Indicator lights
EBU01274
Oil level warning light “7”
This light comes on when the oil level is low.
The light circuit can be checked by the following
procedure.
cC
Always make sure there is enough engine oil
before starting the engine.
1
1. Oil level warning light “7”1. Témoin d’avertissement du niveau d’huile “7”1. Luz de aviso del nivel del aceite “7”
5VM-9-61-02 3/14/03 9:35 PM Page 4

4-5
EBU00757
Oil level warning light checking method
Start the engine.
Wait a few seconds.
Engine oil level and
electrical circuit are OK.Supply engine oil.
Oil level warning light
does not come on
(see NOTE).
Ask a Yamaha dealer to
inspect the electrical circuit.
NOTE:
If the main switch is turned off after the oil level
warning light goes off and the engine is immedi-
ately started again, the oil level warning light
may not come on. This does not indicate a cir-
cuit failure.
Turn the main switch to
“ON” and the engine
stop switch to“RUN”.
Oil level warning
light comes on.
The oil level warning
light stays on.The oil level warning light
goes off.
5VM-9-61-02 3/14/03 9:35 PM Page 6

4-11
EBU00063
Throttle lever
Once the engine is running, movement of the
throttle lever will increase the engine speed.
Regulate the speed of the machine by varying
the throttle position. Because the throttle is
spring-loaded, the machine will decelerate, and
the engine will return to an idle any time the
hand is removed from the throttle lever.
Before starting the engine, check the throttle to
be sure it is operating smoothly. Make sure it
returns to the idle position as soon as the lever
is released.
w
Malfunction of the throttle could make it diffi-
cult to speed up or slow down when you
need to. This could cause an accident.
Check the operation of the throttle lever
before you start the engine. If the throttle
does not work smoothly, check for the
cause. Correct the problem before riding the
ATV or consult a Yamaha dealer.
q
1. Throttle lever1. Levier d’accélération1. Palanca del aceleración
5VM-9-61-02 3/14/03 9:35 PM Page 12

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes9Check operation, free play, fluid level and fluid leakage. 5-5–5-7
9Fill with DOT 4 brake fluid if necessary. 8-55–8-63
Clutch9Check operation, condition and lever free play. 8-71
Parking brake9Check operation, condition and cable free play. 8-65–8-67
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-9–5-11
Transmission oil9Check oil level.
9Fill with oil if necessary.5-15, 8-17–8-23
2-cycle engine oil9Check oil level.
9Fill with oil if necessary.5-13
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-17, 8-73–8-79
Throttle9Check for proper throttle cable operation. 5-17, 8-53
Wheels and tires9Check tire pressure, wear and damage. 5-21–5-27, 8-87
Fittings and fasteners9Check all fittings and fasteners. 5-17
Lights and switches9Check for proper operation. 5-19, 8-89–8-99
5VM-9-61-02 3/14/03 9:35 PM Page 38

6-9
EBU00180
Starting a warm engine
To start a warm engine, refer to the “Starting a
cold engine” section. The starter (choke) should
not be used. The throttle should be opened
slightly.
EBU00182
Warming up
To get maximum engine life, always warm up
the engine before starting off. Never accelerate
hard with a cold engine! To see whether or not
the engine is warm, check if it responds to the
throttle normally with the starter (choke) turned
off.
5VM-9-61-03 3/14/03 10:47 PM Page 10

EBU08371
Transmission oil
Transmission oil measurement
1. Place the machine on a level surface.
2. Warm up the engine for several minutes,
and stop it.
3. Check the oil level through the level window
located at the right side crankcase cover.
NOTE:
Wait a few minutes until the oil level settles
before checking.
4. The oil level should be between the mini-
mum and maximum marks. If the level is
low, add the recommended oil to raise it to
the proper level.
1
2
3
1
1. Level window
2. Maximum level mark 3. Minimum level mark
1. Hublot de contrôle du niveau d’huile
2. Repère de niveau maximum 3. Repère de niveauminimum
1. Mirilla del nivel
2. Marca de máximo 3. Marca de mínimo
8-17
5VM-9-61-05 3/14/03 10:48 PM Page 18

8-23
7. Start the engine and warm it up for a few
minutes. While warming up, check for oil
leakage. If oil leakage is found, stop the
engine immediately, and check for the
cause.
8. Check the oil level.
5VM-9-61-05 3/14/03 10:48 PM Page 24

8-37
NOTE:
The sponge material should be cleaned every
20–40 hours. It should be cleaned and lubricat-
ed more often if the machine is operated in
extremely dusty areas. Each time air filter ele-
ment maintenance is performed, check the air
inlet to the filter case for obstructions. Check the
air filter case rubber joint to the carburetor and
manifold fittings for an air-tight seal. Tighten all
fittings securely to avoid the possibility of unfil-
tered air entering the engine.
cC
Never operate the engine with the air filter
element removed. This will allow unfiltered
air to enter, causing rapid engine wear and
possible engine damage. Additionally, opera-
tion without the air filter element will affect
carburetor jetting with subsequent poor per-
formance and possible engine overheating.
5VM-9-61-05 3/14/03 10:48 PM Page 38

8-39
EBU12831
Carburetor settings
In extremely cold weather, it is necessary to
change the carburetor settings to maintain opti-
mum engine performance and to prevent engine
damage.
w
8Improperly servicing or adjusting the car-
buretor could cause malfunction with the
possibility of an accident or the carburetor
could leak fuel, which would be a fire haz-
ard.
8Carburetor adjustments should only be
performed by a Yamaha dealer. Do not
attempt to perform these procedures
unless you have mechanical knowledge
and the necessary tools.
8Do not perform this procedure while the
engine is hot. Place a rag under the carbu-
retor to catch any fuel. Wipe up any spilled
fuel completely.
8After servicing the carburetor, always
check throttle operation before operating
the ATV to make sure it is working correct-
ly.
5VM-9-61-05 3/14/03 10:48 PM Page 40

8-105
EBU00440
Troubleshooting chart
Check fuel flow
1. Fuel
Check if there is
fuel in the fuel
tank
2. Compression
Kick the kick lever to
see if there is
compression
3. Ignition
Remove plug and
check electrodes
WetWipe clean with
dry cloth
DryAttach plug cap and
ground to chassisKick the kick
starter stronglySpark weak
Spark goodIgnition system normal
No spark
Ask a Yamaha dealer to inspect
Adjust plug gap or
replace plug
There is compressonCompression normal
Ask a Yamaha dealer to inspectNo compression
There is fuelTurn the fuel
cock to “OFF”
Remove the
fuel pipe
Water or dirt
mixed in fuel
No fuel
Fuel cock clogged
Some fuelTurn the fuel
cock to “RES”Restart engine
No fuelSupply fuel
Clean the fuel tank
Turn the fuel
cock to “ON”
Clean the fuel cock
