Specifications
8-2
8
Front tire:Type:
Tubeless
Size:
120/70-13 53P
Manufacturer/model:
MICHELIN/POWER PURE SCRear tire:Type:
Tubeless
Size:
130/60-13 53P
Manufacturer/model:
MICHELIN/POWER PURE SCLoading:Maximum load:
182 kg (401 lb)
(Total weight of rider, passenger, cargo
and accessories)Tire air pressure (measured on cold
tires):1 person:
Front:
150 kPa (1.50 kgf/cm², 22 psi)
Rear:
150 kPa (1.50 kgf/cm², 22 psi)
2 persons:
Front:
160 kPa (1.60 kgf/cm², 23 psi)
Rear:
170 kPa (1.70 kgf/cm², 25 psi)Front wheel:Wheel type:
Cast wheelRim size:
13 x MT3.00
Rear wheel:Wheel type:
Cast wheel
Rim size:
13 x MT3.50Front brake:Type:
Hydraulic single disc brake
Specified brake fluid:
DOT 4Rear brake:Type:
Hydraulic single disc brake
Specified brake fluid:
DOT 4Front suspension:Type:
Telescopic fork
Spring:
Coil spring
Shock absorber:
Hydraulic damper
Wheel travel:
80 mm (3.1 in)Rear suspension:Type:
Unit swing
Spring:
Coil spring
Shock absorber:
Hydraulic damperWheel travel:
64 mm (2.5 in)
Electrical system:System voltage:
12 V
Ignition system:
TCI
Charging system:
AC magnetoBattery:Model:
GS CB5L-B
Voltage, capacity:
12 V, 5.0 Ah (10 HR)Headlight:Bulb type:
Halogen bulbBulb wattage:Headlight:
35.0 W/35.0 W x 1
Brake/tail light:
21.0 W/5.0 W × 1
Front turn signal light:
10.0 W × 2
Rear turn signal light:
10.0 W × 2
Auxiliary light:
5.0 W × 1
License plate light:
5.0 W × 1
Meter lighting:
LED
High beam indicator light:
LED
U1GBE1E0.book Page 2 Tuesday, October 17, 2017 11:45 AM
Page 72 of 78
Specifications
8-3
8
Turn signal indicator light:
LED
Fuel level warning light:
LED
Coolant temperature warning light:
LED
Engine trouble warning light:
LEDFuse(s):Main fuse:
15.0 A
U1GBE1E0.book Page 3 Tuesday, October 17, 2017 11:45 AM
Page 73 of 78
Consumer information
9-1
9
EAU40793
Identification numbersRecord the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case
the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
EAU26411
Vehicle identification number
The vehicle identification number is
stamped into the frame.TIPThe vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensing
authority in your area.
EAUM2811
Model label
The model label is affixed to the bot-
tom of the passenger seat. (See page
3-11.) Record the information on this
label in the space provided. This infor-
mation will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number1ZAUM0287
1. Model labelZAUM1077
1
U1GBE1E0.book Page 1 Tuesday, October 17, 2017 11:45 AM
Page 74 of 78
Consumer information
9-2
9
EAU69910
Diagnostic connectorThe diagnostic connector is located as
shown.
EAU85300
Vehicle data recordingThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research, statisti-
cal analysis and development purpos-
es.
Although the sensors and recorded
data will vary by model, the main data
points are: Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
This data will be uploaded only when a
special Yamaha diagnostic tool is at-
tached to the vehicle, such as when
maintenance checks or service proce-
dures are performed.
Vehicle data uploaded will be handled
appropriately according to the follow-
ing Privacy Policy.
Privacy Policy Yamaha will not disclose this data to a
third party except in the following cas-
es. In addition, Yamaha may provide
vehicle data to a contractor in order to
outsource services related to the han-
dling of vehicle data. Even in this case,
Yamaha will require the contractor to properly handle the vehicle data we
provided and Yamaha will appropriate-
ly manage the data. With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
When the data is not related to an
individual vehicle nor owner
1. Diagnostic connectorZAUM1554
1
https://www.yamaha-motor.eu/eu/
privacy/privacy-policy.aspx
