag - Side Impact (SIPS)
10
Airbags
4
Airbags (front)
4
Alarm
73, 80
All Wheel Drive
94
All Wheel Drive - towing
101
Anti-lock Brake System (ABS)
ii, 25
Approach lighting
33
Ashtray
39, 64
Audio
159
AUTO
49
AUTO (climate control)
49
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (1 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Automatic climate control, ECC 48
Automatic gearbox
89
Auxiliary 12-volt socket
39
Auxiliary lamps
29
Average speed
36
AWD
94
B
Bass
165
Battery
126, 133, 155
Battery - replacing
135
Battery drain - avoiding
90
Battery maintenance
134
Belt check
127
Blower (fan)
49
Booster cushion
17
Brake circuit
95
Brake system
26, 95
Bulbs
137, 156
C
Capacities
152
Carbon Monoxide - Important Warning
85
Catalytic converter
154
CD changer
177
Ceiling lighting
143
Center console - storage compartments
64
Central locking system - remote control
75
Changing coolant
127
Changing oil and oil filter
129
Check Engine warning light
27
Child safety
17
Child safety locks
79
Child seat (Isofix fasteners)
18
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (2 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Climate control systems - general information 46
Clock
24
Coat hanger
66
Coin compartment
64
Cold weather precautions
105
Coolant
131
Coolant - changing
127, 131
Coolant - checking level of
127
Cooling system
153
Courtesy light
61
Cruise control
37
Cup holder
64, 65
Cup holder in rear seat
64
Current fuel consumption
36
D
Defroster
49
Dimension designation (tires)
110
Direction indicators
33
Dolby Pro Logic II (DPL II)
165
Door mirror defroster
35
Driving economically
89
DSTC
29, 97
Dual-threshold air bags
5
E
ECC
48
Economical driving
89
Electric socket
29
Electrical current - conserving
90
Electrical system
155
Engine
128
Engine - starting
87
Engine compartment
128
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (3 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Engine oil 129
Engine oil, capacity
152
Engine specifications
157
Engne oil - checking
130
Environment
iii
F
Fader
165
Federal Clean Air Act
124
FIX NEXT SERVICE
28
Floor mats
62
Fog lamp
27
Folding sideview mirrors
42
Front seat - backrest
55
Front seats
54
Front seats - heated
35
Front seats - manual adjustment
54
Front seats - power
56
Front suspension
153
Fuel
ii, 84
Fuel filler cap
ii, 86
Fuel filler door
ii, 86
Fuel filler door - unlocking
31
Fuel filler door - unlocking manually
32
Fuel Formulations
85
Fuel gauge
24
Fuel tank, capacity
152
Fuses
145
G
Gasoline
84
Geartronic
91
Geartronic - kickdown
92
Geartronic - manual shifting
92
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (4 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
General information ii
Generator warning light
27
Glove compartment
65
H
Handling
90
Hazard warning flashers
35
Headlight flasher
33
Headlight washer
34
Headlight wiper blades
133
Headlights
31
Headphones
162
Heated front seats
35, 50
High beam "flash"
33
High beam indicator
24
High/low beams - replacing
138
Hoisting the car
126
Home Safe System
33
Hood - opening
38
I
IC
12
Immobilizer (start inhibitor)
74
Indicator and warning symbols
24, 25
Inflatable Curtain
12
Instrument lighting
31
Instrument panel
24
Interior
53
Interior Air Quality sensor
51
Interior lighting
61
Intermittent wiping
34
Introduction
i
Isofix fasteners (child seats)
18
J
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (5 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Jump starting 102
K
Keylock
ii, 87
Keys
74
L
LED illumination
33
Lighting panel
31
Locking
77
Locking steering wheel
88
Locks
73
Long distance trips
108
Lubricants
153
M
Maintenance services
124
Malfunction indicator light
27
Messages in the display
28
Moonroof (electrically operated)
43
Multifilter with air quality sensor
51
O
Occupant safety
21
Octane rating
84
Odometer
24
Oil pressure
27
Oil quality
129
Oil viscosity
129
Opening the hood
38
Opening the tailgate
39
P
P Park
91
Paint
120
Paint - color code
120
Paintwork damage
120
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (6 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Parking brake 27, 38
Parking lamps
31
Parking lights
31
Polishing
119
Power seat
56
Power steering fluid
130
Power moonroof
43
PROPOSITION 65 WARNING
102, 136
R
Radiator
128
Rain sensor
34
Rain sensor - windshield wipers
34
Reading lamps
61
Rear fog lamps
31
Rear seat air condition
29
Rear suspension
153
Rear window defroster
35
Rearview mirror/door mirrors
42
Recirculation
50
REDUCE SPEED
28
Refrigerant (A/C system)
46
Refueling
84, 86
Remote control - central locking system
75
Reporting safety defects
21
Reverse warning system
29
Roadholding
90
Roll Stability Control (RSC)
97
S
Safety
1
Safety defects - reporting
21
Seat belt
2
Seat belt maintenance
21
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (7 of 13)12/30/2006\
4:35:33 PM

Downloaded from www.Manualslib.com manuals search engine ProCarManuals.com
2004 VOLVO XC90
Seat belt reminder 42
Seat belts (keeping child seats in place)
20
SEL button
162
Service
124
Service key
74
Service reminder
27
SERVICE REQUIRED
28
SERVICE URGENT
28
Shiftlock
ii, 87
Side airbags
10
Sideview mirrors
42
SIPS airbags
10
Snow chains
111
Snow tires
111
Spare tire - accessing
115
Spare tires
112
Spark plugs
155
Specifications
149
Speedometer
24
Spoiler lamps
31
SRS
4
Start inhibitor (immobilizer)
74
Starting the car
87
Steering
88
Steering wheel adjustment
30
Steering wheel lock
88
Stone chips
120
STOP
28
STOP ENGINE
28
Storage compartments
64
Studded tires
111
Supplemental Restraint System (SRS)
4
file:///K|/ownersdocs/2004/2004_XC90/04xc90_12.htm (8 of 13)12/30/2006\
4:35:33 PM
