Page 266 of 402
8-19
Transmission oil replacement
1. Place the ATV on a level surface.
2. Warm up the engine for several minutes
and then stop it.
3. Place a container under the engine to col-
lect the used oil.
4. Remove the oil filler cap and drain bolt to
drain the oil.
5. Install the drain bolt, and then tighten it to
the specified torque.
6. Fill the engine with the recommended oil,
and then install the oil filler cap.
q
1. Drain bolt1. Boulon de vidange1. Perno de vaciado
Tightening torque:
Drain bolt:
20 Nm (2.0 m0kgf)
5FK-9-66-05 12/3/04 7:54 PM Page 20
Page 276 of 402
8-29
EBU00766
To change the coolant
w
Wait for the engine and radiator to cool
before removing the radiator cap. You could
be burned by hot fluid and steam blown out
under pressure. Always put a thick rag over
the cap when opening. Allow any remaining
pressure to escape before completely
removing the cap.
1. Put the ATV on a level place.
2. Remove the radiator cover bolts, and then
remove the radiator cover.
3. Place a container under the engine and
remove the coolant drain bolts.
qw
w
qq
1. Radiator cover 2. Radiator cover bolt (×3)1. Cache de radiateur 2. Boulon du cache de
radiateur (×3)
1. Cubierta del radiador 2. Perno de la cubierta del
radiador (×3)
1. Drain bolt (×2)
1. Boulon de vidange (×2)1. Perno de drenaje (×2)
5FK-9-66-05 12/3/04 7:54 PM Page 30
Page 280 of 402
8-33
6. Disconnect the hose on the coolant reser-
voir side and drain the coolant from the
coolant reservoir.
7. After draining the coolant, thoroughly flush
the cooling system with clean tap water.
8. Replace the coolant drain bolt washers if
they are damaged, and then tighten the
coolant drain bolts to the specified torque.
9. Install the coolant reservoir hose.
10. Pour the recommended coolant into the
radiator until it is full.
q
w
1. Coolant reservoir hose
2. Coolant reservoir
1. Flexible du vase d’expansion
2. Vase d’expansion
1. Manguera del depósito de refrigerante
2. Depósito de refrigerante
Tightening torque
Coolant drain bolt:
14 Nm (1.4 m0kgf)
5FK-9-66-05 12/3/04 7:54 PM Page 34
Page 302 of 402
8-55
Changing the settings of the carburetors
To change the settings of the carburetors, you
need to disassemble and remove them. Follow
the procedures for both carburetors.
Disassembling and removing the carburetors
1. Turn the fuel cock to the “OFF” position.
2. Turn out the carburetor drain screw to
drain the fuel.
3. Remove the seat.
4. Remove the radiator cover and side cover
by removing the screws.
5. Disconnect the fuel hoses.
6. Remove the fuel tank by removing the
bolts.13
3
2 4
4
4
4
1
2
2 2
2
1. Radiator cover 2. Side cover
3. Screw (×3) 4. Screw (×4)
1. Cache du radiateur 2. Cache latéral
3. Vis (×3)4. Vis (×4)1. Cubierta del radiador 2. Cubierta lateral
3. Tornillo (×3) 4. Tornillo (×4)
1. Fuel tank 2. Bolt (×4)
1. Réservoir de carburant 2. Boulon (×4)
1. Depósito de combustible 2. Perno (×4)
5FK-9-66-05 12/3/04 7:54 PM Page 56
