drain bolt YAMAHA BLASTER 200 2005 Manuale de Empleo (in Spanish)

q
1. Drain bolt1. Boulon de vidange1. Perno de drenaje
8-19
Transmission oil replacement
1. Place the machine on a level surface.
2. Warm up the engine for several minutes,
and stop it.
3. Place a container under the engine to col-
lect the used oil.
4. Remove the oil filler cap and drain bolt to
drain the oil.
5. Install the drain bolt and tighten it to the
specified torque.
6. Fill the engine with the recommended oil
and install the filler cap.
1
1. Transmission oil filler cap1. Bouchon de remplissage d’huile1. Tapón de llenado del aceite
Tightening torque
Drain bolt:
20 Nm (2.0 m0kgf)
5VM-9-62-05 3/12/04 4:15 PM Page 20
