oil level YAMAHA BLASTER 200 2003 Manuale de Empleo (in Spanish)

LOCATION OF THE WARNING AND
SPECIFICATION LABELS .......................1-1
SAFETY INFORMATION .........................2-1
DESCRIPTION AND MACHINE
IDENTIFICATION.....................................3-1
Identification number records ...............3-3
Key identification number .....................3-5
Vehicle identification number ...............3-7
Model label ...........................................3-9
CONTROL FUNCTIONS..........................4-1
Main switch ...........................................4-1
Indicator lights ......................................4-3
Oil level warning light checking
method ...............................................4-5
Handlebar switches ..............................4-9Throttle lever ......................................4-11
Throttle OverRide System ..................4-13
Speed limiter ......................................4-15
Clutch lever ........................................4-17
Brake lever .........................................4-17
Brake pedal ........................................4-19
Parking brake .....................................4-19
Shift pedal ..........................................4-23
Kick starter .........................................4-23
Fuel tank cap ......................................4-25
Fuel cock ............................................4-25
Starter (choke) ....................................4-27
Seat ....................................................4-29
Front shock absorber adjustment .......4-31
Rear shock absorber adjustment .......4-33
PRE-OPERATION CHECKS ...................5-1
Front and rear brakes ...........................5-5
Fuel ......................................................5-9
EBU00015
CONTENTS
1
2
3
4
5
5VM-9-60 (0~3 shou) 6/20/02 4:12 PM Page 12

4-3
EBU00043
Indicator lights
EBU01274
Oil level warning light “7”
This light comes on when the oil level is low.
The light circuit can be checked by the following
procedure.
cC
Always make sure there is enough engine oil
before starting the engine.
1
1. Oil level warning light “7”1. Témoin d’avertissement du niveau d’huile “7”1. Luz de aviso del nivel del aceite “7”
5VM-9-60 (4~5 shou) 6/20/02 4:14 PM Page 4

4-5
EBU00757
Oil level warning light checking method
Start the engine.
Wait a few seconds.
Engine oil level and
electrical circuit are OK.Supply engine oil.
Oil level warning light
does not come on
(see NOTE).
Ask a Yamaha dealer to
inspect the electrical circuit.
NOTE:
If the main switch is turned off after the oil level
warning light goes off and the engine is immedi-
ately started again, the oil level warning light
may not come on. This does not indicate a cir-
cuit failure.
Turn the main switch to
“ON” and the engine
stop switch to“RUN”.
Oil level warning
light comes on.
The oil level warning
light stays on.The oil level warning light
goes off.
5VM-9-60 (4~5 shou) 6/20/02 4:14 PM Page 6

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes9Check operation, free play, fluid level and fluid leakage. 5-5–5-7
9Fill with DOT 4 brake fluid if necessary. 8-55–8-63
Clutch9Check operation, condition and lever free play. 8-71
Parking brake9Check operation, condition and cable free play. 8-65
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-9–5-11
Transmission oil9Check oil level.
9Fill with oil if necessary.5-15, 8-17–8-23
2-cycle engine oil9Check oil level.
9Fill with oil if necessary.5-13
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-17, 8-73–8-79
Throttle9Check for proper throttle cable operation. 5-17, 8-53
Wheels and tires9Check tire pressure, wear and damage. 5-21–5-27, 8-87
Fittings and fasteners9Check all fittings and fasteners. 5-17
Lights9Check for proper operation. 5-19, 8-89–8-99
5VM-9-60 (4~5 shou) 6/20/02 4:15 PM Page 38

5-13
EBU00134
Engine oil
Make sure the engine oil is at the specified level.
Add oil as necessary (see page 10-2).
NOTE:
Be sure to push the cap into the filler neck until it
is properly seated.
q
1. Oil tank filler cap1. Bouchon de remplissage de réservoir d’huile1. Tapa de llenado de depósito de aceite
Recommended oil:
Air-cooled 2-stroke engine oil
Oil quantity:
Total amount:
1.3 L
5VM-9-60 (4~5 shou) 6/20/02 4:15 PM Page 50

5-15
EBU01308
Transmission oil
Make sure the transmission oil is at the specified
level. Add oil as necessary. (See pages 8-17–
8-23.)
cC
8In order to prevent clutch slippage (since
the transmission oil also lubricates the
clutch), do not mix any chemical additives.
Do not use oils with a diesel specification of
“CD” or oils of a higher quality than speci-
fied. In addition, do not use oils labeled
“ENERGY CONSERVING
II” or higher.
8Make sure that no foreign material enters
the crankcase.
Recommended oil:
SAE 10W30
Recommended oil classification:
API Service SE, SF, SG type or higher
Oil quantity:
Total amount:
0.7 L
Periodic oil change:
0.65 L
5VM-9-60 (4~5 shou) 6/20/02 4:15 PM Page 52

8-9
NOTE:
8Recommended brake fluid: DOT 4
8Brake fluid replacement:
9When disassembling the master cylinder or caliper cylinder, replace the brake fluid. Normally
check the brake fluid level and add fluid as required.
9On the inner parts of the master cylinder and caliper cylinder, replace the oil seals every two
years.
9Replace the brake hoses every four years, or if cracked or damaged.
5VM-9-60 (8 shou) 6/20/02 4:22 PM Page 10

EBU01277
Transmission oil
Transmission oil measurement
1. Place the machine on a level place.
2. Warm up the engine for several minutes,
and stop it.
3. Check the oil level through the level window
located at the right side crankcase cover.
NOTE:
Wait a few minutes until the oil level settles
before checking.
4. The oil level should be between the maxi-
mum and minimum marks. If the level is low,
add oil to raise it to the proper level.
1
2
3
1
1. Level window
2. Maximum level mark 3. Minimum level mark
1. Regard
2. Repère de niveau maximum 3. Repère de niveauminimum
1. Mirilla
2. Marca de máximo 3. Marca de mínimo
8-17
5VM-9-60 (8 shou) 6/20/02 4:22 PM Page 18

q
1. Drain bolt1. Boulon de vidange1. Perno de drenaje
8-19
Transmission oil replacement
1. Place the machine on a level place.
2. Warm up the engine for several minutes,
and stop it.
3. Place a container under the engine.
4. Remove filler cap and drain bolt to drain the
oil.
5. Install the drain bolt and tighten to specifica-
tion.
6. Fill the engine with oil and install the filler
cap.
1
1. Transmission oil filler cap1. Bouchon de remplissage d’huile1. Tapón de llenado del aceite
Tightening torque
Drain bolt:
20 Nm (2.0 m0kgf)
5VM-9-60 (8 shou) 6/20/02 4:22 PM Page 20

8-23
7. Start the engine and warm up for a few min-
utes. While warming up, check for oil leak-
age. If oil leakage is found, stop the engine
immediately, and check for the cause.
8. Check the oil level.
5VM-9-60 (8 shou) 6/20/02 4:22 PM Page 24
