4-11
EBU00068Clutch lever
The clutch lever is located on the left handlebar.
Pull the clutch lever to the handlebar to disen-
gage the clutch, and release the lever to engage
the clutch. The lever should be pulled rapidly and
released slowly for smooth clutch operation.EBU00070Front brake lever
The front brake lever is located on the right han-
dlebar. Pull it toward the handlebar to apply the
front brake.
q
q
1. Clutch lever1. Levier d’embrayage1. Palanca de embrague
1. Front brake lever1. Levier de frein avant1. Palanca del freno delantero
5FK-9-63-4~5 2/7/02 1:25 PM Page 12

1. Lean towards inside of turn.
2. Support your weight on the outer footrest.1. Se pencher vers l’intérieur du virage.
2. S’appuyer sur le repose-pied externe.1. Inclínese hacia el interior del giro.
2. Descanse su peso en el descansapie externo.
7-43
As you approach a curve, slow down and begin
to turn the handlebars in the desired direction.
As you do so, put your weight on the footboard
to the outside of the turn (opposite your desired
direction) and lean your upper body into the
turn. Use the throttle to maintain an even speed
through the turn. This maneuver will let the
wheel on the inside of the turn slip slightly,
allowing the ATV to make the turn properly.
This procedure should be practiced at slow
speed many times in a large off-road area with
no obstacles. If an incorrect technique is used,
your ATV may continue to go straight. If the ATV
doesn’t turn, come to a stop and then practice
the procedure again. If the riding surface is slip-
pery or loose, it may help to position more of
your weight over the front wheels by moving for-
ward on the seat.Once you have learned this
technique you should be able to perform it at
higher speeds or in tighter curves.
q
w
