EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes9Check operation, free play, fluid level and fluid leakage. 5-5–5-7
9Fill with DOT 4 brake fluid if necessary. 8-55–8-63
Clutch9Check operation, condition and lever free play. 8-71
Parking brake9Check operation, condition and cable free play. 8-65–8-67
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-9–5-11
Transmission oil9Check oil level.
9Fill with oil if necessary.5-15, 8-17–8-23
2-cycle engine oil9Check oil level.
9Fill with oil if necessary.5-13
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-17, 8-73–8-79
Throttle9Check for proper throttle cable operation. 5-17, 8-53
Wheels and tires9Check tire pressure, wear and damage. 5-21–5-27, 8-87
Fittings and fasteners9Check all fittings and fasteners. 5-17
Lights and switches9Check for proper operation. 5-19, 8-89–8-99
5VM-9-62-02 3/12/04 4:13 PM Page 38

5-21
EBU00158
Tires
Always use the recommended tires.
w
Use of improper tires on this ATV, or opera-
tion of this ATV with improper or uneven tire
pressure, may cause loss of control, increas-
ing your risk of accident.
Pay attention to the following.
1. The tires listed below have been
approved by Yamaha Motor Co., Ltd. for
this model. Other tire combinations are
not recommended.
2. The tires should be set to the recom-
mended pressure:
8Recommended tire pressure
Front 30 kPa (0.30 kg/cm
2, 0.30 bar)
Rear 25 kPa (0.25 kg/cm2, 0.25 bar)
Manufacturer Size Type
FrontDUNLOP AT21 ×7–10 KT851A
CHENG SHIN AT21 ×7–10 C873N
RearDUNLOP AT21 ×10–8 KT895A
CHENG SHIN AT21 ×10–8 C874N
5VM-9-62-02 3/12/04 4:13 PM Page 58

5-23
8Check and adjust tire pressures when
the tires are cold.
8Tire pressures must be equal on both
sides.
3. Tire pressure below the minimum speci-
fied could cause the tire to dislodge from
the rim under severe riding conditions.
The following are minimums:
Front 27 kPa (0.27 kg/cm
2, 0.27 bar)
Rear 22 kPa (0.22 kg/cm2, 0.22 bar)
4. Use no more than the following pres-
sures when seating the tire beads.
Front 330 kPa (3.3 kg/cm
2, 3.3 bar)
Rear 280 kPa (2.8 kg/cm2, 2.8 bar)
Higher pressures may cause the tire to
burst. Inflate the tires very slowly and
carefully. Fast inflation could cause the
tire to burst.
5VM-9-62-02 3/12/04 4:13 PM Page 60

5-25
EBU00159
How to measure tire pressure
Use the low-pressure tire gauge.
NOTE:
The low-pressure tire gauge is included as stan-
dard equipment. Make two measurements of the
tire pressure and use the second reading. Dust
or dirt in the gauge could cause the first reading
to be incorrect.
Set pressure with tires cold.
Set tire pressures to the following specifications:
q
1. Low-pressure tire gauge1. Manomètre basse pression pour pneus1. Manómetro de baja presión
30 kPa
(0.30 kg/cm2,
0.30 bar)27 kPa
(0.27 kg/cm2,
0.27 bar)33 kPa
(0.33 kg/cm2,
0.33 bar) Recommended
pressureMinimum Maximum
25 kPa
(0.25 kg/cm
2,
0.25 bar)22 kPa
(0.22 kg/cm2,
0.22 bar)28 kPa
(0.28 kg/cm2,
0.28 bar) Front
Rear
5VM-9-62-02 3/12/04 4:13 PM Page 62

7-15
w
Always use the size and type tires specified
in the Owner’s Manual for this vehicle on
pages 5-21–5-23. Always maintain proper tire
pressure as described in the Owner’s Manual
on page 5-25. Use of improper tires on this
ATV, or operation of this ATV with improper
or uneven tire pressure, may cause loss of
control, increasing your risk of an accident.
Do not operate at speeds too fast for your
skills or the conditions.
w
Always go at a speed that is proper for the
terrain, visibility and operating conditions,
and your experience. Operating this ATV at
speeds too fast for your skills or the condi-
tions increases your chances of losing con-
trol of the ATV, which can result in an acci-
dent.
5VM-9-62-04 2/18/04 1:14 PM Page 16

8-3
EBU01222
Owner’s manual and tool kit
You are recommended to put this owner’s man-
ual and low-pressure tire gauge in the vinyl bag
and always carry them along with the owner’s
tool kit under the seat. The service information
included in this manual is intended to provide
you, the owner, with the necessary information
for completing your own preventive maintenance
and minor repairs. The tools provided in the
owner’s tool kit are sufficient for this purpose,
except that a torque wrench is also necessary to
properly tighten nuts and bolts.
NOTE:
If you do not have a torque wrench available
during a service operation requiring one, take
your machine to a Yamaha dealer to check the
torque settings and adjust them as necessary.
we
q
1. Owner’s manual
2. Low-pressure tire gauge
3. Owner’s tool kit
1. Manuel du propriétaire
2. Manomètre basse pression pour pneus
3. Trousse à outils du propriétaire
1. Manual del propietario
2. Comprobador de presión de los neumáticos
3. Equipo de herramientas del propietario
5VM-9-62-05 3/12/04 4:15 PM Page 4

8-8INITIAL EVERY
month 1 3 6 6 12
ITEM ROUTINEWhichever
km 320 1200 2400 2400 4800 comes first
(mi) (200) (750) (1500) (1500) (3000)
hours 20 75 150 150 300
* Front and rear9Check pad wear.
222
brake pads9Replace if necessary.
* Clutch9Inspect free play and operation.
2222
9Replace if necessary.
Drive chain9Lubricate, check free play and alignment.
2222
9Replace if necessary.
* Drive chain guard
9Check wear and replace if necessary.222
and rollers
* Steering system9Inspect play, clean and lubricate with lithium-soap-
22222
based grease.
* Front and rear9Inspect and lubricate with lithium-soap-based
22222
suspensiongrease.
Tires9Inspect air pressure, wheel runout, and tire wear.22222
* Wheels9Inspect bearings.
22222
9Replace bearings if necessary.
* Throttle, control 9Check routing and connection.
22222
cables9Lubricate.
Outside nuts and bolts9Tighten if necessary.22222
Frame9Clean and inspect.2222
Lighting9Inspect.22222
* Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service.
