Cooling system ...................................8-23
Spark plug inspection .........................8-39
Air filter cleaning .................................8-43
Carburetor settings .............................8-51
Idle speed adjustment ........................8-67
Throttle lever adjustment ....................8-71
Front and rear brake pad
inspection .........................................8-73
Brake fluid level inspection .................8-75
Brake fluid replacement ......................8-79
Front brake adjustment ......................8-81
Brake pedal height adjustment ...........8-83
Parking brake adjustment ...................8-85
Adjusting the rear brake light switch ...8-89
Clutch adjustment ...............................8-91
Drive chain slack check ......................8-91
Drive chain slack adjustment ..............8-93
Lubricating the drive chain .................8-95
Cable inspection and lubrication ........8-99Brake and shift pedal/brake and
clutch lever lubrication ....................8-101
Front upper and lower arm pivot
lubrication .......................................8-101
Rear arm pivot lubrication ................8-103
Wheel removal .................................8-105
Wheel installation .............................8-105
Replacing the headlight bulb ............8-107
Headlight beam adjustment ..............8-109
Tail/brake light bulb replacement .....8-111
Troubleshooting ................................8-113
Troubleshooting chart .......................8-117
CLEANING AND STORAGE ...................9-1
A. Cleaning ...........................................9-1
B. Storage ............................................9-7
SPECIFICATIONS .................................10-1
10
9
5FK-9-64-0~3 4/8/02 1:19 PM Page 14

7-67
Test your brakes after leaving the water. Do not
continue to ride your ATV without verifying that
you have regained proper braking ability.
cC
After riding your ATV in water, be sure to
drain the trapped water by removing the
check hose at the bottom of the air filter
case. Wash the ATV in fresh water if it has
been operated in salt water or muddy condi-
tions.
q
1. Check hose1. Tuyau de contrôle1. Manguito de retención
5FK-9-64-7 4/8/02 1:25 PM Page 68

8-7
EBU00262
PERIODIC MAINTENANCE/LUBRICATION
INITIAL EVERY
ITEM ROUTINE 1 3 6 6 1
month months months months year
Transmission9Replace oil.2222
9Check coolant leakage.
Cooling system9Repair if necessary.22222
9Replace coolant every 24 months.
9Check condition.
Spark plug9Adjust gap and clean.22222
9Replace if necessary.
Air filter9Clean. Every 20–40 hours.
9Replace if necessary. (More often in wet or dusty areas)
* Carburetor9Check idle speed / starter operation.
2222
9Adjust if necessary.
* Crankcase breather9Check breather hose for cracks or damage.
222
system9Replace if necessary.
9Check for leakage.
* Exhaust system9Retighten if necessary.222
9Replace gasket(s) if necessary.
* Fuel line9Check fuel hose for cracks or damage.
222
9Replace if necessary.
Throttle operation9Inspect and adjust free play if necessary.22222
* Front and rear9Check operation/fluid leakage/see NOTE Page 8-9.
22222
brake operation9Correct if necessary.
* Front and rear9Check pad wear.
222
brake pads9Replace if necessary.
5FK-9-64-8 4/8/02 1:26 PM Page 8

8-43
EBU00289
Air filter cleaning
NOTE:
There is a check hose at the bottom of the air fil-
ter case. If dust or water collects in this hose,
empty the hose and clean the air filter element
and air filter case.
1. Remove the seat.
2. Remove the air filter case cover.
q
q
1. Check hose1. Flexible de contrôle1. Manguito de comprobación
1. Air filter case cover
1. Cache du boîtier de filtre à air1. Tapa de la caja del filtro de aire
5FK-9-64-8 4/8/02 1:26 PM Page 44

q w
q
w
1. Air filter element 2. Element guide1. Elément du filtre à air 2. Guide de l’élément1. Elemento filtrante de aire 2. Guía del elemento
8-45
3. Remove the air filter element, and sepa-
rate it from the guide.
4. Wash the element gently but thoroughly in
solvent.
w
Always use parts cleaning solvent to clean
the air filter element. Never use low flash
point solvents or gasoline to clean the air fil-
ter element because the engine could catch
fire or explode.
5. Squeeze the excess solvent out of the filter
and let it dry.
cC
Do not twist the filter element when
squeezing it.
5FK-9-64-8 4/8/02 1:26 PM Page 46

8-49
NOTE:
The air filter element should be cleaned every
20–40 hours. It should be cleaned and lubricat-
ed more often if the machine is operated in
extremely dusty areas. Each time filter element
maintenance is performed, check the air inlet to
the filter case for obstructions. Check the air
cleaner rubber joint to the carburetor and mani-
fold fittings for an air-tight seal. Tighten all fit-
tings securely to avoid the possibility of unfil-
tered air entering the engine.
cC
Never operate the engine with the air filter
element removed. This will allow unfiltered
air to enter, causing rapid engine wear and
possible engine damage. Additionally, opera-
tion without the filter element will affect car-
buretor jetting with subsequent poor perfor-
mance and possible engine overheating.
5FK-9-64-8 4/8/02 1:26 PM Page 50

q
1. Air filter case cover1. Cache du boîtier de filtre à air1. Tapa de la caja del filtro de aire
1. Carburetor cap securing plate
1. Plaque de fixation du bouchon du carburateur1. Placa de seguridad de la tapa del carburador
8-57
7. Remove the air filter case cover.
8. Remove the securing plate of each carbu-
retor.
q
5FK-9-64-8 4/8/02 1:26 PM Page 58

8-65
7. Tighten the joint screws of each carbure-
tor.
Throttle cable adjustment
After the jet needle clip positions are changed,
throttle cable adjustment may be necessary.
1. Move the throttle lever a few times.
2. Push the throttle lever forward until it stops
and hold it in this position.
3. Check through the window of each carbu-
retor to see if the punch mark on the throt-
tle valve is at the specified position.
4. If not, loosen the locknuts and turn the
adjusters until proper position is obtained.
5. Move the throttle lever a few times and
recheck the position.
6. Install the fuel tank, side cover, radiator
cover and air filter case cover.
7. Reconnect the fuel hoses.
8. Install the seat.
a
wq
a. Specified position : 0–1mma. Position spésifiée : 0 à 1mma. Posición especificada : 0–1mm
1. Locknut (×2) 2. Adjuster (×2)
1. Contre-écrou (×2) 2. Dispositif de réglage (×2)1. Tuerca de bloqueo (×2) 2. Tensor (×2)
5FK-9-64-8 4/8/02 1:26 PM Page 66

10-2
Model YFZ350
Engine oil (2-cycle):
Type Yamalube R, Castrol R30, A545, A747
Mixing ratio See page 5-15.
Transmission oil:
Type SAE10W-30
Rcommended transmission oil classification: API Service SE, SF, SG type or higher
Quantity
Periodic oil change 1.5 L
Total amount 1.7 L
Radiator:
(Including all routes) 1.5 L
Air filter: Wet type element
10
cC
In order to prevent clutch slippage (since the
engine oil also lubricates the clutch), do not
mix any chemical additives. Do not use oils
with a diesel specification of “CD” or oils of
a higher quality than specified. In addition,
do not use oils labeled “ENERGY CONSERV-
ING
II” or higher.
5FK-9-64-9~11 4/8/02 2:35 PM Page 13
