Page 14 of 388
LOCATION OF THE WARNING AND
SPECIFICATION LABELS .......................1-1
SAFETY INFORMATION .........................2-1
DESCRIPTION AND MACHINE
IDENTIFICATION.....................................3-1
Identification number records ...............3-3
Key identification number .....................3-5
Vehicle identification number ...............3-7
Model label ...........................................3-9
CONTROL FUNCTIONS..........................4-1
Main switch ...........................................4-1
Indicator lights ......................................4-3
Oil level warning light checking
method ...............................................4-5
Handlebar switches ..............................4-9Throttle lever ......................................4-11
Throttle OverRide System ..................4-13
Speed limiter ......................................4-15
Clutch lever ........................................4-17
Brake lever .........................................4-17
Brake pedal ........................................4-19
Parking brake .....................................4-19
Shift pedal ..........................................4-23
Kick starter .........................................4-23
Fuel tank cap ......................................4-25
Fuel cock ............................................4-25
Starter (choke) ....................................4-27
Seat ....................................................4-29
Front shock absorber adjustment .......4-31
Rear shock absorber adjustment .......4-33
PRE-OPERATION CHECKS ...................5-1
Front and rear brakes ...........................5-5
Fuel ......................................................5-9
EBU00015
CONTENTS
1
2
3
4
5
5VM-9-62-01 3/12/04 2:33 PM Page 12
Page 68 of 388
4-3
EBU00043
Indicator lights
EBU01274
Oil level warning light “7”
This light comes on when the oil level is low.
The light circuit can be checked by the following
procedure.
cC
Always make sure there is enough engine oil
before starting the engine.
1
1. Oil level warning light “7”1. Témoin d’avertissement du niveau d’huile “7”1. Luz de aviso del nivel del aceite “7”
5VM-9-62-02 3/12/04 4:13 PM Page 4
Page 70 of 388
4-5
EBU00757
Oil level warning light checking method
Start the engine.
Wait a few seconds.
Engine oil level and
electrical circuit are OK.Supply engine oil.
Oil level warning light
does not come on
(see NOTE).
Ask a Yamaha dealer to
inspect the electrical circuit.
NOTE:
If the main switch is turned off after the oil level
warning light goes off and the engine is immedi-
ately started again, the oil level warning light
may not come on. This does not indicate a cir-
cuit failure.
Turn the main switch to
“ON” and the engine
stop switch to“RUN”.
Oil level warning
light comes on.
The oil level warning
light stays on.The oil level warning light
goes off.
5VM-9-62-02 3/12/04 4:13 PM Page 6
Page 372 of 388
10-5
Model YFS200
Suspension:
Front suspension Double wishbone
Rear suspension Swingarm (monocross)
Shock absorber:
Front shock absorber Coil spring/Oil damper
Rear shock absorber Coil spring/Gas-oil damper
Wheel travel:
Front wheel travel 180 mm
Rear wheel travel 180 mm
Electrical:
Ignition system C.D.I.
Generator system C.D.I. magneto
Headlight type: Bulb type
Bulb voltage, wattage ×quantity:
Headlight 12V, 35 W/36.5 W ×1
Tail/brake light 12V, 5/21 W ×1
Oil level warning light 12V, 3.4 W ×1
5VM-9-62-06 2/18/04 1:20 PM Page 16
