parking brake YAMAHA BANSHEE 350 2002 Manuale de Empleo (in Spanish)

LOCATION OF THE WARNING AND
SPECIFICATION LABELS .......................1-1
SAFETY INFORMATION .........................2-1
DESCRIPTION AND MACHINE
IDENTIFICATION.....................................3-1
Identification number records ...............3-3
Key identification number .....................3-5
Vehicle identification number ...............3-7
Model label ...........................................3-9
CONTROL FUNCTIONS .........................4-1
Main switch ...........................................4-1
Handlebar switches ..............................4-3
Throttle lever ........................................4-5
Throttle OverRide System ....................4-7
Speed limiter ........................................4-9
Clutch lever ........................................4-11
4321
Front brake lever ................................4-11
Rear brake pedal ................................4-13
Parking brake .....................................4-13
Shift pedal ..........................................4-17
Kick starter .........................................4-17
Fuel tank cap ......................................4-19
Fuel cock ............................................4-19
Starter (choke) ....................................4-21
Seat ....................................................4-23
Front shock absorber adjustment .......4-25
Rear shock absorber adjustment .......4-27
PRE-OPERATION CHECKS ...................5-1
Front and rear brakes ...........................5-5
Fuel ....................................................5-11
Engine mixing oil ................................5-15
Transmission oil .................................5-17
Chain ..................................................5-19
Throttle lever ......................................5-19
5
EBU00015
CONTENTS
5FK-9-63-0~3 2/7/02 1:24 PM Page 12

Cooling system ...................................8-23
Spark plug inspection .........................8-39
Air filter cleaning .................................8-43
Carburetor settings .............................8-51
Idle speed adjustment ........................8-67
Throttle lever adjustment ....................8-71
Front and rear brake pad
inspection .........................................8-73
Inspecting the brake fluid level ...........8-75
Brake fluid replacement ......................8-79
Front brake adjustment ......................8-81
Rear brake adjustment .......................8-83
Parking brake adjustment ...................8-85
Adjusting the rear brake light switch ...8-89
Clutch adjustment ...............................8-91
Drive chain slack check ......................8-91
Drive chain slack adjustment ..............8-93
Lubricating the drive chain .................8-95
Cable inspection and lubrication ........8-99Brake and shift pedal/brake and
clutch lever lubrication ....................8-101
Upper arm and lower arm pivot
lubrication .......................................8-101
Rear arm pivot lubrication ................8-103
Wheel removal .................................8-105
Wheel installation .............................8-105
Replacing the headlight bulb ............8-107
Headlight beam adjustment ..............8-109
Tail/brake light bulb replacement .....8-111
Troubleshooting ................................8-113
Troubleshooting chart .......................8-117
CLEANING AND STORAGE ...................9-1
A. Cleaning ...........................................9-1
B. Storage ............................................9-7
SPECIFICATIONS .................................10-1
109
5FK-9-63-0~3 2/7/02 1:24 PM Page 14

3-1
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION1. Tail/brake light 13. Rear wheel
2. Seat 14. Starter (choke)
3. Kick starter 15. Shift pedal
4. Fuel tank cap 16. Clutch lever
5. Headlight 17. Parking brake
6. Brake pedal 18. Main switch
7. Rear brake light switch 19. Front brake lever
8. Front wheel 20. Throttle lever
9. Front shock absorber 21. Handlebar switch
10. Radiator
11. Fuel cock
12. Rear shock absorberNOTE:
The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
e
r
t
y
w
q
u
!6 !7
!8!9
@1 @0i!0!1
o
!2
!3
!4 !5
5FK-9-63-0~3 2/7/02 1:24 PM Page 46

4-13
EBU00071Rear brake pedal
The brake pedal is located on the right side of
the machine. Push down on the pedal to apply
the rear brake.EBU00081Parking brake
Use the parking brake when you have to start the
engine or park the machine, especially on a
slope. Squeeze the clutch lever while pushing
the button, then push in the lock plate to apply
the parking brake. Squeeze the clutch lever to
release the parking brake.NOTE:
When the parking brake is used, engine speed is
limited to 2,300 r/min. Be sure the parking brake
is released before moving the throttle lever. Oth-
erwise, the engine will misfire, preventing normal
operation.
q
q
w
1. Rear brake pedal1. Pédale de frein arrière1. Pedal del freno trasero
1. Button 2. Lock plate1. Bouton 2. Frein d’écrou1. Botón 2. Placa de bloqueo
5FK-9-63-4~5 2/7/02 1:25 PM Page 14

4-15
w8Always set the parking brake before start-
ing the engine. The ATV could start mov-
ing unexpectedly if the parking brake is
not applied. This could cause loss of con-
trol or a collision.
8Always be sure you have released the
parking brake before you begin to ride. The
brake could overheat if you ride the ATV
without releasing the parking brake. You
could lose braking performance which
could cause an accident. You could also
wear out the brakes prematurely.
5FK-9-63-4~5 2/7/02 1:25 PM Page 16

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes9Check operation, free play, fluid level and fluid leakage. 5-5 ~ 5-9
9Fill with DOT 4 brake fluid if necessary. 8-73 ~ 8-83
Clutch9Check operation, condition and lever free play. 8-91
Parking brake9Check operation, condition and free play. 8-85 ~ 8-87
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-11 ~ 5-13
Transmission oil9Check oil level.
9Fill with oil if necessary.5-17, 8-17 ~ 8-23
Coolant reservoir 9Check coolant level.
9Fill with coolant if necessary.8-23 ~ 8-37
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-19, 8-91 ~ 8-97
Throttle9Check for proper throttle cable operation. 5-19, 8-71
Wheels and tires9Check tire pressure, wear and damage. 5-23 ~ 5-29, 8-105
Fittings and Fasteners9Check all fittings and fasteners. 5-19
Lights9Check for proper operation. 5-21, 8-107 ~ 8-111
5FK-9-63-4~5 2/7/02 1:25 PM Page 36

6-3
EBU00512Starting a cold enginewAlways make sure all control cables work
smoothly before you begin riding in cold
weather. If the control cables are frozen or
do not work smoothly, you could be unable
to control the ATV, which could lead to an
accident or collision. 1. Set the parking brake.
2. Turn the fuel cock to “ON”.
3. Turn the main switch to “ON” and the engine
stop switch to “RUN”.
4. Shift the transmission into neutral.
5. Use the starter (choke) in reference to the
figure:
5FK-9-63-6 2/7/02 1:26 PM Page 4

6-9
EBU00180Starting a warm engine
To start a warm engine, refer to the “Starting a
cold engine” section. The starter (choke) should
not be used. The throttle should be opened
slightly.EBU00538Warming up
To get maximum engine life, always warm up
the engine before starting off. Never accelerate
hard with a cold engine! To see whether or not
the engine is warm, check if it responds to the
throttle normally with the starter (choke) turned
off.NOTE:
When the parking brake is used, engine speed
is limited to 2,300 r/min. Be sure the parking
brake is released before moving the throttle
lever. Otherwise, the engine will misfire, pre-
venting normal operation.
5FK-9-63-6 2/7/02 1:26 PM Page 10

6-25
EBU00212Parking
When parking, stop the engine and shift into low
gear. Turn the fuel cock to “OFF” and apply the
parking brake.
5FK-9-63-6 2/7/02 1:26 PM Page 26

6-27
EBU00214Parking on a slopewAvoid parking on hills or other inclines.
Parking on a hill or other incline could cause
the ATV to roll out of control, increasing the
chance of an accident. If you must park on
an incline, put the machine in low gear, apply
the parking brake, and block the front and
rear wheels with rocks or other objects.
Do not park the ATV at all on hills that are so
steep you could not walk up them easily.1. Bring the machine to a stop by applying the
brakes in low gear.
2. Stop the engine and release the clutch
lever.
3. With the front and rear brakes applied, apply
the parking brake and slowly release the
rear brake pedal.
